Zooming The Structurescan Image; Using The Cursor On The Structurescan Panel - Simrad GO XSE Operator's Manual

5
Zoom (downscan) / Range (sidescan) icons
6
Range scale

Zooming the StructureScan image

You can zoom a StructureScan image by:
• using the panel zoom icons
• by pinching or spreading on the screen
Using the cursor on the StructureScan
panel
By default, the cursor is not shown on the StructureScan image.
When you position the cursor on a DownScan image, the screen
pauses, the cursor information window and the history bar are
activated. On a DownScan image, the depth is shown at cursor
position.
When you position the cursor on a SideScan image, the screen
pauses, and the cursor information window is activated. On a
SideScan image, the left/right distance from the vessel to the cursor
are shown at the cursor position.
GoTo cursor
You can navigate to a selected position on the image by positioning
the cursor on the panel, then using the Goto Cursor option in the
menu.
The Cursor assist function
The cursor assist function allows for fine tuning and precision
placement of the cursor without covering details with your finger.
Press and hold your finger on the screen to switch the cursor
symbol to a selection circle, appearing above your finger.
Without removing your finger from the screen, drag the selection
circle over the desired item to display item information.
When you remove your finger from the screen the cursor reverts to
normal cursor operation.
StructureScan | GO XSE Operator Manual
103
