WARNING
READ ALL INSTRUCTIONS AND WARNINGS
CAREFULLY. FAILURE TO FOLLOW PROPER
PROCEDURES AND WARNINGS MAY RESULT
IN SERIOUS INJURY AND PROPERTY DAMAGE
Example only: SERIAL # ________ MFG. DATE ________ PURCHASE DATE: _________
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-877-323-5263, 8 a.m. - 6 p.m., PST, Monday - Friday, 8 a.m. – 12 p.m.
Saturday.
STAINLESS STEEL CHARCOAL GRILL
BARBECUE AU GAZ EN ACIER INOXYDABLE
(page17 )
PARRILLA A DE ACERO INOXIDABLE (página33 )
WARNING
FOR OUTDOOR USE ONLY
WARNING
This grill is not intended to be
installed in or on recreational
vehicles and/or boats.
ITEM/ARTICLE/ARTICULO #0297983
MODEL/MODÈLE/MODELO #720-0686
K15Y08P-1
Advertisement
Table of Contents
Related Manuals for Nexgrill 720-0686
Summary of Contents for Nexgrill 720-0686
- Page 1 ITEM/ARTICLE/ARTICULO #0297983 STAINLESS STEEL CHARCOAL GRILL BARBECUE AU GAZ EN ACIER INOXYDABLE (page17 ) PARRILLA A DE ACERO INOXIDABLE (página33 ) MODEL/MODÈLE/MODELO #720-0686 WARNING FOR OUTDOOR USE ONLY WARNING READ ALL INSTRUCTIONS AND WARNINGS CAREFULLY. FAILURE TO FOLLOW PROPER WARNING...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety Information……………………………………………………..........3 Package Contents List……….……………………………………………………………………….5 Hardware Contents…….…………………. ……………………….…………….………………..6 Preparation..........................6 Assembly Instructions…………………………………………………………………….…..……6 Operating Tips ………………………………………………………………..…….……..11 Charcoal Grill Information ………………………………………………………………….………14 Warranty……………………….………….…………………………………………..…………..….15 Replacement Parts List………………….…..……………………………………..…….….…….16... -
Page 3: Safety Information
SAFETY INFORMATION CAUTION WARNING – Hazards or unsafe practices which COULD result in severe This unit is heavy. Two people required for safe personal injury or death. assembly. Some parts may contain sharp edges. Wear protective gloves if necessary. CAUTION – Hazards or unsafe Read and follow all safety statements, warning, practices which COULD result in minor assembly instructions and use and care instructions... - Page 4 WARNING WARNING DO NOT store or operate this product in an area The grill head is heavy and will require two or more people to lift and position onto grill cart. accessible to children or pets. Store this unit in a dry, protected location.
-
Page 5: Package Contents List
PACKAGE CONTENTS LIST A. Bottom Panel -----------1pc B. Caster ------------------2pcs C. Swivel Caster with brake-- D. Swivel Caster ----------1pc E. Left Side Panel --------1pc F. Right Side Panel---------1pc G. Back Panel ----------1pc H. Charcoal grill firebox with Crank Handle ----------1pc main lid ---1pc Charcoal Tray ----------1pc Drawer A ----------1pc . -
Page 6: Hardware Contents
HARDWARE CONTENTS Required Extra Pack Description Total hardware assembly 1/4-in. x 15-mm Truss Head Screw With Locking Washer (PDC) 24 pcs. 1/4-in. x 12-mm Truss Head Screw With Locking Washer(Stainless 20 pcs. Steel) 5/32. x10mm Truss Head Screw With Locking Washer(Stainless Steel) 3 pcs. - Page 7 Fig. 2 2. Side Panel Assembly Use two 1/4-in.×12-mm truss head screw with locking washers (BB) to connect the bottom of the left side panel (E) to the bottom panel (A). Make the left side panel flush with rear of bottom panel and tighten the screws as shown in Fig.
- Page 8 Fig. 5 4. Drawer Clapboard assembly Insert the drawer clapboard (Q) into the slot which under the first line of glides, attached the clapboard with two 5/32-in. x 10-mm truss head screw with locking washers (CC) as shown in Fig.5. 5/32-in.x10-mm truss head screw with locking washers (CC) 2 x Fig.
- Page 9 Fig. 8 6. Charcoal Tray and Drawers Assembly Insert the charcoal tray (J), drawer and drawer B to the glides. and then push them in as shown in Fig. 8. Fig. 9 7. Charcoal Handle Assembly Remove the charcoal handle from the carton, and then screw it into the hole on the charcoal door by turning the handle clockwise as shown in Fig.
- Page 10 Fig. 11 Align the bottom key holes on right side shelf with two loosened screws, and tighten these two screws as shown in Fig. 11. Fig. 12 three 1/4-in. x 15-mm truss head screws with locking washer (AA) and three 1/4-in. Flat Washer(DD), to keep the right side shelf(O) in place.
-
Page 11: Operating Tips
Operating Tips Fig. 14 Use of the Grate Lifter WARNING: THE GRATES COULD BE EXTREMELY HOT EVEN WHEN CHARCOAL IS EXTINGUISHED. DO NOT TRY TO MOVE THE GRATES WHILE CHARCOAL IS BURNING. IF YOU MUST MOVE THE GRATES WHILE THE GRATES ARE STILL HOT, WARN ANYONE AROUND AND HANDLE GRATES WITH CARE. - Page 12 Seasoning Unit 1. Before your first cooking you should season the unit to enhance the cooking and to provide better overall durability. Failure to properly follow these steps may damage the finish and/or impart metallic flavors to your foods. 2. Remove all retail hangtags that are on the unit, making sure NOT to remove safety markings from the unit.
-
Page 13: Charcoal Grill Information
CHARCOAL GRILL INFORMATION WARNING Keep a fire extinguisher nearby at all times. This grill is for outdoor use only, in well-ventilated areas. The use of alcohol, prescription or non-prescription drugs may impair the user’s ability to properly assemble and safely operate this unit. Use caution when lifting and moving the unit to avoid back strain or back injury. - Page 14 ONE YEAR LIMITED WARRANTY (Model # 720-0686) Nexgrill warrants to the original consumer-purchaser only that this product (Model #720-0686) shall be free from defects in workmanship and materials after correct assembly and under normal and reasonable home use for the periods indicated below beginning on the date of purchase. The manufacturer reserves the right to require photographic evidence of damage, or that defective parts be returned, postage and or freight pre-paid by the consumer, for review and examination.
-
Page 15: Replacement Parts List
REPLACEMENT PARTS LIST For replacement parts, call our customer service department at 1-877-323-5263, 8 a.m. – 6 p.m., PST, Monday – Friday and 8 a.m. – 12 p.m. PS, Saturday. WARRANTY WARRANTY REF# DESCRIPTION REF# DESCRIPTION COVERAGE COVERAGE Main lid Left side panel, top Main lid screw Right side panel, top... - Page 16 Printed in China 110408-CZ-1...
