Page 1 Mobile Digital Video Recorder User’s Manual V1.0.0...
Page 2: Cybersecurity Recommendations
Cybersecurity Recommendations Mandatory actions to be taken towards cybersecurity 1. Change Passwords and Use Strong Passwords: The number one reason systems get “hacked” is due to having weak or default passwords. It is recommended to change default passwords immediately and choose a strong password whenever possible.
Page 3 8. Use a Different Username and Password for SmartPSS: In the event that your social media, bank, email, etc. account is compromised, you would not want someone collecting those passwords and trying them out on your video surveillance system. Using a different username and password for your security system will make it more difficult for someone to guess their way into your system.
Page 4: Regulatory Information
Regulatory Information The regulatory information herein might vary according to the model you purchased. Some information is only applicable for the country or region where the product is sold. FCC Information CAUTION Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
Page 5: Foreword
This user’s manual (hereinafter referred to be "the Manual") introduces the appearance, installation, application and interface operations of Mobile Video Recorder (hereinafter referred to be "the Device"). Models MCVR6204, MCVR6208, MXVR6212 Safety Instructions The following categorized signal words with defined meaning might appear in the Manual. Signal Words...
Page 6 About the Manual  The Manual is for reference only. If there is inconsistency between the Manual and the actual product, the actual product shall prevail.  We are not liable for any loss caused by the operations that do not comply with the Manual. ...
Page 7: Important Safeguards And Warnings
Important Safeguards and Warnings This Chapter describes the contents covering proper handling of the Device, hazard prevention, and prevention of property damage. Read these contents carefully before using the Device, comply with them when using, and keep it well for future reference. Operating Requirements ...
Page 8  Prevent short circuit from occurring on all external wiring parts.  After all the lines connections are completed, you can start connecting power cable.  Ensure the project is well grounded to avoid interference to video and audio signals and avoid electrostatic or induced voltage to damage the Device.
Page 9: Table Of Contents
Table of Contents Cybersecurity Recommendations ......................I Regulatory Information ........................... III Foreword ..............................IV Important Safeguards and Warnings ....................VI 1 Overview ..............................1 General............................1 Function ............................1 2 Installation .............................. 4 Unpacking the Box ........................4 The Grand Tour ..........................4 2.2.1 Front Panel .........................
Page 10 4.3.3 Configuring Vehicle Settings ..................... 80 4.3.4 Configuring Alarm Events Settings ................... 91 4.3.5 Configuring RS-232 Port Parameters ................100 4.3.6 User Management ......................102 4.3.7 HDD Management ......................111 System Maintenance .........................113 4.4.1 Requirement for Maintenance ..................113 4.4.2 Viewing System information ....................113 4.4.3 Automatic Maintenance ....................117 4.4.4 Backup and Restore ......................119 4.4.5 Upgrading System ......................
Page 11 Appendix 2 HDD Capacity Calculation....................228 Table of Contents X...
Page 12: Overview
Overview This chapter introduces the features, application scenarios, and functions of the Device. General This series of Mobile Network Video Recorder applies to high-end high definition digital video surveillance management.  The Device integrates image processing, wireless network, GPS, and vehicle information collection and processing technologies.
Page 13 Function Description Stores the data in the dedicated format which cannot be falsified and Storage ensure the data security. Supports multi-channel audio and video signals, and each channel signal Compression supports real-time compression by independent hardware to realize the sync between sound and image. ...
Page 14 Function Description To cope with the low-bandwidth and instability of wireless network, the Device adopts the dual stream technology (respectively encode the Dual stream real-time video and encode video in network transmission) to optimize the coding of network transmission, which improves the control capability of wireless network transmission.
Page 15: Installation
Installation When you receive the Device, unpack the box to check the Device appearance and structures, and then install SIM card and HDD according to your network situation and storage requirement. If you need to use the audio, video, and alarm functions, get knowledge about the connections of audio and video input and output, and alarm input and output.
Page 16 Name Description RJ-45 network Network port. port Two USB ports that connect to peripheral devices such as USB USB port storage device and mouse.  When pulling out HDD, the Device must be unlocked, and if Lock switch the Device is turned on, it will shut down automatically. (Device switch) ...
Page 17: Rear Panel
2.2.2 Rear Panel Figure 2-2 Rear panel Table 2-2 Rear panel introduction Name Function Outputs analog video data to the connected display with VGA VGA port port. For details, see "VGA Port" introduction. Connects to the display with audio function on the vehicle, and AV OUT port simultaneously outputs video and audio data to the display.
Page 18 Name Function CH5-8 Connects to 6V DC–36V DC power source on the vehicle. The red with fuse represents the positive pole of power supply Power cable (normal fire), the black represents grounding line, and the orange represents ACC signal (key fire). VGA port Figure 2-3 VGA port...
Page 19 Remote signal light that receives infrared signal from remote control. +12V/1A output. Ground AV video output RS-232 port sender and receiver that connects to RS-232 port. Voice talk port Figure 2-6 Voice talk port Name Function +12V output Ground Mic In that can connect to microphone. Mic Out that can connect to earphone.
Page 20: Installing Sim Card And Sd Card
Installing SIM Card and SD Card You can install a SIM card for network access and install a SD card for record data storage. The SIM card and SD card are not provided with the Device by default. Please purchase separately if necessary.
Page 21 Figure 2-9 Viewing HDD Information Step 2 Remove the HDD box cover: Remove the screws, the rear panel, and then the enclosure. Figure 2-10 HDD box rear panel removing Figure 2-11 HDD box rear panel enclosure Step 3 Remove HDD brackets. Installation 10...
Page 22 Figure 2-12 HDD brackets removing Step 4 Fix the HDD to brackets with eight screws, and then fix the brackets to holding bracket with two screws. See Figure 2-13. Figure 2-13 HDD box installation (1) Step 5 Install HDD box enclosure in place along the rails, and then fix the HDD box rear panel with two screws.
Page 23: Audio And Video Input And Output Connection
Figure 2-14 HDD box installation (2) Audio and Video Input and Output Connection This section helps you understand the connection of audio and video input and output when you need to use this function. 2.5.1 About Audio and Video Input The Devices adopts standard RJ-45 port to input the audio and video data.
Page 24: Audio And Video Output Port
Figure 2-17 Rubber gasket installation Step 4 Plug the Ethernet plug into the Ethernet port, and then fasten the waterproof connector overall. See Figure 2-18. Figure 2-18 Waterproof connector fastening See Figure 2-19 for the connected waterproof connenctor. Figure 2-19 Connection completed 2.5.2 Audio and Video Output Port The four-cored aviation port (Figure 2-20) can output the video and audio data.
Page 25: Alarm Input And Output Connection
Video output , 75Ω) port and VGA port, and The Device is provided with one CVBS (PAL/NTSC 1.0V supports the simultaneous output from these two ports. Read the following contents carefully before using the computer instead of monitor.  For VGA output, you need to prepare a VGA adapter cable to connect to computer. To extend the Device life, do not keep the Device running for a long time.
Page 26: Alarm Port Introduction
Alarm Input Type Both NO and NC are supported. 2.6.1 Alarm Port Introduction Figure 2-21 Alarm input/output port Name Function Alarm input 1–9. 1–7 represent local alarm input; 8 and 9 represent 1–9 pulse input. Alarm output port that outputs alarm signal to alarm device. C, NO NO: Alarm output port of Normally Open type.
Page 27: Alarm Output Port
Figure 2-22 NC alarm input 2.6.3 Alarm Output Port The alarm output is on-off output (Normally Open Contact), and there should be additional  power supply to external alarm device. RS-485 A line and B line are used for connecting the A line and B line on the PTZ decoder. ...
Page 28 Vibrate 10Hz～55 Hz 3.3mm double-amplitude Humidity 98% RH, 40℃ Temperature range -30℃–70℃ Weight About 2.2g Leading-out end mode Packaging method Plastic Coil Rated coil power Standard: 200mW; Sensitive:150mW parameter Installation 17...
Page 29: Turning On/Off The Device
Turning On/Off the Device Turning On the Device Rotate the Device key to and rotate the vehicle key to ACC position. The power indicator is on, and the Device is ready for work. Booting up takes time. After the Device is booted up, the live view screen is displayed. For the first boot up or after restored to the factory default, the initialization interface is displayed on the screen.
Page 30: Local Configurations
Local Configurations This chapter introduces the local configurations such as initialization, operations, settings, and maintenance. Initial Settings 4.1.1 Initializing Device When booting up for the first time or after restoring to factory default, you need to initialize the Device. The Device can be configured and operated only after initialization. ...
