Adjusting To The Body Size; Removal Of The Booster Inlay - CYBEX JUNO-FIX User Manual

g
8
e
h
g
d

ADJUSTING TO THE BODY SIZE

For a proper height adjustment of the CYBEX JUNO-fix a booster inlay (g)
is included and already inserted under the seat cover when purchased. It is
recommended to use this height adjustment inlay (g) between the age of 9 and
18 months. For children over 19 months the height adjustment inlay (g) may be
removed. Afterwards the height adjustment should be regulated by moving the
headrest (e) into the correct position. Pull the adjustment handle (h) in order to
release the headrest (e). The seat is correctly adjusted if you can fit 2 fingers
between the bottom edge of the headrest (e) and the shoulder of the child. Pull the
adjustment handle (h) in order to unlock the shoulder and headrest.
Note! Shoulder and headrest (e) need to be perfectly adjusted in height to provide
the best protection and comfort for your child and to also guarantee the optimal
position of the diagonal belt. The height of the shoulder and headrest can be
adjusted in 8 positions. The shoulder part is attached to the headrest and does not
have to be adjusted separately.

REMOVAL OF THE BOOSTER INLAY

• Open the press buttons at the front of the booster cover (d).
• Lift the booster cover until the height adjusting inlay (g) can be easily removed
from the front.
• Remove the height adjustment inlay (g) according to the above age
recommendation.
• Put the seat cover back in its original position and fasten the press buttons.
