- Page 1 Assembly and Operating Manual Mirage 2000 SPECIFICATION: Length: 26-3/5"(675mm) Wing Span:20-3/5"(520mm) Flying Weight: 11-3/5 oz. (320g)
- Page 2 2.4GHz radios placed under stress. factory-assembled model aircraft from the systems are recommended, similar to the unit SKYANGEL range and thank you for placing included with our deluxe version. Kit contents your trust in us.
-
Page 3: Parts Illustration
Assembly and Operating Manual Fig. 1 Open the box and check all the parts. Parts Illustration Parts List Description Fuselage Integral wing panels Tail Set - One Vertical Fin Cockpit Canopy Nose cone Fuel tank Radio Control Transmitter (we highly recommend 2.4 GHz system) Balance Charger 850Ah 11.1V 20C Li-Po Battery Receiver... - Page 4 Assembly and Operating Manual Fig. 2 - Glue the control rod to wing set (glue not Fig. 3 - Remove any excess glue and hold in Fig. 4 - Connect the push rods to the aileron servo included). position until glue sets. The photo shows the arm and control horns.
- Page 5 Assembly and Operating Manual Fig. 8 - Apply glue to the fuselage. Fig. 9 - Remove any excess glue and hold in Fig. 10 - The photo shows the finished view after position until glue sets. The photo shows the gluing the wings in place.
- Page 6 Assembly and Operating Manual Fig. 14 - Hold in position until glue sets. The photo Fig. 15 – Apply glue to the fuel tank Fig. 16 – Apply glue to the wing set. shows the finished view. Fig. 17 - Hold in position until the glue sets. Photo Fig.
- Page 7 Assembly and Operating Manual Fig. 20 - The photo shows the finished view after Fig. 21 - Reverse the procedure to the right side. Fig. 22 - Apply glue to the Mommutator segments gluing the Mommutator segments in place. The photo shows the finished view for vertical fin Fig.
- Page 8 Assembly and Operating Manual Fig. 26 - Apply glue to the fuselage (glue not Fig. 27 - Assemble the nose cone to the fuselage. Fig. 28 - Apply glue to the fuel hose (glue not included). The photo shows the finished view. included).
- Page 9 Assembly and Operating Manual Fig. 32 - Photo shows battery leads connected to Fig. 33 - The canopy is held in place by magnets Fig.34 - Photo shows the finished view after the speed controller. and can be lifted off. canopy is assembled.
- Page 10 Assembly and Operating Manual Fig. 36 - Charge the flight battery; connect the Equalizer lead using and adapter lead matching your charger (adapter lead not included) Fig. 37 - Switch the transmitter on, and move the throttle stick to the “Motor OFF” position. (Diagram MODE 1 right throttle control stick)
- Page 11 Assembly and Operating Manual 38 and39- Checking Ailerons and Elevators Check that the control surfaces respond to the appropriate movements of the transmitter sticks. If not, swap over the connectors at the receiver. Make sure do not apply glue to control rods fastener before check the neutral position of the control surfaces Stand behind the model.
- Page 12 Assembly and Operating Manual Fig. 41- Checking the model’s balance Place the flight battery in its compartment, without connecting. Mark the Centre of Gravity (CG) on both sides of the fuselage; the position is shown in the photo. Support the model at the marked points and allow it to hang freely.
- Page 13 Switch the motor on, and launch the airplane strongly into the wind, with the fuselage and wings level. Allow the Mirage 2000 Jet to fly straight and level initially, do not try to turn it when it is close to the ground.
- Page 14 Jiangyin Skyangel Electronic Technology Co., Limited. 5th Floor, A3 Building, Xinjianxing Technology Industrial Park, Fengxin Road, Guangming Town, Bao'an, Shenzhen City, 518107 China Phone: +86 755 33699201 Fax: +86 755 33699203 www.skyangelrc.com...