Page 31 Figure 4-2 Unlock Pattern Step 3 Draw an unlock pattern. If you do not want to configure the unlock pattern, click Skip. The password protection setting interface is displayed. See Figure 4-3. Figure 4-3 Password protection Step 4 Configure the protection parameters for password. If you do not want to configure the settings, clear both the Email Address check box and the Security Question check box.
Page 32: Logging The Device
4.1.2 Logging the Device You can login the web to perform local configurations. Step 1 Right-click on the live view screen, the shortcut menu is displayed. Then select Main Menu. The SYSTEM LOGIN interface is displayed. See Figure 4-4. Figure 4-4 System login ...
Page 33: Configure Ip Address And Port
Figure 4-5 Main menu 4.1.3 Configure IP Address and Port Connect the Device to the network and make sure the Device can communicate with other devices in the network diagram. Preparation Make sure the Device is connected to the network properly. Procedure Step 1 Select Main Menu >...
Page 34 Figure 4-6 Network configuration Step 2 Configure the settings for the network parameters. For details, see Table 4-1. Table 4-1 Network Settings Parameter Description In the IP Version list, you can select IPv4 or IPv6. Both versions are supported for access.
Page 35 Parameter Description Hyper Text Transfer Protocol over Secure Socket Layer port. Select the Enable HTTPS check box, and then enter the value according to your actual situation. The default Port setting is 443. Real Time Streaming Protocol port. The default setting is 554. If the default ...
Page 36: Configuring General Settings
Figure 4-7 Network service settings Select the check box of the service options on this interface to enable the corresponding function. If the service is not configured, double-click on the service option, the corresponding setting interface is displayed. For details, see "4.3.2 Configuring Network Service Settings."...
Page 37 Figure 4-8 General system settings Step 2 Configure the general setting parameters. For details, see Table 4-2. Table 4-2 General settings description Parameter Description System Configure the current system time. Time Date Format Select a date format for the system. Date Select a separator for the data format.
Page 38: Configuring Remote Devices
Parameter Description Language Select a language for the Device system. Configure the settings for the situation when the HDD is full. Stop Record: When the HDD is full and there is no extra free disk, the  HDD Full recording stops. Overwrite: When the HDD is full and there is no extra free disk, the new ...
Page 39 Figure 4-9 Remote device Step 2 Click IP Search. The searched devices are displayed. Step 3 Select the Uninitialized check box. The uninitialized devices are displayed. Step 4 Select the check box the uninitialized device, and then click Initialize. The password setting interface is displayed. See Figure 4-10. Figure 4-10 Password setting Step 5...
Page 40 The password setting interface is displayed. See Figure 4-11. Figure 4-11 New password setting In the New Password box, enter the new password and enter it again in the Confirm Password box. Click Next. The security setting interface is displayed. See Figure 4-12. Figure 4-12 Security setting In the Email Address box, enter the email address.
Page 41 Figure 4-13 Initialization completed Step 7 Click Save. 4.1.5.2 Adding a Remote Device You can add a remote device manually or by search. Step 1 Select Main Menu > REMOTE. The REMOTE interface is displayed. You can also access the REMOTE interface by either of the following ways: On the live view screen, drag the pointer to the middle of any one channel ...
Page 42 Figure 4-14 Manual add Configure the parameters. For details, see Table 4-3. The parameters might be different depending on the model you purchased. Table 4-3 Manual add parameters description Parameter Description Channel In the Channel list, select a channel number for the remote device. In the Manufacturer list, select a manufacturer according to the actual Manufacturer situation.
Page 43: Configuring Channel Type
Step 1 Select Main Menu > REMOTE. The REMOTE interface is displayed. Step 2 In the added device area, click next to a remote device. The Edit interface is displayed. See Figure 4-15. Figure 4-15 Edit Step 3 Enter the user name and password of remote device. The system automatically obtains the user name, which is admin by default.
Page 44: Configuring Record Settings
Figure 4-16 Channel type Step 2 Configure the channel type. In the channel type list, you can select Auto, CVI, AHD, TVI, or CVBS according to the connected camera type. Step 3 Click Save. 4.1.7 Configuring Record Settings The record mode is consisted of manual mode and auto mode. You can also enable or disable snapshot function.
Page 45: Configuring Recording Schedule
Figure 4-17 Record control Step 2 Configure the parameters. For details, see Table 4-4. Table 4-4 Record control parameters description Parameter Description Displays the channel number. The channel 9 to channel 12 is Channel displayed only when the cameras are connected. You can select one or several channels or select All.
Page 46 The auto recording is enabled. For details, see "4.1.7 Configuring Record Settings." Procedure Step 1 Select Main Menu > SETTING > SCHEDULE. The SCHEDULE interface is displayed, see Figure 4-18. Figure 4-18 Recording schedule Step 2 Configure the parameters. For details, see Table 4-5. Table 4-5 Record schedule parameters description Parameter Description...
Page 47: Function Modules Operations
Parameter Description This function can help better secure your data safety. To use this function, make sure there are several HDDs are connected to the Device with at least one HDD is set to be redundancy HDD. Select the Redundancy check box, and then you can back up the recorded files to different HDD simultaneously.
Page 48 Figure 4-19 Preview For the icons in information bar, see Table 4-6. Table 4-6 Information Bar Icons Description Displays the license plate number of vehicle where the Device is located. For details about setting the plate number of vehicle, see "4.1.4 Configuring General Settings."...
Page 49 Icons Description  Indicates positioning module connection failed. Indicates positioning module connection succeeded.  Displays the DSS registration status of the Device. For details about DSS registration, see "4.3.3.3 Configuring Auto Register Settings." Indicates DSS registration failed.   Indicates DSS registration succeeded. 4.2.1.1 Preview You can view the information such as time, channel name, GPS, and recording and alarm status in the channel view.
Page 50 The parameters might be different depending on the model you purchased. Figure 4-21 Shortcut menu  View layout: Configure the live view screen to a single-channel layout, 4-channel layout, 8-channel layout, 9-channel layout, or 16-channel layout. Different model supports different view layout mode.
Page 51 4.2.1.4.1 Configuring Display Effect You can configure the display effect such as adjusting image transparency, displaying channel title, overlay of channel title and GPS title, tour type of motion detection and alarm, split mode, video mirror, live view, and voice talk volume. Step 1 Select Main Menu >...
Page 52 Parameter Description Image Select the Image Enhance check box to optimize the image edge effect. Enhance Configure the tour setting of channels. For details, see "4.2.1.4.2 Tour Configuring Tour Settings." Motion Tour Configure the view layout for motion tour type and alarm tour type. The Type motion tour type and alarm tour type only support View 1 and View 8.
Page 53 Figure 4-23 Tour Step 3 Select the Enable Tour check box. Step 4 Configure the parameters. For details, see Table 4-9. Table 4-9 Tour settings parameters description Parameter Description Configure the time for the channel groups display in turn. The default is 5 Interval seconds.
Page 54 Step 1 Select Main Menu > SETTING > DISPLAY. The DISPLAY interface is displayed. Step 2 Click Setup next to Zero-Ch Encode. The Zero-Ch Encode interface is displayed. See Figure 4-24. Figure 4-24 Zero-Channel Encode Step 3 Select the Enable check box. Step 4 Configure the parameters.
Page 55: Ptz Control Panel
Select the Monitor check box for Time Display, License No., and Speed. Click Setup. Drag the title to a proper position, and then right-click on the screen to return to Overlay interface. Click Save. The configured titles are displayed in the windows of live view screen. Step 6 Click Save.
Page 56 Parameter Description Channel Select a channel that is connected to PTZ camera. Protocol Select the protocol that matches the PTZ camera. Enter the address for PTZ camera. Address The entered address must be the same with the address configured on the PTZ camera;...
Page 57 Figure 4-28 PTZ control panel The functions with buttons in gray are not supported by the system. Table 4-12 PTZ control panel buttons and parameters description Parameter Description Controls the movement speed. The bigger the value is, the faster the Speed movement will be.
Page 58 4.2.2.3.1 Configuring Presets You can quickly move the PTZ camera to the configured presets after configuration. Step 1 On the PTZ control panel, click Set. The PTZ function settings interface is displayed. Step 2 Click the Preset tab. The Preset interface is displayed. See Figure 4-30. Figure 4-30 Preset Step 3...
Page 59 Click Del Preset to delete the preset in tours. This operation can be repeated to  delete more presets. Some protocols do not support deleting. Click Del Tour to delete the tour.  4.2.2.3.3 Configuring Patterns The PTZ camera repeats movement according to the configured operations. The operation records include the information such as the manual operations and focus adjustment.
Page 60 Figure 4-33 Border Step 3 Click Left to complete the left border setting. The PTZ control panel is displayed. Step 4 On the PTZ control panel, use the direction buttons to set the right border. Step 5 On the PTZ control panel, click Set > Border > Right. 4.2.2.4 Calling PTZ Functions On the PTZ control panel, click Pg Switch, the PTZ function calling interface is displayed, see Figure 4-34.
