• Detailed list of memory
This function displays detailed information about the registered
memory.
1. Call up the memory display.
Select [Memory] [User Memory] or [Channel Memory]
from the main menu.
2. Select the memory number you wish to view.
Press the remote control
number or channel number.
3. Display the contents of the memory.
Press and hold the remote control CTL button, then press the
DISPLAY button.
To turn off the diplay, press the MENU button.
Memory No. .......... U-02
Frequency ............. fH 80.3 kHz
Frequency ............. fV 75 Hz
Pixel Clock ............ 135.6 MHz
Sync Polarity ......... HD (+) VD (-)
Default Area .......... 02
Scan Mode ........... Non Interlace ..... Currently
Interpolation .......... PC Mode ........... Currently
Sync Termination Hi-Z ...................... Currently
Image Mode .......... Normal .............. Currently
Image Filter ........... Off ..................... Currently
/
button and select the list
se-
lected Scan mode
se-
lected Interpola-
tion mode
se-
lected Sync termi-
nation mode
se-
lected
mode
se-
lected Image filter
mode
CONTROLLING THE SWITCHER
(Switcher)
Before Using the Switcher Control Functions...
Connecting a switcher (ISS-6020) to the projector permits a
number of external pieces of equipment to be connected. (A
maximum of 100 channels can be controlled with the projec-
tor.)
To integrate and manage the picture adjustments of these
pieces of equipment, the adjustment values are registered to
channel memory and any piece of equipment can be repro-
duced with the same picture conditions.
To use the switcher functions, connect the projector with the
switcher and also connect a control cable between the RE-
MOTE 1 connectors of the units. See "Selecting the Switcher
Control Method [Switcher Control]" on page E-38.
The switcher is a unit that switches the input equipment
when a number of different video devices or computers are
connected.
When the REMOTE 1 connector is used, input selection and
adjustment are permitted by the projector. See "Connections
with ISS-6020" on Page E-28.
After the connections have been made, perform the [Switcher
Control] in conjunction with the switcher and the system.
See "Selecting the Switcher Control Method" on Page E-38.
These steps now permit switcher input selection, picture
adjustment, and volume adjustment from the projector.
Make adjustments with the signals being input from the
external equipment that is connected to the switcher.
When there is no signal, adjustment and setting of [Volume]
and [Audio Select] are permitted.
E-70
