3
Main Wing
Please apply glue to wing joiner and all surfaces in contact.
4
Vertical Fin
PM2x20mm Screw
2
d2xD5mm Washer
4
M2 Nylon Insert Lock Nut
2
5
Battery & ESC
Install and arrange the equipment as shown in
the picture.
Front
Battery Tie
Battery
E210NXMPO24831008
M2 Nylon Insert
Lock Nut
d2xD5mm
Washer
PM2x20mm
Ø5x135mm
Completed
Bottom View
30A Brushless ESC
P.4
30A Brushless
ESC
Cable Tie
Double-Sided tape