Page 61 Function Operation Calling Click AutoPan, the PTZ camera keeps horizontal rotating by 360° . Click AutoPan Stop to stop rotating. Using Flip Click Flip to turn the image upside down (180° ). function Reset Click Reset to restore the camera to the default position. 4.2.2.5 Auxiliary Functions On the PTZ control panel, click Pg Switch till the auxiliary functions setting interface is displayed.
Page 62 4.2.2.6 Entering PTZ Menu If the remote device supports OSD menu, you can open the OSD menu from the Device to perform the corresponding configurations. This function is supported only on Channel 9 to Channel 12. Step 1 On the PTZ control panel, click Pg Switch till the PTZ menu configuration interface is displayed.
Page 63: Video Search
Figure 4-37 PTZ OSD menu Table 4-16 TCP/IP parameters description Parameter Description Move the pointer to Camera, and then click Enter to enter the sub-menu of Camera. Camera You can configure the camera parameters such as image, exposure, backlight, white balance, day & night, zoom, and focus. Move the pointer to PTZ, and then click Enter to enter the sub-menu of PTZ.
Page 64 Figure 4-38 Video search Table 4-17 Video search parameters description Function Description Display Displays the searched recorded video or picture. It supports playing in window single-channel and 4-channel. Playback Playback control buttons. For details, see "4.2.3.1 Introducing controls bar Playback Controls Bar." Displays the type and time period of the current recorded video.
Page 65 Function Description Click the date that you want to search, the time bar displays the corresponding record. Calendar The dates with record or snapshot are filled with blue color.  The dates with no record or snapshot are empty.  Supports playback in View 1 and View 4.
Page 66 Icons Description Previous Frame/Next Frame.  When the playback is paused, click or click to play back single frame record. When playing back single-frame recorded video, click  start playing forward. Slow Playback. During playing back, click this button to set the speed of slow playback, such as Slow×1/2, Slow×1/4.
Page 67 Step 2 Select the month, year, and channel number that you want to search. For single-channel playback, select Channel 13 to search the recorded videos of multi-window. Step 3 Select date and record type. Figure 4-40 Record type Step 4 Click to start playing back recorded video.
Page 68 Record type: R indicates regular record; A indicates alarm; M indicates motion detection. Step 6 Double-click the recorded video file to start playing back recorded video. Select a recorded video, and then click to lock the video file. The locked video file will not be covered.
Page 69 Figure 4-42 File list Step 5 Set the start time, and then click , the searched snapshots are displayed. Step 6 Double-click the snapshots folder or click The system is playing back snapshots according to the configured interval. 4.2.3.4 Clipping Recorded Video During playback, clip sections of recorded video and save to the external storage such as USB flash disk.
Page 70 Step 4 Click The BACKUP interface is displayed. See Figure 4-44.  Maximum 1024 files can be backed up at one time.  The files that are selected in the File List cannot be clipped. Figure 4-44 Backup Step 5 Select the recorded video files that you want to back up.
Page 71 Figure 4-45 Files backup Step 2 Click Detect. The detected external storage devices are displayed with the corresponding space information and status.  Select the external storage device, and then click Format to clear the data in the external storage device. ...
Page 72: Configuring System Settings
Step 4 Select the external storage device and backup route. Step 5 Configure the record type, channel number, file format, start time and end time, and then click Add. The satisfied recorded video files with a selected mark are displayed. See Figure 4-47. ...
Page 73 4.3.1.1 Configuring Image Color You can adjust the video image color effect such as hue, brightness, contrast, saturation, and gain for different period. Step 1 Right-click on the live view screen, the shortcut menu is displayed. Select Color Setting. The COLOR SETTING interface is displayed. See Figure 4-48. Figure 4-48 Color setting Step 2...
Page 74 4.3.1.2 Configuring Camera Parameters You can configure the camera parameters such as bit rate, overlay, and snapshot. 4.3.1.2.1 Configuring Encode Setting You can configure encode settings for main stream and sub stream. Step 1 Select Main Menu > SETTING > ENCODE. The ENCODE interface is displayed, see Figure 4-49.
Page 75 Parameter Description Select a control mode for bit rate of video. CBR: Constant Bit Rate. It is a fixed value.  VBR: Variable Bit Rate, which changes along with environment.  Bit Rate Type It is recommended to select CBR when there might be only small changes in the monitoring environment, and select VBR when there might be big changes in the monitoring environment.
Page 76 Figure 4-50 Overlay Step 4 Configure the parameters. For details, see Table 4-21. Table 4-21 Overlay settings parameters description Parameter Description After the cover-area is configured, the real-time monitoring cannot be performed to the covered area. When Channel 1 to Channel 8 is selected, both Preview and Monitor check boxes are displayed.
Page 77 4.3.1.2.3 Configuring Snapshot Settings You can configure the snapshot type, size, quantity, and image quality. Step 1 Select Main Menu > SETTING > ENCODE. The ENCODE interface is displayed. Step 2 Click Snapshot. The SNAPSHOT interface is displayed, see Figure 4-51. Figure 4-51 Snapshot settings Step 3...
Page 78 Figure 4-52 Time period Select a channel. In the Period list, select a day, enter the specific time in the period box, and then select the check box. Click OK. Step 5 Click OK. The ENCODE interface is displayed. Step 6 Click OK.
Page 79 Figure 4-53 Device status Table 4-23 Device status parameters description Parameter Description Channel Displays the channel number of remote device. Displays the connection status of remote device. : Online.  Status : Offline.  IP Address Displays the IP address of remote device. Displays the alarm status for motion detect, video loss, tampering, and Motion Detect external alarms.
Page 80: Configuring Network Service Settings
Step 1 Select Main Menu > INFO > REMOTE DEVICE INFO > Connection Log. The Connection Log interface is displayed. See Figure 4-54. Figure 4-54 Connection log Step 2 Select a channel, and then enter the start time and end time. Step 3 Click Search.
Page 81 The NETWORK interface is displayed. Step 2 Click NETWORK SETTING. The NETWORK SETTING interface is displayed. Step 3 Configure DDNS settings. Double-click DDNS. The DDNS interface is displayed. See Figure 4-55. Figure 4-55 DDNS Select the Enable check box. Configure the parameters. For details, see Table 4-24. Table 4-24 DDNS setting parameters description Parameter Description...
Page 82 Step 2 Click NETWORK SETTING. The NETWORK SETTING interface is displayed. Step 3 Configure email settings. Double-click EMAIL. The EMAIL interface is displayed. See Figure 4-56. Figure 4-56 EMAIL settings Configure the parameters. For details, see Table 4-25. Table 4-25 EMAIL settings parameter description Parameter Description Configure the address of Simple Mail Transfer Protocol.
Page 83 Parameter Description Select the Health Enable check box, and then enter the interval. The system can send a test email to check the connection according to the interval. Interval The value ranges from 30 minutes to 1440 minutes. Click Test to test the email sending and receiving function. If the configuration is correct, the receiver’s email account will receive the test Test email.
Page 84 4.3.2.3 Configuring FTP Settings You can store the recorded videos and snapshots on the FTP server. Preparation Make sure you have purchased or download a FTP server and installed it on your PC. For the created FTP user, you need to set the write permission; otherwise the upload of recorded videos and snapshots will be failed.
Page 85 Parameter Description Create folder on FTP server. If you do not enter the name of remote directory, system automatically  Remote creates the folders according to the IP and time. Directory If you enter the name of remote directory, the system creates the folder ...
Page 86 Preparation  The Device is connected into the Internet.  DMSS Client is downloaded and installed on you mobile phone. Procedure Step 1 Select Main Menu > SETTING > NETWORK. The NETWORK interface is displayed. Step 2 Click NETWORK SETTING. The NETWORK SETTING interface is displayed.
Page 87 > Device Manager. The Device Manager interface is displayed. See Figure 4-59. Figure 4-59 Device manager Click , follow the onscreen instructions to initialize device if needed, and then add the device by wired connection or wirelessly by scanning the QR code. Step 3 After the Device is added, click Start Live Preview to see the live view interface of Device.
Page 88 Double-click Switch Settings. The Switch Settings interface is displayed. See Figure 4-60. Figure 4-60 Switch settings Enter the IP address, subnet mask, and gateway. The IP address of Switch cannot be in the same network segment with the IP address of Device. It is recommended to use the default IP address. Click OK.
Page 89 Operation Description Map the The PoE port is correspondence to channel one by one. For example, PoE channel with port 1 corresponds to Channel 1. PoE port When using network cable to connect IP camera to PoE port, if all the channels are occupied, the system prompts up a message requiring for take placing of one channel.
Page 90 Figure 4-62 Test result 4.3.2.6.2 Testing Network Load You can view the network port information such as MAC address, connection status, IP address, and data receiving speed and sending speed. Step 1 Select Main Menu > INFO > NETWORK > NET LOAD. The NET LOAD interface is displayed.
