- Page 1 Assembly and Operating Manual 3D cap-232 Specification: *Length: 25-9/10"(655mm) *Wing Span: 29-3/5"(750mm) *Flying Weight: 15-9/10 oz (450g)
- Page 2 The receiving system is powered by the speed Integral wing panels with L.H / R.H. ailerons and SKYANGEL 3D range and thank you for placing controller’s integral BEC system. servos your trust in us.
- Page 3 Assembly and Operating Manual 3D cap-232 Fig. 1 - Tighten the control rod in horizon tail with screw. Fig. 2 -Reverse the procedure to the right wing. The photo shows the finished view. Fig. 3 -Tighten the control rod in vertical tail with screw.
- Page 4 Assembly and Operating Manual 3D cap-232 Fig. 5 -Tighten the control rod in wing set with screw. Fig.6 - Photo shows the finished view Figs. 7 - Reverse the procedure to the left wing. The photo shows the finished view.
- Page 5 Assembly and Operating Manual 3D cap-232 Figs. 9 -Assemble the taildraggers to the steering hole. Figs. 10 -Apply glue to vertical tail . Figs. 11 - Assemble the vertical tail and taildraggers to the fuselage. Figs. 12 -Photo shows the vertical tail and taildraggers...
- Page 6 Assembly and Operating Manual 3D cap-232 Figs. 13 -Apply glue to the fuselage . Figs. 14 -Apply glue to the horizon tail. Figs. 15 -Photo shows the horizon tail settled in the fuselage. Figs. 16 - Connect the horizon tail pushrod cullet to control...
- Page 7 Assembly and Operating Manual 3D cap-232 Figs. 17 -Reverse the procedure to the left side. The photo shows the finished view. Figs.18 -Connect the vertical tail pushrod collet to control rod arm. Figs.19 -Photo shows the finished view. Figs. 20 - Connect the wing panel push rod to the servo arm at first hole.
- Page 8 Assembly and Operating Manual 3D cap-232 Figs. 21 -Connect the wing panel push rod to control rod arm. Figs.22 -Photo shows the finished view . Figs. 23 - Reverse the procedure to the left wing. The photo shows the finished view.
- Page 9 Assembly and Operating Manual 3D cap-232 Figs. 25 -Tight the fixup presser with screw. Figs. 26 -Tight the plastic spinner with screw. Figs. 27 - Fixed the propeller with screw. Figs. 28 - Connect to the receiver and place the receiver in...
- Page 10 Assembly and Operating Manual 3D cap-232 Figs. 29 - Place the flight battery in the fuselage. Figs. 30 - Photo shows battery leads connected to the speed controller. Figs. 31-32 - Opening and closing the canopy: The canopy is retained by the cowl at the front,...
- Page 11 Assembly and Operating Manual 3D cap-232 Fig. 33 Balancing - Place the canopy on the fuselage. - Place the battery in the model of balancing; do not connect it. - Make the Centre of Gravity on both sides. - Support the model at the marked C.G. and allow it to hang freely.
- Page 12 Assembly and Operating Manual 3D cap-232 Figs.36-37 - Check the channel assignment of the control surfaces, and swap over the connectors at the - Check the neutral position of the control surfaces. Make adjustments to the clevises if necessary. - Stand behind the model.
- Page 13 Assembly and Operating Manual 3D cap-232 - Switch the transmitter on, and connect the Test-flying, flying notes - With the motor running at full-throttle, give the flight pack aeroplane a firm launch directly into any breeze, Read the sections in the Safety - Check the direction of rotation of the motor: with the fuselage and wings level.
- Page 14 Assembly and Operating Manual 3D cap-232 Jiangyin Skyangel Electronic Technology Co., Limited. 5th Floor, A3 Building, Xinjianxing Technology Industrial Park, Fengxin Road, Guangming Town, Bao'an, Shenzhen City, 518107 China Phone: +86 755 33699201 Fax: +86 755 33699203 www.skyangelrc.com...
