Tools and Parts

Gather the required tools and parts before starting installation.
Read and follow the instructions provided with any tools listed
here.
I
Flat-blade screwdriver
I
#2 Phillips screwdriver
I
Adjustable wrench that
opens to 1" (2.54 cm) or
hex-head socket wrench
(for adjusting dryer feet)
I
Level
I
Vent clamps
Parts supplied
Remove parts package from dryer drum. Check that all parts are
included.
4 Leveling legs
NOTE: Do not use leveling legs if installing the dryer on a
pedestal.
Parts needed
Check local codes. Check existing electrical supply and venting.
See "Electrical Requirements" and "Venting Requirements"
before purchasing parts.
I
For close-clearance installations between 28.65" (72.77 cm)
and 34.15" (86.74 cm), see "Plan Vent System" section for
venting requirements.
Mobile home installations require metal exhaust system hardware
available for purchase from your local Sears store or Sears
Service Center. For further information, please call
®
1-800-4-MY-HOME
(1-800-469-4663).

INSTALLATION INSTRUCTIONS

I
Caulking gun and
compound (for installing
new exhaust vent)
I
Tin snips (new vent
installations)
I
¼" nut driver or socket
wrench (recommended)
I
Tape measure
34.15"
(86.74 cm)

Optional Pedestal

Are you placing the dryer on a pedestal? You can purchase a
pedestal separately for this dryer. This pedestal will add about
10" (25.4 cm) to the height of your unit for a total height of
approximately 46" (116.8 cm).
For a garage installation, you will need to place the dryer at least
18" (46 cm) above the floor.
Optional pedestal
The pedestal is available in:
White - Part Number 46822
To order, call your local Sears store. For further information,
please call 1-800-4-MY-HOME
Stack Kit
Are you planning to stack your Kenmore washer and dryer? To do
so, find the stack kit in the dryer drum. Follow instructions
included with the kit. See "Location Requirements."

Location Requirements

WARNING
Explosion Hazard
Keep flammable materials and vapors, such as
gasoline, away from dryer.
Place dryer at least 18 inches (46 cm) above the floor
for a garage installation.
Failure to do so can result in death, explosion, or fire.
You will need
I
A location that allows for proper exhaust installation. See
"Venting Requirements."
I
A separate 30-amp circuit.
I
A grounded electrical outlet located within 2 ft (61 cm) of
either side of the dryer. See "Electrical Requirements."
I
A sturdy floor to support the total dryer weight of 127 lbs
(57.6 kg). The combined weight of a companion appliance
and pedestals should also be considered.
®
(1-800-469-4663).
5
