PC Control Command Reference

Command Codes
No. Function
01 Video
02 RGB1
03 RGB2
04 S-VIDEO
05 PC CARD
06 Power On
07 Power Off
08 Picture Mute
09 Onscreen Mute
10 Power Zoom W
11 Power Zoom T
12 Power Focus +
13 Power Focus –
14 Reset
15 Freeze
16 Slide +
17 Slide -
18 Front Floor
19 Front Ceiling
20 Rear Floor
21 Rear Ceiling
22 Auto Start On
23 Auto Start Off
24 Image mode Select
25 Power Management On 15H
26 Power Management Off 16H
Code Data Description
03H No Same as remote
04H No Same as remote
05H No Same as remote
C6H No Same as remote
27H No Same as remote (available only when the Viewer board is installed)
08H No Same as remote (See NOTE on page 104.)
14H No Same as remote
47H No Same as remote
11H No
09H No Same as remote
0AH No Same as remote
0BH No Same as remote
0CH No Same as remote
43H No (Resets immediately after returning ACK)
4CH No Same as remote
4BH No Same as remote (available only whenPC CARD is selected)
20H No Same as remote (available only whenPC CARD is selected)
33H No
34H No
35H No
36H No
19H No
1AH No
1EH Yes 0 to 2 at Video, 3 to 5 at the others
No
No
