Customer Operation & Installation Manual
This appliance shall be installed in accordance with:
•
Manufacturers Installation Instructions
•
Local Gas Fitting Regulations
•
Municipal Building Codes
•
A.G.A. Installation code AS 5601 'Gas Installations'
•
Any other local relevant Statutory Regulation
Installation & Service must be performed by an authorised person.
This heater is NOT designed to be built directly into a combustible opening.
For combustible opening installations, a Rinnai zero clearance kit is available
from your gas appliance retailer.
Proudly a member of the A.G.A.
All of our gas products are A.G.A.
tested and approved
INSTALLER: MUST LEAVE THIS MANUAL WITH THE UNIT AFTER INSTALLATION
OWNER: RETAIN THIS MANUAL SAFELY, FOR FUTURE REFERENCE
SLIMFIRE 25
FLAME FIRE
Head Office Certified
Distributed and serviced in Australia under a Quality
System certified as complying with ISO 9002 by
Standards Australia Quality Assurance Service
Advertisement
Table of Contents
Related Manuals for Rinnai SLIMFIRE 25
Summary of Contents for Rinnai SLIMFIRE 25
- Page 1 Installation & Service must be performed by an authorised person. This heater is NOT designed to be built directly into a combustible opening. For combustible opening installations, a Rinnai zero clearance kit is available from your gas appliance retailer. Head Office Certified...
-
Page 2: Limited Warranty
LIMITED WARRANTY As a purchaser of a high quality Rinnai product, we provide you with the following guarantee on your new Flame Fire Heater. Free Labour Period Free Parts Period 1 Year 2 Years FANS 1 Year 10 Years Pro-Rata*... -
Page 3: Table Of Contents
INSTALLERS INFORMATION - WIRING DIAGRAM ................18 TECHNICAL SPECIFICATION ......................19 INSTALLERS INFORMATION - DIMENSIONS ................... 19 INSTALLATION / COMMISSIONING CHECKLIST ................20 INSTALLERS / GAS FITTER DETAILS ....................20 CUSTOMER CONTACTS ........................21 IBF - Slimfire 25 - iii - Issue 5 - ©Rinnai... -
Page 4: Customer Information - Safety Points
DO NOT PLACE ARTICLES ON OR AGAINST THIS APPLIANCE. DO NOT USE OR STORE FLAMMABLE MATERIALS NEAR THIS APPLIANCE. DO NOT SPRAY AEROSOLS IN THE VICINITY OF THIS APPLIANCE WHILST IT IS IN OPERATION. IBF - Slimfire 25 - 1 - Issue 5 - ©Rinnai... -
Page 5: Customer Information - Operation
Burner pattern 1. Ignition / Low 7.7 MJ/h (NAT) 9 MJ/h (Propane) 2. Medium 14.2 MJ/h (NAT) 15.8 MJ/h (Propane Low) 3. High 25 MJ/h (NAT) 25 MJ/h (Propane) High IBF - Slimfire 25 - 2 - Issue 5 - ©Rinnai... -
Page 6: Customer Information - Important Points
12. If the supply cord, gas hose or glass are secondary guard is required. damaged or require replacing, they must be replaced by the manufacturer or the IBF - Slimfire 25 - 3 - Issue 5 - ©Rinnai... -
Page 7: Customer Information - Specifications
Top front louvres Flue: Natural draft rectangular flue Ignition: Electronic spark Power Supply: 240 V 50 Hz Rating Plate location: Bottom panel, front right hand side Weight: 39 Kgs. IBF - Slimfire 25 - 4 - Issue 5 - ©Rinnai... -
Page 8: Customer Information - Trouble Shooting
Call Rinnai Service Department / Agent. • NOTE: If you have any other faults or problems, please refer to your installer or a Rinnai Customer Care Centre Consultant on 1300 366 388. • IMPORTANT: Do not remove any panels or attempt to carry out any service work other than that mentioned in the trouble shooting chart. -
Page 9: Installers Information - Location
8. Before installing the heater, inspect the chimney, flue piping and/or solid fuel burning fire place and remove any combustible materials. IBF - Slimfire 25 - 6 - Issue 5 - ©Rinnai... -
Page 10: Installers Information - Flueing
If the heater is not properly supported noise and vibration may result. 3. Install Flue For installations into a masonry fireplace a Rinnai Flexible Flue system is required. Rinnai rigid flame fire flueing is not suitable. Assemble and connect flue in accordance with the instructions supplied with the flue kit, please refer to the detailed instructions which are included in the Flexliner Flue Kit. - Page 11 Note: Ensure maximum vertical rise before any change of direction and avoid sharp bends as this will restrict the chimneys ability to draw. Fitting of the Appliance Adaptor to the heater IBF - Slimfire 25 - 8 - Issue 5 - ©Rinnai...
