Viewing the Details of the Input Signal (Display Menu)
This function is convenient for checking the condition of the signal that is
currently being input.
Select [Display Menu] from the main menu and press the ENTER button.
The display will change to the Display menu.
Press the remote control /
ENTER button.
The details of the input signal will be displayed.
To turn off the display, press the MENU button. The display will return to the
previous menu.
Press the MENU button from the main display to turn off the display.
Memory number .... This is the list number or channel number of the user
registration, channel registration, the standard
memory, and the default are:
S : Standard memory, U : Default area, U : User
memory, C : Channel memory
Horizontal
frequency .............. This is the horizontal scanning frequency.
Vertical
frequency .............. This is the vertical scanning frequency.
Pixel Clock ............ This is the clock frequency.
Sync Polarity ......... This is the polarity of the horizontal sync signal and the
vertical sync signal.
Default Area .......... This is the location number where the default data is
stored.
Resolution ............. This is the horizontal and vertical resolution for the
currently displayed signal.
Scan Mode ........... This is the currently selected scan mode.
button to select [Input Signal], then press the
Main Menu
Alignment
Memory
Switcher
Display Menu
Settings Menu
Source
Display
Lamp Usage
Input Signal
Input Signal

Memory No.

Frequency fH
Frequency fV

Pixel Clock

30.0MHz

Sync Polarity

Default Area

Resolution
640 480
Scan Mode
terlace
E-69
U--00
37.5kHz
75Hz
HD(-) VD(-)
06
Non In-