Page 91: Configuring Vehicle Settings
 The green line represents data sending speed, and the red line represents data receiving speed. 4.3.3 Configuring Vehicle Settings You can configure the vehicle settings such as auto register, speed, gyro, and position report. 4.3.3.1 Configuring MAC Acquisition 4.3.3.1.1 Configuring MAC Acquisition Parameters After MAC acquisition function is enabled, the system automatically collects the MAC addresses of nearby devices.
Page 92 Step 2 Enter the start time and end time. Step 3 Click Search. The MAC information satisfying the searching conditions is displayed. See Figure 4-65. Figure 4-65 Mac information 4.3.3.1.3 Backing Up MAC Information Step 1 Select Main Menu > ADVANCED > Mac Info. The Mac Info interface is displayed.
Page 93 If the backup is successful, the system pops up a message indicating the backup is completed. Step 4 Click Save. 4.3.3.2 Configuring 3G/4G Network Settings You can connect the Device to the Internet through 3G/4G network or Wi-Fi. Make sure the Device can communicate with other devices in the network diagram.
Page 94 Figure 4-67 3G/4G Step 2 Select the Enable check box. Step 3 Configure the parameters. For details, see Table 4-29. Table 4-29 3G/4G parameters description Parameter Description When the Device is accessed to private network, select the NetAccess check box, enter APN name and select authentication mode. If PAP or NetAccess CHAP is selected for authentication mode, enter user name and password, and then the Device is automatically accessed to private...
Page 95 Parameter Description 3G wireless After dial-up is succeeded, the 3G module status is displayed here, Network such as SIM status, PPP dial-up status, and IP address. Step 4 Click Apply. 4.3.3.2.2 Configuring Wi-Fi Network You can connect the Device to network through Wi-Fi. This function is supported on the Device with Wi-Fi module.
Page 96 The available Wi-Fi with information such as name, encryption type, and signal strength are displayed. Double-click the Wi-Fi that you want to connect, enter the password, and then click Save.  Manual add Click Static Setting. The Static Setting interface is displayed. See Figure 4-69. Figure 4-69 Static setting Enter SSID and password, select priority level and verification type, set IP address,...
Page 97 Figure 4-70 Ap setting Step 3 Click WIFI AP. The WIFI AP setting interface is displayed. See Figure 4-71. Figure 4-71 WIFI AP Step 4 Enter SSID information, select work band and verification type, and then enter the connection password. ...
Page 98 4.3.3.3 Configuring Auto Register Settings When the Device is connected into Internet, it will report the current location to the specified server which acts as the transit to make it easier for the client software to access the Device. Step 1 Select Main Menu >...
Page 99 Step 4 Click Save. 4.3.3.4 Configuring Speed You can configure the speed parameters such as mileage and speed source of vehicle where the Device is located. Step 1 Select Main Menu > VEHICLE > SPEED. The SPEED interface is displayed, see Figure 4-73. Figure 4-73 Speed Step 2...
Page 100 Parameter Description Pulse 1 Displays the frequency of pulse system from the accessed device. Pulse 2 Step 3 Click OK. 4.3.3.5 Configuring Gyro You can configure the vehicle type and rectify vehicle position, and view the acceleration, gyro, and temperature. Step 1 Select Main Menu >...
Page 101 Figure 4-75 Position report (device auto) Configure the parameters. For details, see Table 4-32. Table 4-32 Device auto report parameters description Parameter Description When the vehicle ACC status is on, the system report the position Report Interval to platform according to the configured report interval, report Report by Distance distance, and inflexion angle.
Page 102: Configuring Alarm Events Settings
Figure 4-76 Position report (platform schedule)  Resume Upload after Offline Only when the platform supports this function and the Device is registered to the platform, the Status shows Activated, and you can use this function.  When the connection between the Device and platform is correct, the Device will upload the position information to the platform according to the report strategy.
Page 103 Figure 4-77 Alarm setting Step 2 Select the event type.  Local Alarm: The alarm signal detected by the alarm input port on the Device.  IPC Disconnect: The alarm signal is generated when the IP camera is disconnected. Step 3 In the Alarm In list, select a channel number, and then select the Enable check box.
Page 104 Parameter Description Connect the alarm device such as light and siren to the alarm output port. Alarm Select the check box of Alarm Out to enable the alarm linkage. When an alarm Output event occurs, the system links the alarm device to activate alarm. Set a length of time for the Device to delay turning off alarm after it is canceled.
Page 105 4.3.4.2 Configuring Video Detection Settings Video detection includes motion detection, video loss, and tampering. This function detects the abnormal changes and trigger alarms. Step 1 Select Main Menu > SETTING > DETECT. The DETECT interface is displayed, see Figure 4-78. Figure 4-78 Video detect Step 2...
Page 106 Figure 4-79 Motion detection area setting Drag on the screen to select the region that you want to detect. You can clear the selected blocks by the same way. By default, the whole region is covered by motion detection range. Right-click on the screen.
Page 107 Parameter Description Select the Send Email check box to enable the system to send an email notification when an alarm event occurs. Send Email To use this function, make sure the email function is enabled. For details, see "4.3.2.2 Configuring EMAIL Settings." Select the Record Channel check box and select a record channel(s), when an alarm event occurs, the corresponding channel starts recording automatically.
Page 108 Figure 4-80 Abnormal event settings Step 2 Select an event type. The supported event type and linkage settings parameters might be different depending on the model you purchased. The actual interface shall prevail. No HDD: When there is no HDD installed with the Device, the system generates ...
Page 109  Illegal Login: When the times of consecutive user name or password input errors exceed the set number, the account is locked and the system generates alarm and link the configured actions. Step 3 Select the Enable check box. Step 4 Configure the parameters.
Page 110 Parameter Description Select the Send Email check box to enable the system to send an email notification when an alarm event occurs. Send Email To use this function, make sure the email function is enabled. For details, see "4.3.2.2 Configuring EMAIL Settings." Select the Buzzer check box to activate a buzzer noise at the Device when Buzzer an alarm event occurs.
Page 111: Configuring Rs-232 Port Parameters
Status: Indicates the status of each alarm output port. Indicates there is alarm output, and indicates there is no alarm output. 4.3.4.5 Configuring Face Detection You can enable the face detection function for Channel 9 to Channel 12. The system automatically detects the faces and takes snapshots for the corresponding channel.
Page 112 Figure 4-83 RS-232 settings Step 2 Configure the parameters. For details, see Table 4-36. Table 4-36 RS-232 port parameters description Parameter Description MainCom: Connects the external device according to your requirement. Index Com1: Connects to touch screen monitor. Select the corresponding protocol. If MainCom is selected, the supported protocol includes Console, Keyboard, Adapter, Net Keyboard, PTZ Matrix, and ITS.
Page 113: User Management
4.3.6 User Management You can add, modify and delete user accounts and groups, and configure security questions for admin account. The Default User and Authority The default user account is admin.  The admin account is defined as high privileged user. To manage the user account easily, when defining the user account authority, it is ...
Page 114 Figure 4-84 Account Step 2 Click Add User. The Add User interface is displayed. See Figure 4-85. Figure 4-85 Add user Step 3 Configure the parameters. For details, see Table 4-37. Table 4-37 Parameters description for adding user Parameter Description Reusable Select the check box, user name can also be used to login the web.
Page 115 Parameter Description Memo Enter a description of the user. User MAC Enter user MAC address that is allowed to login the Device. Group Select a group for the user. Select the authorities to the user of a group.  The authority for admin account cannot be changed. Authority To management account easily, when defining the user account ...
Page 116 4.3.6.3 Adding a Group You can add a group and set the necessary authority. Step 1 Select Main Menu > ADVANCED > ACCOUNT. The ACCOUNT interface is displayed. Step 2 Click Add Group. The Add Group interface is displayed. See Figure 4-87. Figure 4-87 Add group Step 3...
Page 117 Figure 4-88 Modify group Step 3 In the Group list, select a group that you want to modify.  Modifying admin group and user group are not supported.  Click Delete to delete the added user group. Step 4 Click Save. The message pops up.
Page 118  The new password can be set from 8 characters through 32 characters and contains at least two types from number, letter and special characters (excluding ' " ; : &).Please enter a strong password according to the password strength indication.
Page 119 4.3.6.7 Resetting password You can reset the password through reserved email or security questions when you forgot the password for admin account. Step 1 Enter the login interface.  If you configured unlock pattern, the unlock pattern interface is displayed. See Figure 4-91.
Page 120  If the reserved email address was configured before, see Figure 4-93.  If the reserved email address was not configured before, see Figure 4-94. Please set the reserved email address, and then click Next, the QR code interface is displayed, see Figure 4-93.