-
Page 12: Installation Into A Combustible Opening
Zero clearance box must be used for these installations. Rinnai Flame Fire Rigid Flueing allows the air to be drawn in through the louvres in the plinth panel, pass around the sides and back of the Flame Fire heater and be drawn away through the outer skin of the flue. - Page 13 675mm 370 mm 685mm 3. Install Rinnai Zero Clearance Box (ZEROR) • ‘Zero clearance’ means the panels of metal from the zero clearance box can be in contact with any combustible material. • The hearth surface must be flat and level to support the zero clearance box.
- Page 14 4. Run gas supply. For details please see page 15. 5. Install Rinnai Flame Fire Rigid Flueing as per the instructions supplied with the flue kit, taking careful note of the following: Flue termination above the roof must comply with AS5601.
- Page 15 10.Install top decorative surround to face of fireplace. 11. Log Installation - for Log Installation details, please refer to page 16. 12.Commissioning - for Commissioning details, please refer to page 17. IBF - Slimfire 25 - 12 - Issue 5 - ©Rinnai...
- Page 16 - 1 x Sleeve Clamp Note: Overall flue length approximately 6.3m (plus height of appliance plus 765mm) Maximum wall thickness 270mm (Full installation instructions are supplied with all accessory kits). IBF - Slimfire 25 - 13 - Issue 5 - ©Rinnai...
-
Page 17: Customer Information - Installation Procedures
Make sure that front flanges. the gas flare fitting and gas supply pipe are clean and free of damage and fit together ready for fitting to the heater. (4) IBF - Slimfire 25 - 14 - Issue 5 - ©Rinnai... -
Page 18: Installers Information - Gas Connection
The power cord passes through the slot in the lower left or right hand side of the heater front assembly. Rinnai recommends that the heater be plugged into a 240V,10A earthed power point. The power point must be a POWER CORD... -
Page 19: Installers Information - Log Installation
Avoid pushing the granules under the log or spilling over the front of the burner. Step. 6 Replacing Glass Replace the glass ensuring the joint in the glass sealing tape is at the bottom. IBF - Slimfire 25 - 16 - Issue 5 - ©Rinnai... -
Page 20: Installers Information - Testing & Commissioning
IBF - Slimfire 25 - 17 - Issue 5 - ©Rinnai... -
Page 21: Installers Information - Wiring Diagram
If the supply cord is damaged or requires replacing, it must be replaced by the manufacturer or the manufacturers agent or similarly qualified person in order to avoid a hazard. The supply cord must only be replaced with a genuine Rinnai spare part. IBF - Slimfire 25 - 18 - Issue 5 - ©Rinnai... -
Page 22: Technical Specification
Installation type: Inbuilt only Flue requirement: Can be flued directly into a sealed chimney as per AS 5601 or fitted with a Rinnai approved flue system INSTALLERS INFORMATION - DIMENSIONS IBF - Slimfire 25 - 19 - Issue 5 - ©Rinnai... -
Page 23: Installation / Commissioning Checklist
Model: _______________________________ 1. Was a fireplace inspection carried out? (i.e. clearances, combustibles etc). 2. Was a Rinnai flue system installed in accordance with the instructions? 3. Has specified gas pressures been checked and set? 4. Are decorative logs located correctly? 5. -
Page 24: Customer Contacts
CUSTOMER CONTACTS The Rinnai Flame Fire Heater Family Inbuilt Royale Freestanding Royale Inbuilt Slimfire IB35 / IB35ETR FS35 / FS35ETR IB25 Australia Pty. Ltd. ABN 74 005 138 769 Head Office Internet: www.rinnai.com.au E-mail: enquiry@rinnai.com.au 10-11 Walker Street, Braeside, Victoria 3195 National Help Line P.O.
