Summary of Contents for Gosafe G626
- Page 1 ...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Device Introduction 1.1 Physical Appearance 1.2 Speci cation 1.3 Features 2. Quick Install Instructions 2.1 Open device 2.2 Insert SIM card 2.3 Power on 2.4 Set User No. 2.5 Modify Password 2.6 Set Work Mode 2.7 Con guration 3. -
Page 3: Device Introduction
1.DEVICE INTRODUCTION G626 is a great tracking device which is designed by Gosafe Company Limited. It combines GSM and SMS with GPS to locate your belongings .Due to its compact size and long life battery, G626 can be easily installed and concealed somewhere in your vehicle, motorcycle or boat to track and locate them. -
Page 4: Speci Cation
Accsessories 1.2 SPECIFICATION Physical Specification Size 86(L) x 60(W) x 25(H) mm Weight 160g (Including Battery) IP Rating IP65 Power Rechargeable Battery 5V DC; Li-Ion 3.7V 2400mAh Power Consumption Sleep Mode <700uA, Active Mode <300mA TI MSP430 12KB RAM, 256KB Flash Antenna Internal Modem... -
Page 5: Features
Channels 50 Parallel Channels Sensitivity -162dBm Navigation update 1sec Acquisition Cold Starts: 27s Aided Starts: <1s Hot Starts: <1s Location Accuracy 2.5 to 10m (Strong Signals) 500 m (Weak Signals) Sensor 3D G-Force Sensor Onboard Memory Flash 10,000 Locations Environmental Conditions Operating Temperature -20°C to +60°C Storing Temperature... -
Page 6: Quick Install Instructions
2.QUICK INSTALL INSTRUCTIONS 2.1 OPEN DEVICE Open G626 enclosure carefully by screwing off the four screws. 2.2 INSERT SIM CARD Insert SIM card into the SIM card jacket correctly according to the below picture. Note Please do activate the SIM card, disable its PIN code function, and make sure SIM card has enough balance before operating the device. -
Page 7: Power On
2.3 POWER ON Connect battery to device, like the shown in the picture below; 2.4 SET USER NO. with country code Message 1234,UNO;+8613912345678 without country code 1234,UNO;13912345678 Command Control Word Send SMS Reply UNO:13912345678 UNO:+8613912345678... -
Page 8: Modify Password
2.5 MODIFY PASSWORD Connect USB cable to the device and connect it with the computer. For further details, please refer to the documents for configuration. New Password Message 1234,UPW;5678 Command Control Word Factory Password Send SMS Reply UPW: 5678 Note Please memorize your New Password and wait for confirmation SMS for password modification from device. -
Page 9: Set Work Mode
2.6 SET WORK MODE There are 3 different work modes configurable for device according to user's need: O, S and G. To set device in G Work Mode, you should send the following SMS command to the SIM card No. the type of message Message 1234,UUM;30M;G;T... -
Page 10: Con Guration
2.7 CONFIGURATION Connect USB cable to the device and connect it with the computer. For further details, please refer to the documents for configuration. -
Page 11: Commands For Device Setting
3. COMMANDS FOR DEVICE SETTING All the commands for device setting in this User Manual are in the same format: 3.1 COMMAND TABLE The user commands are shown in the below table. The whole command format is "PSW,CMDXX;Para". Table only show the second part "CMDXX;Para" in the column of command format. Description Ctrl Word Command... -
Page 12: Set Apn
Description Ctrl Word Command Reply Remarks Parameter range "APN": 1~30 characters "user name": 0~30 characters "password": 0~30 characters The second command APN: APN; user way "APN; APN”Means only set APN; APN; user name; name; APN. Device comes with of some password set APN password... - Page 13 Description Ctrl Word Command Reply Remarks 5: open GPS module on demand, closing 3D location in reservation setting of GPS reach time, there is no 2D location when GPS research time is over, closing module. GSM mode consists of: 0: always on GSM; 1: open GSM module on-demand.