Page 121  You can get the security code twice by scanning the same QR code. If you need to get the security code once again, please refresh the interface.  The security code is valid for 24 hours.  Security question In the Reset Type list, select Security Question, the security question interface is displayed, see Figure 4-95.
Page 122: Hdd Management
The new password can be set from 8 characters through 32 characters and contains at least two types from number, letter and special characters (excluding ' " ; : &).Please enter a strong password according to the password strength indication. Step 6 Click Save.
Page 123 Figure 4-98 HDD management Step 2 In the HDD No. list, select an HDD that you want to configure.  In the Set To list, select the HDD type, and then click Execute.  Read/Write: Read HDD data and save data to HDD. ...
Page 124: System Maintenance
Figure 4-99 HDD information Table 4-38 HDD information parameters description Parameter Description Displays the connected HDDs. The asterisk (*) means the current working HDD. Type Indicates HDD type. Free Space Indicates the total and free capacity of HDD. Total Space Status Indicates the HDD running status.
Page 125 4.4.2.1 Viewing Version Details You can view the version details such as system version and build date. Select Main Menu > INFO > VERSION. The VERSION interface is displayed. See Figure 4-100. Figure 4-100 Version details 4.4.2.2 Viewing Device Information You can view the device information such as ACC status, voltage, HDD status, GPS positioning status, DSS register status, 3G dial-up status, and Wi-Fi connection status.
Page 126 Figure 4-101 Device information 4.4.2.3 Viewing Satellite Information You can view the information such as GPS module status, positioning status, latitude and longitude, and speed. Select Main Menu > INFO > SATELLITE INFO. The SATELLITE INFO interface is displayed. See Figure 4-102. If the GPS module state indicates Normal and not positioned within five minutes, the GPS ...
Page 127 Figure 4-102 Satellite information 4.4.2.4 Viewing Log Information You can view and back up the log information. Step 1 Select Main Menu > INFO > LOG. The LOG interface is displayed. See Figure 4-103. Figure 4-103 Log information Step 2 In the Type list, select a log type;...
Page 128: Automatic Maintenance
4.4.2.5 Viewing Data Rate Information You can view the real-time data stream rate and diagram of data rate changes. Select Main Menu > INFO > BPS. The BPS interface is displayed. See Figure 4-104. Figure 4-104 Data rate information 4.4.3 Automatic Maintenance You can configure the automatic maintenance settings such as auto reboot, auto deleting old files, auto booting up, auto shutdown, and delay for auto shutdown.
Page 129 Figure 4-105 Automatic maintenance Step 2 Select the auto reboot time. Step 3 Click OK. 4.4.3.2 Auto Deleting Old Files After configuring auto deleting old files, when the Device is working, it deletes the old files that occurred before the set schedule. Step 1 Select Main Menu >...
Page 130: Backup And Restore
off by the configured time. If the system time is before the auto booting up or after the auto shutdown, the Device is turned off immediately.  If the auto booting up is not set, when the ACC is disconnected, the Device shuts down at the scheduled time.
Page 131 Figure 4-106 IMP/EXP Step 2 You can import and export the configuration files if needed.  When exporting the configuring files, select a save path, and then click Export. A file under the name of “Config_time” is created under the save path. When importing the configuration files, select the file that you want to import, and ...
Page 132 Figure 4-107 Log information Step 2 In the Type list, select a log type; in the Start Time box and End Time box, enter the time respectively. Click Search. The search results including log time and events are displayed. Double-click on the log or click Details to view the log details.
Page 133: Upgrading System
Figure 4-108 Default Step 2 Select the functions that you want to restore to default.  Clear Config: Click Clear Config, the system pops up a message indicating that the Device will reboot if you continue the operation. Click OK to start rebooting. After the Device is rebooted, except the IPV4 address information and added user information, all the other configurations will return to the default.
Page 134 Figure 4-109 Version details Step 2 Upgrade system.  Click Start to upgrade firmwares.  Click MCU Update to upgrade MCU. The System Upgrade interface is displayed. See Figure 4-110. Figure 4-110 System upgrade Step 3 Select the upgrade file, and then click Start. If the upgrading is successful, the system pops up a message indicating the upgrading is completed.
Page 135: Backing Up The Network Packet
4.4.6 Backing Up the Network Packet You can back up the network packet to the external storage device. These data can be provided to the developers or engineers to analyze the network usage status. Preparation Make sure the external storage device such as USB flash disk is connected to the Device. Procedure Step 1 Select Main Menu >...
Page 136: Logging Out The System
Step 4 Click to start backing up packet.  The packet of only one network port can be captured each time.  When the backing up is started, you can exit the NET TEST interface to take other operations, such as web login and monitoring. Step 5 Click to stop backing up.
Page 137  Switch User: Log out the current user and the login interface is displayed for the other user to login. Step 3 Click OK. The system responds according to different operation. Local Configurations 126...
Page 138: Web Operations
Web Operations You can access and manage the Device from web interface on PC. The web interface provides the functions such as monitoring channels, searching for recorded files, settings configuring, configuring system, and PTZ control. There are several browsers are supported, including Safari, Firefox, and IE. Initial Settings 5.1.1 Initializing Device When booting up for the first time or after restoring to factory default, you need to initialize the...
Page 139: Logging The Web
Figure 5-2 Password protection Step 3 Select the reset type. It is recommended to enable the two types. Select the Email Address check box, and then enter the email address in the box.  Select the Security Question check box, select the question and enter the ...
Page 140: Configuring Ip Address
Figure 5-4 Web login interface Step 2 Enter the user name and password, and then click Login. The PREVIEW interface is displayed. See Figure 5-5.  Install the plugin as prompted by the system for initial login.  In the upper left corner, M represents main stream and S represents sub stream. ...
Page 141 Procedure Step 1 Select SETUP > NETWORK > TCP/IP. The TCP/IP interface is displayed. See Figure 5-6. Figure 5-6 TCP/IP Step 2 Configure the parameters. For details, see Table 5-1. Table 5-1 TCP/IP parameters description Parameter Description Select IPv4 or IPv6. Both versions are supported. IP Version For IPv6 version, in the IP address box, the Gateway box, the Preferred DNS box, and the Alternate DNS box, enter 128 bits and cannot be blank.
Page 142: Configuring General Settings
5.1.4 Configuring General Settings You can configure the device basic settings time and date settings. 5.1.4.1 General Settings Step 1 Select SETUP > SYSTEM > GENERAL > General. The General setting interface is displayed. See Figure 5-7. Figure 5-7 General Step 2 Configure the parameters.
Page 143 Parameter Description IPC Time You can select the IPC Time Sync check box and enter the interval for IPC Sync sync with the Device. Step 3 Click Save. 5.1.4.2 Date and Time Settings You can configure settings such as date format, time format, and timing mode. Step 1 Select SETUP >...
Page 144: Configuring Remote Devices
Parameter Description Server In the Timing Mode list, if NTP is selected, configure this parameter. After configuring NTP server, the Device syncs time with NTP server. Synchronize In the Timing Mode list, select NTP to enable the NTP timing Port function.
Page 145 Figure 5-9 Remote device Step 2 Click Device Search. The searched devices are displayed. Step 3 Select the Uninitialized check box. The uninitialized devices are displayed. Step 4 Select the check box the uninitialized device, and then click Initialize. The password setting interface is displayed. See Figure 5-10. Figure 5-10 Password setting Step 5...
Page 146 Figure 5-11 New password setting In the New Password box, enter the new password and enter it again in the Confirm Password box. Click Next. The password setting interface is displayed. See Figure 5-12. Figure 5-12 Password protection Enter the email address if needed. Step 6 Click Next.
Page 147 Figure 5-13 Initialization completed Step 7 Click Save. 5.1.5.2 Adding a Remote Device You can add a remote device manually or by search. Step 1 Select SETUP > CAMERA > REMOTE. The REMOTE interface is displayed. Step 2 Add a remote device. By search ...
Page 148 Figure 5-14 Manual add Configure the parameters. For details, see Table 5-4. The parameters might be different depending on the model you purchased. Table 5-4 Manual add parameters description Parameter Description Manufacturer Select a manufacturer according to the actual situation. IP Address Enter the IP address of remote device.
Page 149: Configuring Detect Type
 To delete an added device, select it, and then click Delete; to modify information, click or double-click an added device; to go to the web interface of remote device, click 5.1.5.3 Modify IP Address of Remote Device You can modify the IP address of remote device according to your network plan. Step 1 Select SETUP >...
Page 150: Configuring Record Settings
Figure 5-16 Detect type Step 2 Configure the channel type. In the channel type list, you can select Auto, CVI, AHD, TVI, or CVBS according to the connected camera type. Step 3 Click Save. 5.1.7 Configuring Record Settings The record mode is consisted of manual mode and auto mode. You can also enable or disable snapshot function.
Page 151: Configuring Recording Schedule
