Pre-Assembly Information - Compass 3D Plus Nitro Powered Helicopter Assembly Manual

When first opening your 3D Plus kit, you will notice that all of the parts are packaged and numbered to coordinate with the
assembly step numbers of this instruction manual. All small hardware (nuts, bolts, washers, etc.) for each step are packaged
separately within the main parts bags. When beginning a section, you will need to open only the bag with the corresponding
number to the section you are about to start. It is suggested that you place all of the hardware in an open container (e.g., servo
case) during assembly so as not to lose any of the small parts. It may also be helpful to familiarize yourself with the various
sizes of screws, bolts, nuts, etc., as illustrated in the appropriate assembly section before you begin assembly. In most cases, at
the end of each assembly section, there should be no parts remaining. Great care has been taken in filling the bags with the
correct quantity of parts and hardware for each section. However, occasional mistakes happen. In the event that you find a
parts shortage or are in need of technical assistance, please contact your local Compass Model parts dealer.
This model is packed according to assembling steps. Do not open all the bags at one time.
Step 1
Tail Set
Step 7
Mishandling due to failure to follow these instructions may result in damage, personal injury or danger.
Use Blue Threadlock
Use Grease
Use AB Glue
Use Bearing Retainer
* Always apply blue Threadlock when fixing Bolts on Metal parts.
* Always apply green retainer where bearings has to be fit into metal parts.
* Do not over-tighten self tapping screws into plastic parts or you will strip the threads!

Pre-assembly Information

In the Box
Open only one bag for each step of assemply when building.
Step 2
Step 4
Step 9
Symbols & Assembling
Step 3
Step 5
Frame set
Long items
Rotor Head
Step 12
