PC Control Command Reference

Command Codes
1. Power ON
[function] Switching ON the projector power
[Command] C0 00
[ACK] C0 00
2. Power OFF
[function] Switching OFF the projector power
[Command] C0 00
[ACK] C0 00
3. Focus
[function] Focus adjustment
[Command] C0 00
[ACK] C0 00
"PARA=01:+, FF:-"
4. Zoom
[function] Zoom adjustment
[Command] C0 00
[ACK] C0 00
"PARA=01:Wide, FF:Tele"
5. Digital Zoom
[function] Digital Magnifying function
[Command] C0 00
[ACK] C0 00
"PARA=01:+, FF:-, 00:Off"
6. Key Cursor
[function] Cursor keys
[Command] C0 00
[ACK] C0 00
"PARA=00:Up, 01:Down, 02:Right,
03:Left"
available at the time of Digital
Zoom only
7. Expand
[function] Digital Enlagement function
[Command] C0 00
[ACK] C0 00
"PARA=00:Off, 01:On"
8. Input Select
[function] Video source selection
[Command] C0 00
[ACK] C0 00
"PARA=00:RGB1, 01:RGB2, 02:VIDEO,
03:S-VIDEO"
9. Brightness
[function] Brightness adjustment
[Command] C0 00
[ACK] C0 00
DATA= -31 - +32 (decimal)
01 00 CKS
01 00 CKS
02 00 CKS
02 00 CKS
03 01 PARA CKS
03 00 CKS
04 01 PARA CKS
04 00 CKS
05 01 PARA CKS
05 00 CKS
06 01 PARA CKS
06 00 CKS
07 01 PARA CKS
07 00 CKS
08 01 PARA CKS
08 00 CKS
09 01 DATA CKS
09 00 CKS
10. Contrast
[function] Contrast adjustment
[Command] C0
[ACK] C0
DATA= -31 - +32 (decimal)
11. Volume
[function] Volume adjustment
[Command] C0
[ACK] C0
DATA= 00 - 63 (decimal)
12. Color
[function] Color adjustment
[Command] C0
[ACK] C0
DATA= -31 - +32 (decimal)
13. Tint
[function] Tint adjustment
[Command] C0
[ACK] C0
DATA= -31 - +32 (decimal)
14. Sharpness
[function] Sharpness adjustment
[Command] C0
[ACK] C0
DATA= -31 - +32 (decimal)
15. Brightness R/G/B
[function] Brightness adjustment for RGB
[Command] C0
[ACK] C0
"RGB=00:R, 01:G, 02:B"
DATA= -31 - +32 (decimal)
16. Contrast R/G/B
[function] Contrast adjustment for RGB
[Command] C0
[ACK] C0
"RGB=00:R, 01:G, 02:B"
DATA= -31 - +32 (decimal)

17. Image Mode

[function] Image mode selection
[Command] C0
[ACK] C0
"PARA=00:Normal, 01:Normal 1,
02:Normal 2,03:Normal 3, 04:Doc Cam"

18. Scan Mode

[function] Scan mode selection
[Command] C0
[ACK] C0
"PARA=00:Auto, 01:Non Interlace,
02:Interlace Video, 03:Interlace
PC"
E-83
00 0A 01 DATA CKS
00 0A 00 CKS
00 0B 01 DATA CKS
00 0B 00 CKS
00 0C 01 DATA CKS
00 0C 00 CKS
00 0D 01 DATA CKS
00 0D 00 CKS
00 0E 01 DATA CKS
00 0E 00 CKS
00 0F 02 RGB DATA CKS
00 0F 00 CKS
00 10 02 RGB DATA CKS
00 10 00 CKS
00 11 01 PARA CKS
00 11 00 CKS
00 12 01 PARA CKS
00 12 00 CKS