Figure 5-17 Record control Step 2 Configure the parameters. For details, see Table 5-5. Table 5-5 Record control parameters description Parameter Description Displays the channel number. The channel 9 to channel 12 is displayed Channel only when the cameras are connected. You can select one or several channels or select All.
Page 152 The auto recording is enabled for the corresponding channel. For details, see "5.1.7 Configuring Record Settings." Procedure Step 1 Select SETUP > STORAGE > SCHEDULE > Record. The Record interface is displayed, see Figure 5-18. Figure 5-18 Record schedule Step 2 Configure the parameters.
Page 153 Parameter Description This function can help better secure your data safety. To use this function, make sure there are several HDDs are connected to the Device with at least one HDD is set to be redundancy HDD. Select the Redundancy check box, you can back up the recorded files to different HDD simultaneously.
Page 154: Configuring Snapshot Schedule
5.1.9 Configuring Snapshot Schedule You can configure the storage schedule for taking the snapshot. Preparation The Snapshot is enabled for the corresponding channel. For details, see "5.1.7 Configuring Record Settings." Procedure Step 1 Select SETUP > STORAGE > SCHEDULE > Snapshot. The Snapshot interface is displayed, see Figure 5-20.
Page 155: Function Modules Operations
Click Save. Snapshot schedule appears on the Snapshot interface to view the configured snapshot schedule directly. Step 3 Click Save. Function Modules Operations 5.2.1 Preview After logging the web interface, the PREVIEW interface is displayed. See Figure 5-22. Figure 5-22 Preview Table 5-7 Preview interface parameters description Name...
Page 156 Name Description Configure the image quality, playback fluency, full screen,  vertical sync, and window split mode. For real-time monitoring, you can select the fluency or real-time  Screen layout to be the priority according to your actual requirement.  Select the window split mode for the screen layout.
Page 157 Figure 5-24 Video monitoring screen Table 5-8 Video monitoring window parameters description Parameter Description 1–4 Displays the IP address, channel number, bit rate, and stream Device information type (M represents main stream, S represents sub stream). Click this icon and then hold down the left mouse button to select the area you want to enlarge.
Page 158 5.2.1.3 Voice Talk You can do the voice talk between the Device and Client such as web and DSS. Figure 5-26 Voice Talk Click Start Talk to enable the voice talk between the Device and Client.  In the Start Talk list, select a voice talk mode: DEFAULT, G711a, PCM, G711u, and AMR. ...
Page 159 Step 1 Select SETUP > SYSTEM > PTZ. The PTZ interface is displayed. Step 2 Select a channel. Step 3 In the PTZ Type list, select PTZ type, and then configure other parameters.  If Channel 1 to Channel 8 is selected, the PTZ type is Local by default which cannot be modified.
Page 160 5.2.1.4.2 Introducing PTZ Settings You can configure scan, preset, tour, pattern, and auxiliary functions. For details, see Figure 5-30 and Table 5-10. Figure 5-30 PTZ setting Table 5-10 PTZ functions settings parameters Parameter Description The camera automatically scans the configured left border and right border after configuration.
Page 161 Parameter Description The PTZ camera repeats movement according to the configured patterns. The operation records include the information such as the manual operations and focus adjustment. In the PTZ Setup list, select Pattern, and then enter the value in the Pattern box.
Page 162 Figure 5-31 PTZ OSD menu Table 5-11 PTZ menu parameters description Parameter Description Up and down buttons: Select the item that is pointed. Left and right buttons: When the item is pointed, perform configurations to the item. Click On to turn on the OSD menu that is displayed on the monitoring window.
Page 163 5.2.1.5 Image and Alarm out Settings For each channel, you can configure the image settings such as adjusting brightness and contrast, and enable or disable the alarm out. 5.2.1.5.1 Configuring Image Settings You can adjust the video image color effect such as brightness, contrast, saturation, and hue by right-clicking on the channel.
Page 164: Playback Interface
Step 3 Click the number to select the alarm signal for the corresponding channel. After the alarm signal is enabled, the icon shows orange like Click to refresh the list. 5.2.1.5.3 Configuring Zero-Channel Settings After the zero-channel function is enabled, the main CVBS output image is compressed to combine multiple channels in the local interface to one channel.
Page 165 Figure 5-35 Playback interface Table 5-14 Playback interface function introduction Function Description Playback control buttons. For details see “5.2.2.1 Playback Playback controls bar controls bar.” Displays the type and time period of the current recorded video. Click a point to start playback from here. ...
Page 166 Function Description You can download recorded video by file type or time, and verify File list the completeness. Clip a section of recorded video and save it. For details, see Video clip "5.2.2.3 Clipping." 5.2.2.1 Playback controls bar Playback control buttons. For details, see Table 5-15. Table 5-15 Playback controls bar introduction Icons Function...
Page 167 Step 3 Click to start playing back recorded video. 5.2.2.2.2 Playing Back Recorded Video by File List Step 1 Select the month and year that you want to search, and then select the screen split layout and enter the corresponding channel number. Step 2 Select a date with recorded video files, click on the window channel to select a playback channel.
Page 168 Step 1 Search the recorded video that you want to clip. Step 2 Select the channel number. Step 3 Clip the recorded video by either of the following ways.  Click , the slider are displayed. Move the slider to the proper location, and then click to clip and save the section between the sliders.
Page 169 The system supports searching the recorded files through the record type (general, motion detect, or alarm), and supports searching the snapshots. Step 3 Select the file that you want to download, and then click Download to Local. The Download to Local interface is displayed. See Figure 5-40. Figure 5-40 Download to local Step 4...
Page 170: Searching For Face Picture
Figure 5-42 Watermark Step 2 Click Local File and select a file that you want to verify. Step 3 Click Verify. The system indicates the verifying progress and result after completed. See Figure 5-43. Figure 5-43 Watermark 5.2.3 Searching for Face Picture You can search for and download the detected face pictures, and play and download the recorded videos corresponding to the pictures.
Page 171 Procedure Step 1 Click the FACESEARCH tab. The FACESEARCH interface is displayed. Step 2 Select a date from calendar or enter the start time and end time, and then click Search. The face pictures are displayed, see Figure 5-44. Click Clear to delete the searched face pictures. Figure 5-44 Face search Step 3...
Page 172: Configuring Alarm Events Settings
Figure 5-45 Setting In the Type list, select Picture or Record, and select the save path. Click Save. The system starts downloading the pictures or recorded videos. During downloading, click Stop to stop the process. 5.2.4 Configuring Alarm Events Settings The parameters might be different depending on the model you purchased, and the actual interface shall prevail.
Page 173: Configuring System Settings
Alarm type Description Preparation The alarm is triggered when The temperature detect function is enabled. Temperature the Device temperature is too For details, see "5.3.3.3 Configuring System Too High high. Event Settings." The low battery detection function is Battery Low The alarm is triggered when enabled.
Page 174: Remote Devices Configurations
5.3.1 Remote Devices Configurations 5.3.1.1 Configuring Image Settings Different camera corresponds to the different image parameters, and the actual product shall prevail. Step 1 Select SETUP > CAMERA > Camera Attribute. The Conditions interface is displayed. See Figure 5-47. Figure 5-47 Image settings Step 2 Select a channel.
Page 175 Parameter Description This function is supported only on Channel 1 or Channel 5. When the image is dark, select the White Level check box, and in the White Level White Level strength list, select the strength level. The image brightness can be adjusted.
Page 176 Parameter Description Enable the smart code function. This function can reduce the video bit Smart Code stream to maximize the storage space. In the Resolution list, select the video resolution. The higher the value is, the Resolution better the image quality will become. Frame Rate Configure the frames per seconds for video.
Page 177 Step 1 Select SETUP > CAMERA > ENCODE > Snapshot. The Snapshot interface is displayed, see Figure 5-49. Figure 5-49 Snapshot settings Step 2 Select a channel. Step 3 Configure the parameters. For details, see Table 5-20. Table 5-20 Snapshot setting parameters description Parameter Description In the Mode list, select Regular or Trigger.
Page 178 Figure 5-50 Overlay settings Step 2 Select a channel. Step 3 Configure the parameters. For details, see Table 5-21. Table 5-21 Overlay settings parameters description Parameter Description Select the Preview check box or the Record check box, the Setup button is displayed. Click Setup, and then hold down the left mouse button to select the area that you want to cover.
Page 179: Network Parameters Configuration
5.3.1.2.4 Configuring Save Path You can configure the storage path of captured snapshots and recorded videos. Step 1 Select SETUP > CAMERA > ENCODE > Path. The Path interface is displayed. See Figure 5-51. Figure 5-51 Storage path Step 2 Click Browse to select the save path for snapshots and records.
Page 180 Step 1 Select SETUP > NETWORK > CONNECTION > Connection Setting. The Connection Setting interface is displayed. See Figure 5-53. Figure 5-53 Connection setting Step 2 Configure the parameters. For details, see Table 5-22. The settings take effect after reboot. Please operate with care. Table 5-22 Connection setting parameters description Parameter Description...
