Setting the appearance of the Instrument
bar
Data sources connected to the system can be viewed in the
Instrument bar.
You can configure the Instrument bar to display either one or two
bars. If you specify to display two bars you can set it to alternate the
bars automatically. You can specify the information displayed in the
instrument bars.
You can turn the Instrument bar off from the System controls
dialog.
Note:
Ú This only turns the Instrument bar off for the current
page.
Turning the Instrument bar on/off
1. Activate the System controls dialog
2.
Deactivate/activate the instrument bar icon to toggle the bar on
and off.
Select a predefined activity bar
1.
Activate the Instrument bar by selecting it
2. Select the MENU button to open the menu
3. Select Bar 1 or Bar 2 and then a predefined activity bar.
Predefined gauges are displayed in the instrument bar. You can
change a gauge in the activity Instrument bar, refer to Edit the
content of the Instrument bar below.
Edit the content of the Instrument bar
1.
Activate the Instrument bar by selecting it
2. Select the MENU button to open the menu
3. Select Edit to change an instrument gauge followed by the
gauge you want to change
4.
Select the content you want to display from the Choose Data
dialog
5. Select Menu and then Finish editing to save your changes.
