Nady Wireless Systems are type accepted under FCC rules parts 90, 74 and 15. The
device complies with RSS-210 of Industry & Science Canada. Operation is subject to
the following two conditions: (1) this device may not cause harmful interference and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
NADY SYSTEMS, INC.
6701 Shellmound Street • Emeryville, CA 94608 USA
Tel: 510/652-2411 • Fax: 510/652-5075
www.nady.com
E N C OR E 20 0
VHF Bass Wireless Microphone System
OWNER'S MANUAL
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Nady Systems ENCORE 200
Summary of Contents for Nady Systems ENCORE 200
- Page 1 E N C OR E 20 0 VHF Bass Wireless Microphone System Nady Wireless Systems are type accepted under FCC rules parts 90, 74 and 15. The device complies with RSS-210 of Industry & Science Canada. Operation is subject to...
- Page 2 Nady Service Department via telephone at (510) 652-2411 or e-mail to service@nady.com for a Return Authorization (R/A) Number and a service quote (if out of warranty). Make sure the R/A Number is clearly marked on the outside of the package and enclose a cashier’s check or money order (if not prepaid with a credit card).
-
Page 3: Specifications
Controls OFF/STANDBY/ON switch, input level adjust This manual will first list the features of the Encore 200 and then will take you step by LED Indicator Unit “ON” (single flash), step to show you how to operate your new system. Included in this manual are system specifications and servicing information. - Page 4 • All the advantages of wireless operation — with the true-to-life sound of a cord... and more ENCORE 200 RECEIVER • Rugged half-rack model with retractable front panel dual antennas • DigiTRU Diversity™ for optimum range and dropout protection •...
- Page 5 RF LEVEL DISPLAY (15) flicker or stay on, the squelch control should be turned clock- The AF LEVEL LED DISPLAY (16) on the Encore 200 receiver will light up to 5 LEDs wise until the LEDs extinguish. When the squelch is properly adjusted, the (4 green and 1 red) for all input signals.
- Page 6 6. Connecting the Audio Output The Encore 200 receiver provides both a fixed mic level BALANCED AUDIO OUTPUT XLR (8) and an adjustable line level UNBALANCED AUDIO OUTPUT 1/4” JACK (10). The level from the UNBALANCED OUTPUT is controlled by the rear panel VOL- UME CONTROL (7).