Page 181 Parameter Description Real Time Streaming Protocol port. The default setting is 554. If the  default setting is displayed, you do not need to configure this parameter. If you use Apple browser QuickTime or VLC to play the real-time monitoring screen, the following formats can be used: This function is also supported by Blackberry mobile phone.
Page 182 For the first time to use this function or after changing the Device IP address, you need to create server certificate. Step 1 Select SETUP > NETWORK > CONNECTION > HTTPS. The HTTPS interface is displayed. See Figure 5-54. Figure 5-54 HTTPS Step 2 Click Create Server Certificate.
Page 183 Figure 5-56 Download by file Step 3 Click Open. The Certificate interface is displayed. See Figure 5-57. Figure 5-57 Certificate Step 4 Click Install Certificate. The Certificate Import Wizard interface is displayed. See Figure 5-58. Web Operations 172...
Page 184 Figure 5-58 Certificate import wizard Step 5 Click Next. The certificate store selection interface is displayed. See Figure 5-59. Figure 5-59 Certificate store Step 6 Click Next. The certificate import completing wizard is displayed. See Figure 5-60. Web Operations 173...
Page 185 Figure 5-60 Certificate import wizard completing Step 7 Click Finish. The security warning interface is displayed. Step 8 Click Yes. The system pops up a messaged that indicates the import was successful. Viewing and Setting HTTPS Port After creating server certificate or download root certificate, you need to set the HTTPS port. Step 1 Select SETUP >...
Page 186 “Port” corresponds to your HTTPS port. If the default value is 443, do not enter “: Port”, and  just enter “https://xx.xx.xx.xx” to visit. 5.3.2.2 Configuring MAC Acquisition 5.3.2.2.1 Configuring MAC Acquisition Parameters After MAC acquisition function is enabled, the system automatically collects the MAC addresses of nearby devices.
Page 187 Click Backup and select the save path to export the MAC information to PC.   Click Remove to delete the searched MAC information. 5.3.2.3 Configuring DDNS Settings When the IP address of the Device changes frequently, the DDNS function can dynamically refresh the correspondence between the domain on DNS and the IP address, ensuring you access the Device by using the domain.
Page 188 Parameter Description The domain name for registering on the website of DDNS service provider. Domain Name Click Test to check whether the domain name can be used. Username Enter the user name and password obtained from DDNS service provider. You need to register (including user name and password) on the website Password of DDNS service provider.
Page 189 Parameter Description Port Enter the port value of SMTP server. For details, see Table 5-25. Username Enter the user name and password of SMTP server. For details, see Table Password 5-25. Enter the sender’s email address. Sender In the Encrypt list, select an encryption type from NONE, SSL, and TLS. Encrypt type For details, see Table 5-25.
Page 190 Mailbox Encrypt SMTP server Port Description type type The mailbox must have applied  465/994 SMTP service. The password must be an  “authorized password”. The email login password is invalid. smtp.163.com NONE Obtain the authorized password when your mailbox is applying for SMTP service.
Page 191 Figure 5-66 FTP setting Step 2 Select the Enable check box. Step 3 Configure the parameters. For details, see Table 5-26. Table 5-26 FTP parameter description Parameter Description Server IP IP address of the PC that is installed with FTP server. Port The default value is 21.
Page 192 Parameter Description Interval of uploading snapshots. If this interval is longer than snapshot interval, the system uploads the  most recent snapshot. For example, the interval is 5 seconds, and snapshot interval is 2 seconds per snapshot, then the system uploads the recent snapshot every 5 seconds.
Page 193 Figure 5-67 Step 2 Select the Enable check box. Step 3 Use DMSS Client to scan the QR code under Device SN to add the device to DMSS Client. Please scan the QR code on the actual interface of Device. Step 4 Click Save.
Page 194 Figure 5-68 Device manager Click , follow the onscreen instructions to initialize device if needed, and then add the device by wired connection or wirelessly by scanning the QR code. Step 4 After the Device is added, click Start Live Preview to see the live view interface of Device.
Page 195 The 3G/4G Setup interface is displayed. See Figure 5-69. After 3G/4G module is connected, the module information and wireless signal are displayed; if not, click Search to search for wireless signal. Figure 5-69 3G/4G setting Step 2 In the 3G Network list, select the Ethernet port, and then select the Enable check box. Step 3 Configure the parameters.
Page 196 Parameter Description Flow use policy Select the flow use policy and data flow upper limit for 3G/4G module. Flow threshold(M) Currently used View the currently used flow by 3G/4G module. flow(K) Step 4 Click Save. After access is succeeded, the obtained IP address is displayed. 5.3.2.7.2 Configuring Wi-Fi Network You can connect the Device to network through Wi-Fi.
Page 197 The available Wi-Fi networks list including the information such as connection mode, authorization mode, and signal intensity. Double-click the Wi-Fi that you want to connect, enter the password, and then click Save.  Manual add Click Static Setting. The WIFI setting interface is displayed. See Figure 5-71. Figure 5-71 WIFI setting Enter SSID, select priority level and verification type, set IP address, subnet mask,...
Page 198 Figure 5-72 Step 3 Enter SSID information, select work band and verification type, and then enter the connection password. In the Work Band list, you can select 2.4G or 5G.  Select the Connection Password check box, the clear text password is displayed. ...
Page 199: Alarm Events Configuration
Step 4 Click Save. 5.3.3 Alarm Events Configuration 5.3.3.1 Configuring Video Detection Settings Video detection includes motion detection, video loss, and tampering. This function detects the abnormal changes and trigger alarms. 5.3.3.1.1 Configuring Motion Detect Settings When the moving object appears and moves fast enough to reach the preset sensitivity value, the system activates alarm.
Page 200 Figure 5-75 Motion detection area setup Select the detection area according to the actual situation. Click Save to complete the settings. Step 4 Configure the parameters. For details, see Table 5-29. Table 5-29 Motion detect parameters description Parameter Description Configure the event detection lasting time. The system records only one Anti-dither event during this period.
Page 201 Parameter Description Select the Tour check box and the channels. When an alarm event occurs, a tour of the selected channels is displayed on the Device local interface. To use this function, make sure the tour function is enabled and the ...
Page 202 Figure 5-76 Video Loss Step 2 Select the Enable check box and the channel that you want to apply the video loss detect function. Step 3 Configure the parameters. For details, see Table 5-29. Step 4 Click Save. 5.3.3.1.3 Configuring Tampering Settings When the camera lens is covered, or the video is displayed in a single color because of the causes such as sunlight status, the monitoring cannot be continued normally, and in this case, the system activates alarm and links the configured actions.
Page 203 5.3.3.2 Configuring Alarm Input Settings Step 1 Select SETUP > EVENT > ALARM. The ALARM interface is displayed. See Figure 5-78. Figure 5-78 Alarm setting Step 2 Select alarm input type.  Local Alarm: The alarm signal detected by the alarm input port on the Device. ...
Page 204 Parameter Description Select the Record Channel check box and select a record channel(s), when an alarm event occurs, the corresponding channel starts recording automatically. Record Channel The recording setting for alarm must be configured beforehand. The recording for alarm is enabled. For details, see “5.1.8 ...
Page 205 5.3.3.3 Configuring System Event Settings Step 1 Select SETUP > EVENT > ABNORMAL. The HardDisk interface is displayed. See Figure 5-79. Figure 5-79 Abnormal event settings Step 2 Select the Enable check box. Step 3 Configure the parameters. For details, see Table 5-31. Table 5-31 Abnormal event setting parameters description Parameter Description...
Page 206 Parameter Description If Over Speed is selected, configure this parameter. Max Speed The upper limit of vehicle speed. When the vehicle speed exceeds this value, the system generates alarm. If Low Speed is selected, configure this parameter. Min Speed The lower limit of vehicle speed. When the vehicle speed is lower this value, the system generates alarm.
Page 207 Figure 5-80 Alarm Output Step 2 Select alarm output mode. Manual: After the alarm linkage is configured, no matter whether there is an alarm  event occurs, the corresponding alarm output port keeps generating alarm.  Auto: After the alarm linkage is configured, only when there is an alarm event occurs, the corresponding alarm output port generates alarm.
Page 208: Hdd Management
5.3.4 HDD Management Managing Storage Device and Viewing HDD Information 5.3.4.1 Managing Storage Device Select SETUP > STORAGE > HDD MANAGE, the Storage interface is displayed. See Figure 5-82. Read and Write: Read and store the data on the HDD. ...
Page 209: Configuring System Settings
Figure 5-84 Smart information 5.3.5 Configuring System Settings 5.3.5.1 Configuring Display Effect 5.3.5.1.1 Configuring Basic Display Settings You can configure the preview effect but the settings here will not affect the recording and playback display effect. Step 1 Select SETUP > SYSTEM > DISPLAY > Display. The Display interface is displayed.
Page 210 Parameter Description The higher the percentage, the more transparent the local interface will Transparency become. Select the Channel Display check box, then the channel title is Channel Display displayed in the live view screen. Select the GPS Display check box, the GPS information is displayed in GPS Display the live view screen.
