D.2 Characteristics of the different interfaces
ADSL / ADSL2 / ADSL2+ Interface
Standards supported
Transmission Code
Maximum upward
transmission rate
Maximum downward
transmission rate
Latence
TX Power
Access Impedance
Range
Connection technology
Interface LAN Ethernet
Rate
Standard
Connection technology
F@ST 4310 Reference Manual
• G.992.1 (ADSL), G.992.3 (ADSL2), G.992.5 (ADSL2+)
• G.994.1 (G.Handshake)
• DMT
• 24,5 Mbit/s
• 1,3 Mbit/s
• Simple (Fast or interleaved)
• 12,5 dB
• 100 Ù
• According to standard G.992.1 table Annex
• RJ11
• 10 Mbit/s or 100 Mbit/s, self-configurable
• Half / Full Duplex
• IEEE 802.3
• RJ45
• Type MDI or MDI-x self-detecting port
• Crossed or straight cord
Sagemcom Broadband SAS document. Reproduction and disclosure prohibited
Annex D - Technical Characteristics
Page D-3
