SPECIFICATIONS

General (Dimensions & Weight):
Dimensions (base): 14.5"(H) x 19"(W) x 20.5"(D) (36cm x 48cm x 52cm)
Weight: 23lbs. (10.4kg)
Operating temperature range: 50-104°F / 10-40°C
Storage temperature range: 32-122°F / 0-50°C
Controls: Light Switch On/Off, Auto Focus/Focus Lock, Preset,
Magnification, Mode, Power On/Off
Magnification (based upon usage of a 19" DVI monitor):
2.7x (minimum) to 62x (maximum)
Power Supply: P/N:
TR9CG1200C35-MED
(EV Part Number: PWS-0500-00)
100V-240V-0.5A MAX, 50-60Hz
15V - 1.2A
Equipment classification (iec 601-
1):
Type of Protection: Class I
Degree of Protection: Type B
Environmental Rating: IP20
Mode of Operation: Continuous
29
Specifications
