Compass 3D Plus Nitro Powered Helicopter Assembly Manual page 13

10
Setup
Pitch
General Flight
Throttle
5 100%
4 85%
3
70%
2
35%
1
0%
3D Style
Throttle
5 100%
4 75%
50%
3
2 75%
1 100%
Swash Type Setting
JR
Swash Type
S3 120
Aile Elev
50% 50%
A
Make sure that the Flybar Control Arms and Paddles are in line as shown in the diagram.
B
Aileron Servo
Turn on the Transmitter, set the Throttle Stick into center position for 0 ° Pitch. Use the Subtrim menu to
adjust the 3 Swash Servo Arms to reach the angle shown
necessarily parallel but must be the same length
Pitch
13 deg
4~5 deg
-5 deg
Pitch
13 deg
6.5 deg
0 deg
-6.5 deg
-13 deg
Futaba
SWH
SR3
Pitch
50%
Parallel
Swashplate
,
Throttle Curve
100%
80%
60%
40%
20%
0%
1 2
100%
80%
60%
40%
20%
0%
1 2
For any radio setup please refer to your radio
instructions first.
The data's shown above provide some general suggestions
for radio setting. This information varies according to types
of main blades, motor, pinion gear and engine. Adjustment
has to be made during the actual flight.
T Arm
above.The 2 Push pull link rods are not
.
0 0 0 0 10
3 4 5
3 4 5
Swashplate
Elevator Servo
-
30
20 40
I Arm
