7- TV over ADSL service

7.1 Introduction

Your router is compatible with TV over ADSL technology.

7.2 Access to the optional TV over ADSL service

To access this service, you must have:
• made the connection in accordance with section 2.3.4,
• necessarily taken a subscription with your Internet Service Provider (ISP)
• configured one VC (Virtual Channel) dedicated to video, and another VC dedicated to data (see screen
below)
Note
In the example above, the ATM interface "ppp_8_35_1" is dedicated to data and the
ATM interface "nas_8_50_1" is dedicated to video.
• configured accordingly "Port Mapping" in Advanced Setup (see section 6).
