Assembly and operating instructions Assembly and Operating Manual...
Page 2
SKYANGEL Hummingbird range and thank you 2.4GHz radios systems are recommended, similar for placing your trust in us. to the unit included with our deluxe version.
Assembly and Operating Manual Fig. 1 Open the box and check all the parts. Parts Illustration Parts List Description Fuselage Nose Cone Wing Set – One Left (and one Right) Wing Panel Tail Set - One Left (and one Right) Horizontal Stabilizer with Elevator Tail Set - One Vertical Fin Cockpit Canopy One Left (and one Right) Rear Landing Gear Fixed Plate...
Page 4
Assembly and Operating Manual Fig. 2 - Locate the fuselage and nose cone Fig. 3 - Glue the nose to the front of fuselage (glue Fig. 4 - Glue the horizontal tail wings to the slots at not included). the rear of the fuselage (glue not included). Fig.
Page 5
Assembly and Operating Manual Fig. 8 - Apply glue to the sides of each main wing Fig. 9 - The photo shows the finished view after Fig. 10 - Locate the hardware set. panel (glue not included). gluing the wings in place. Fig.
Page 6
Assembly and Operating Manual Fig. 14 - Glue the vertical fin sections as shown in Fig. 15 - Connect the electronic speed controller Fig. 16 - Locate the battery and canopy. Charge the photo (glue not included). and servos to the receiver. Refer to the RC system the battery according to the safety instructions instructions for the correct channel sockets and before installing.
Page 7
Assembly and Operating Manual Fig. 20 - Locate the fixed plate for the front wheel. Fig. 21 - Glue the fixed plate into the fuselage as Fig. 22 - Attach the front wheel to the fixed plate. shown in the photo (glue not included). Fig.
Page 8
Assembly and Operating Manual Optional parts (not required) Fig. 26 – Two sets of 3 painted missiles, for extra realism, are included. Fig. 27 - Missiles shown after being separated. Cut apart for assembly as shown Fig. 28 - Glue missiles according to the main wing slots (glue not included). Fig.
Page 9
Assembly and Operating Manual Fig. 30 - Charge the flight battery; connect the Equalizer lead using and adapter lead matching your charger (adapter lead not included). Fig. 31 - Switch the transmitter on, and move the throttle stick to the “ Motor OFF”position. - Remove any loose objects such as cloths, tools or similar from the area in front of the model, as they could easily be sucked into the ducted fan.
Page 10
Assembly and Operating Manual Fig. 32 and 33 - Checking Ailerons and Elevators - Check that the control surfaces respond to the appropriate movements of the transmitter sticks. If not, swap over the connectors at the receiver. - Check the neutral position of the control surfaces; you may need to screw the clevises in or out to correct any discrepancy.
Page 11
Assembly and Operating Manual Fig. 35 - Checking the model’ s balance - Place the flight battery in its compartment, without connecting. - Mark the Centre of Gravity (CG) on both sides of the fuselage; the position is shown in the photo. - Support the model at the marked points and allow it to hang freely.
Page 12
A good flying site is a large, flat, open field; well away from trees, fences, Jiangyin Skyangel Electronic Technology Co., Limited. No.606 Zhencheng Road,Xiagang Town, Jiangyin city, Jiangsu Province, 214400, China Tel / Fax: +86-0510-86168833 www.jpower.hk...