- Page 14 Description Ctrl Word Command Reply Remarks 4: open GSM module on-demand. (Open conditions: Getting LBS data, uploading data according to setting and alarm occurred). Then upload all data. Then close module. 5: open GSM module on-demand. (Open conditions: Getting LBS data, Uploading SMS data.
-
Page 15: Setting Uploading Tcp Server Mode
Description Ctrl Word Command Reply Remarks 8: open GSM module on-demand. (Open conditions: Getting LBS data, Uploading SMS data. Uploading saved data according to setting and alarm occurred). Then upload all data. Then close module. Default: PSM:00 One Can set two modes. TPM is the same as TPM0, these two both are mode 0.TMP1 is mode 1. -
Page 16: Enable/Disable Over Speed Alarm Parameter
Description Ctrl Word Command Reply Remarks "parameter2" (30 seconds), the device s will regard the vehicle as in moving status. "40": sustained stop time. Unit is second. This parameter is used to judge whether the vehicle statusis shift from move status to stop status. -
Page 17: Set Time Zone
Description Ctrl Word Command Reply Remarks Set local time zone parameter from -12:00 to 12:00, Negative represent western time Time zone 3.14 zone, positive represent east TZN;8:00 TZN:8:00 setting eastern time zone Default : 0 : 00 User alarm 3.15 cleared Query SIM *100#: USSD code used to get... -
Page 18: Commands Wait
1 min, device would receive and process real-time commands then reply accordingly. 3.19ALARMS The device sends alarm immediately it triggers. The message receive when device is in alarm as follows: G626 V1.05 GPS 6/77 UTC 11-00.5-14 05:33:47 N23.164479 E113.428606 SPD:0km/h 0... - Page 19 Description SMS Received Moving (When the vehicle G626 V1.05 I stopped and the movement GPS 6/77 sensor is enable the device sends UTC 11-05-14 05:33:47 move alarm on the trigger N23.164479 of movement sensor) E113.428606 SPD:0km/h 0 Alarm:Moving Geo-Fence (Future use the G626 V1.05...
-
Page 20: Default Parameters
3.20 DEFAULT PARAMETERS Description Parameter User number (EMPTY) SMS center number (EMPTY) PIN code of SIM 1234 APN list APN list of China only User password 1234 User upload mode 30M;G;W Manager phone number (empty) Manager upload mode 30M；G；T Server IP or domain name domain name (empty) IP (114.142.154.28) TCP port... -
Page 21: Structures Of Sms From Device
4. STRUCTURES OF SMS FROM DEVICE 4.1NORMAL LOCATION SMS FORMAT (G MODE) (Located Successful) Gosafe G626 V1.05 Device Name and Version GPS 3/56 Satellites Connected &Time used for Location (secs) LTM08:00 11-24-0 02:54 Speci c time zone and Location time based on speci c time zone N23 9.8329... -
Page 22: Error Command Alert
(Located Successful）Yandex link Device Name and Version Gosafe G626 V1.05 Yandex Link http://m.maps.yandex.ru/?ll=116.3875,3 9.949328&pt=116.3875,39.949328&z=12 Temperature TMP=25.6C Power PWR=12.5V (Located Unsuccessful Gosafe G626 V1.05 Device Name and Version MCC=460 Mobile Country Code MNC=1 Mobile Network Code LAC=517A Location Area Code CID=1FB1 Cell Identity TMP=25.6C... -
Page 23: Led Flashes & Relevant Device Status
5. LED FLASHES & RELEVANT DEVICE STATUS There are some internal LED lights to re ect device status and the charging state in G626. Generally, only we have some problems about the G626, we will disassemble it and check the LED lights for status. - Page 24 Device also uses LED ashes to indicate relevant error if any of the following situations happens: Device Error, SIM card no balance, GSM network cannot register. When there is any error above, LED light will ON for 1sec then ash quickly, which helps to trouble shoot the errors;...
-
Page 25: Appendix
6. APPENDIX 6.1 CHARACTERS FOR COMMANDS “ & ‘ < >... - Page 26 www.gosafesystem.com...
