- Page 1 Assembly and Operating Manual Specification: *Length: 26-2/5"(670mm) *Wing Span: 39-2/5"(1000MM) *Flying Weight: 21-9/10 oz .(620g)
- Page 2 Fuselage, complete with motor, speed controller recommend 2.4 GHz systems. factory-assembled model aircraft from the and servo. TRAINER DHC and thank you for placing your The receiving system is powered by the speed Integral wing panels with L.H / R.H. ailerons and trust in us.
- Page 3 Assembly and Operating Manual Figs. 1 - Connect the control rod to horizontal tail ,tighten it with the screws. Figs. 2 -Photo shows the finished view. Fig. 3 -Connect the control rod to vertical tail, tighten it with the screws. Fig.
- Page 4 Assembly and Operating Manual Fig. 5 -Connect the control rod to aileron, tighten it with the screws. Fig. 6 - Photo shows the control rods have locked on the aileron. Fig. 7 -Reverse the procedure to the left wing. The photo shows the finished view.
- Page 5 Assembly and Operating Manual Fig. 9 -Apply glue to horizon tail . Fig. 10 -Photo shows the horizon tail settled in the fuselage. Figs. 11 -Connect the vertical tail push rod to control rod arm. Photo shows the finished view. Figs.
- Page 6 Assembly and Operating Manual Figs. 13 - Connect the wing panel push rod to the servo arm at second hole. Figs. 14 -Photo shows the finished view. Figs. 15 -Reverse the procedure to the left wing. The photo shows the finished view. Figs.
- Page 7 Assembly and Operating Manual Figs. 17 -Lock the fixup presser with screw. Figs. 18 -Photo shows the main panel assembled on the fuselage. Figs. 19 -Apply glue to the fixture of landing gear . Figs. 20 -Apply glue to the fuselage.
- Page 8 Assembly and Operating Manual Figs. 21 -Photo shows the fixture have settled in the fuselage. Figs. 22 -Reverse the procedure to the left wing. The photo shows the finished view. Figs. 23 - Assemble the landing gear to fuselage. Photo shows the finished view.
- Page 9 Assembly and Operating Manual Figs. 25 -Connect the channels to the receiver. Figs. 26 - Located the battery in the fuselage. Figs. 27 -Photo shows battery leads connected to the speed controller. Figs. 28 -Close the battery cover,Photo shows the finished view .
- Page 10 Assembly and Operating Manual Figs. 29 - Fixed the propeller with screw. Figs. 30 -Photo shows the propeller settled. Figs. 31 Balancing - Place the canopy on the fuselage. - Place the battery in the model of balancing; do not connect it.
- Page 11 Assembly and Operating Manual Figs. 32 -Charge the flight battery; connect the Equalizer lead using and adapter lead matching your charger (adapter lead not included). Figs. 33 - Switch the transmitter on, and move the throttle stick to the “Motor OFF” position. (Diagram MODE 1 right throttle control stick)
- Page 12 Assembly and Operating Manual Figs. 34 -36 Function test -Check the channel assignment at the receiver, and if necessary swap the plugs as necessary. - Set the transmitter sticks and trims to centre. - The control surfaces should now also be at centre (neutral). Adjust the clevis where necessary.
- Page 13 Assembly and Operating Manual Fig. 37 checking the electric power system - Caution: position the throttle stick in such a way that the motor cannot possibly start running.
- Page 14 Read the sections in the Safety - Check the direction of rotation of the motor: - Allow the DHC to fly straight ahead initially; don’t Notes entitled “Routine pre-flight when viewed from the front, the output shaft initiate turns close to the ground.
