Specifications - Nady Systems Encore I User Manual

44
36
37
36
XLR Connector – Connects microphone to the transmitter module for signal input
37 Locking Ring – Locks microphone to the transmitter
Optional Pouch – For lavalier bodypack operation (with beltclip and strap ring for
38
securing)
39 Gain Control Switch – Adjusts the input sensitivity (LO or HI)
40 Low Battery LED – Single flash (power on), lit steady (low battery)
41 Power Switch - Turns the power ON/STANDBY/OFF. In standby position, the power is
on and the audio is off.
42
Phantom Power ON/OFF Switch – Turns the phantom power ON/OFF
Battery Compartment
43
44 Release Button – Press to release XLR connector
9V Alkaline Battery
45
16
38
43
41
39
40
42
ENCORE I OVERALL SYSTEM PERFORMANCE
Frequency Response
Dynamic Range
Total Harmonic Distortion
RF Carrier Frequency Range
Frequency Stability
Modulation
Operating Range
TRANSMITTERS
Audio Inputs
•WHT-15
•WLT-15/WGT-15
45
•LINK 2™
Controls
•WHT-15
•WLT-15/WGT-15
•LINK 2™
LED Indicator
RF Power Out
Harmonic & Spurious Emissions
Battery
Battery Life
Dimensions
•WHT-15
•WLT-15/WGT-15
•LINK 2™
Weight (w/o battery)
•WHT-15
•WLT-15/WGT-15
•LINK 2™

SPECIFICATIONS

25-20,000 Hz, +/-3dB
120dB
< 0.3%
169-216 MHz
+/- 0.005%, crystal controlled
FM (F3E), +/-20KHz max.
Up to 250 ft. typical (depending on site
conditions); up to 500+ feet optimum
line-of-sight
Nady DM-10D neodymium dynamic cartridge
3.5mm mono locking jack for connecting to omni
or unidirectional lavalier mic or unidirectional
head worn mic, with phantom power (WLT-15);
or connecting to instrument cable (WGT-15)
Locking XLR jack for connecting to microphone or
cable, with selectable phantom power
OFF/STANDBY/ON switch
OFF/STANDBY/ON switch, input level adjust
OFF/STANDBY/ON, LO/HI Level, and ON/OFF
Phantom power switch
Unit "ON" (single flash),
Low Battery Alert (steady)
50mW (Max. allowed by FCC)
> –40dB
9V Alkaline
Up to 15 hours
9.5" X 1.4" Diam. (24.1 X 3.5 cm)
4.1" X 2.4"X 0.8" (10.4 X 6.1 X 2.0 cm)
4.5" X 1.5" X 1.25" (11.4 X 3.8 X 3.2 cm)
6.9 oz (193 g)
3.6 oz (101 g)
2.6 oz (71 g)
17