Page 211 Parameter Description Display all channel groups under the current window split mode. Click to add a channel group in the list.  Select the check box of any channel group, and then click  delete the channel group. Channel Group Select the check box of any channel group, and then click ...
Page 212 Parameter Description Bit Rate Select a value for bit rate of video. Window Split Select the window split mode and channel for recoding under the zero-channel function. This setting does not affect the window split mode during multi-channel preview. Step 4 Click Save.
Page 213 5.3.5.1.5 Configuring Video Mirror Settings You can configure the mirror display of image in the vertical or horizontal direction. Step 1 Select SETUP > SYSTEM > DISPLAY > Video Mirror. The Video Mirror interface is displayed, see Figure 5-89. Figure 5-89 Video Mirror Step 2 Select a channel.
Page 214 Parameter Description Select the corresponding protocol. If MainCom is selected, the supported protocol includes Console, Keyboard, Adapter, Net Keyboard, PTZ Matrix, and ITS. If Com1 is selected, only ITS protocol is supported. Console: Upgrades programs and debug by suing the serial interface and ...
Page 215 5.3.5.3.1 User Management You can add, delete, or modify user, and set the authorities for the user of a group. Adding a user Step 1 Select SETUP > SYSTEM > ACCOUNT > User. The User interface is displayed. See Figure 5-91. Figure 5-91 User Step 2...
Page 216 Parameter Description Username Password Enter the user name and password, and conform the password. Confirm Password Reusable Select the check box, user name can also be used to login the web. Memo Enter a description of the user. Group Select a group for the user. User MAC Enter user MAC address that is allowed to login the Device.
Page 217 Step 2 Select the Modify Password check box, and then enter old password, new password, and confirm password in the corresponding box. Step 3 (Optional) Set the reserved email address. The system pops up a message to ask you whether sync to the remote devices that are accessed through the default protocol.
Page 218 Figure 5-95 Add group Step 3 In the Group Name box, enter a name for this group; In the Memo box, enter a description for the group. Step 4 Select the authorities for the user. Step 5 Click Save. Click to modify the corresponding group information;...
Page 219 Figure 5-97 Reset password Step 4 Follow the onscreen instructions to scan the QR code and get the security code.  Please scan the QR code on the actual interface of Device.  You can get the security code twice by scanning the same QR code. If you need to get the security code once again, please refresh the interface.
Page 220: Configuring Vehicle Settings
The system pops up a message to ask you whether you want to sync the password to the remote devices that are accessed through the default protocol. Please select the operation according to your actual situation. 5.3.5.3.4 Viewing Online Users Select INFO >...
Page 221 Parameter Description Mileage In the Mileage Cumulation list, select the vehicle mileage cumulation Cumulation mode. Mileage(KM) Displays the total mileage. Start Mileage In the Start Mileage box, enter the initial mileage of vehicle. In the Speed source list, select where the speed is obtained, including No source, Pulse 1, Position Info, and Pulse 1&Position Info.
Page 222: System Maintenance
Figure 5-102 Position report (device auto) Configure the parameters. For details, see Table 5-40. Table 5-40 Device auto report parameters description Parameter Description When the vehicle ACC status is on, the system report the position Report Interval to platform according to the configured report interval, report Report by Distance distance, and inflexion angle.
Page 223: Viewing System Information
 View the system logs regularly and analyze the data to handle the abnormalities timely.  Back up the system configurations regularly.  Reboot system and delete the old files regularly.  Upgrade firmware timely. 5.4.2 Viewing System Information 5.4.2.1 Viewing Version Details You can view the Device version information.
Page 224 Figure 5-105 Step 2 In the Start Time box and End Time box, enter the time period that you want to search the logs, and then in the Type list, select a log type. Step 3 Click Search. The searched logs are displayed. Select the log that you want to back up, and then click Backup.
Page 225: Automatic Maintenance
Figure 5-106 Satellite information 5.4.3 Automatic Maintenance You can configure the automatic maintenance settings such as auto reboot, auto deleting old files, auto booting up, auto shutdown, and delay for auto shutdown. 5.4.3.1 Auto Reboot After configuring auto reboot, when the Device is working, it reboots according to the schedule. Step 1 Select SETUP >...
Page 226 5.4.3.2 Auto Deleting Old Files After configuring auto deleting old files, when the Device is working, it deletes the old files that occurred before the set schedule. Step 1 Select SETUP > SYSTEM > MAINTAIN. The Auto Maintain interface is displayed. Step 2 In the Auto Delete Old Files area, select Customized, and then enter the days.
Page 227: Backup And Restore
The Auto Maintain interface is displayed. Step 2 Configure the auto delay for shutdown. The value ranges from 0 through 65535. The fault value is 5. Step 3 Click Save. 5.4.4 Backup and Restore You can back up or restore the web configurations and restore to default settings. 5.4.4.1 Backing up Configurations You can back up all the configurations of web.
Page 228: Upgrading System Firmware
The corresponding functions will be restored to the factory default, and your current configurations will be lost. Please operate with caution. Step 1 Select SETUP > SYSTEM > DEFAULT. The Default setting interface is displayed. See Figure 5-110. Figure 5-110 Factory default setting Step 2 Select the check box of the options that you want to restore to the factory default.
Page 229: Capturing Network Packet
Step 3 Click Browse, and select the upgrade file that you want to import. Step 4 Click Upgrade. The system starts upgrading. You should login the web again after upgrading. 5.4.6 Capturing Network Packet The packet data can be provided to the developers or engineers to analyze the network usage status.
Page 230: Logging The Device From Dss
Logging the Device from DSS Beside from web, you can also remotely login the Device from Digital Surveillance System (DSS). For details, see the manual of DSS. Mouse Operations 219...
Page 231: Faq
If your questions cannot be answer by the following contents, please contact your local service engineer or the service of our Headquarters for help. We can guide you to solve this problem. Q: DVR cannot boot up properly. A: There are the following possibilities: a) The electronic lock is unlocked.
Page 232 A: There are the following possibilities: a) NTSC and PAL setting is not correct, and the image becomes black and white. b) Device and monitor resistance is not compatible. Video network transmission distance is too far or transmission line signal attenuation is too much.
Page 233 11) Q: Cannot control PTZ from NVR A: There are the following possibilities: a) PTZ error. b) PTZ decoder setting, connection, or installation is not correct. Device serial port setting is not correct. Set it to be network keyboard. d) Cable connection is not correct. e) PTZ setting is not correct.
Page 234 a) Too much data which occupies CPU resources. Please stop recording first and then begin backup. b) Backup device is not compatible. Backup device is damaged. 16) Q: Alarm function does not work. A: There are the following possibilities: a) Alarm setting is not correct. b) Alarm cable connection is not correct.
Page 235 d) The antenna is not installed or poor contacted. e) Insufficient SIM card balance. SIM card package is not enabled. 21) Q: Cannot connect to DSS platform A: There are the following possibilities: a) 3G/4G dial-up failed. b) The device is not added to the platform. The auto register settings on the Device are not configured.
Page 236: Appendix 1 Mouse Operations
Appendix 1 Mouse Operations The operations are based on the considerations for right-handed users. Beside the operations from the front panel and remote control, you can also use mouse to operate menus. Connect the mouse to the USB port of the Device. Operation Function If the user has not logged in the system, the password box is displayed first.
Page 237 Operation Function In text box, click the corresponding button on the panel to enter a numeral, punctuation, English character (small/capitalized), or Chinese. ← represents backspace, and＿represents space. In English input mode: Click ＿ to enter a space, and click ← to delete the previous character.
Page 238 Operation Function In real-time monitoring screen, right-click on the screen, the shortcut menu is displayed. You can configure the settings including view layout, PTZ control, color setting, record search, record control, alarm out, and main menu. To use PTZ Right-click (click the right control and color setting, click in the channel that mouse button)
Page 239 Appendix 2 HDD Capacity Calculation For the first time to install HDD, make sure whether the HDD is already installed. To install IDE HDD, pay attention to the jumper of the HDD. HDD capacity calculation formula: Total capacity (M) = Channel number × Demand time length (hour) × HDD capacity occupied per hour (M/hour) Recording time calculation formula: HDD total capacity (M)

This manual is also suitable for:

Mcvr6208 Mxvr6212

Dahua MCVR6204 User Manual

Cybersecurity Recommendations

Regulatory Information

Foreword

Important Safeguards and Warnings

1 Overview

2 Installation

3 Turning On/Off the Device

4 Local Configurations

5 Web Operations

6 Logging the Device from DSS

7 Faq

Appendix 1 Mouse Operations

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dahua MCVR6204

Summary of Contents for Dahua MCVR6204

This manual is also suitable for:

Table of Contents
