ASSEMBLY & OPERATING INSTRUCTIONS
Model: 720-0697A
FOR OUTDOOR USE ONLY
WARNING
To reduce the risk of fire, burn hazard or other injury,
read the manual carefully and completely before
using your grill.
Example only: SERIAL # ________ MFG. DATE ________ PURCHASE DATE: _________
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1- 800-913-8999, 7 a.m. - 5 p.m., PST, Monday - Friday
300
4 00
500
600
20 0
100
7 00
800
WARNING
FOR OUTDOOR USE ONLY.
WARNING
This grill is not intended to be
installed in or on recreational
vehicles and/or boats.
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 720-0697A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Nexgrill 720-0697A

Summary of Contents for Nexgrill 720-0697A

  • Page 1 ASSEMBLY & OPERATING INSTRUCTIONS 4 00 20 0 7 00 Model: 720-0697A FOR OUTDOOR USE ONLY WARNING WARNING To reduce the risk of fire, burn hazard or other injury, FOR OUTDOOR USE ONLY. ® read the manual carefully and completely before using your grill.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Safety Information….…………………………………………………..………………...……..….3 Package Contents List………………………………………………………………………..……..7 Preparation……………….…………………. ……………………….…………….………………..8 Assembly Instructions…………………………………………………………….…..……..………9 Installation Instructions……………………………………………………………..…….……...16 Operating Instructions…….………………………………………………….…….…..……….….19 Care and Maintenance……………………………………………………………………………..21 Troubleshooting…………………………………………………………………..……….……..…23 Warranty………………………………….…………………………………………..………..…….25 Replacement Parts List………………….…...……………………………………..…….……….26 DANGER WARNING If you smell gas: 1. Do not store or use gasoline or other 1. Shut off gas to the appliance. flammable liquids or vapors in the 2.

  • Page 3: Safety Information

    SAFETY INFORMATION WARNING Do not try lighting this appliance without first reading WARNING the “LIGHTING INSTRUCTIONS” section of this manual. WARNING – Hazards or unsafe practices which COULD result in severe personal injury or death. CAUTION CAUTION – Hazards or unsafe practices which COULD result in minor personal injury.
  • Page 4 WARNING WARNING Do not leave the grill unattended while cooking. Spiders and insects can nest inside the burners of the grill and disrupt gas flow. Inspect the grill at least twice a year. WARNING Failure to properly place the burner over the orifice could cause a fire to occur behind and beneath the valve panel, thereby damaging the grill and making CAUTION...
  • Page 5 Do not use indoors. TESTED IN ACCORDANCE WITH ANSI Z21.58a WARNING LATEST STANDARD and CGA 1.6a-2008 Do not try lighting this appliance without first STANDARD FOR OUTDOOR COOKING GAS reading the “LIGHTING INSTRUCTIONS” section APPLIANCES. THIS GRILL IS FOR OUTDOOR USE of this manual.
  • Page 6 For proper lighting and performance of the burners, keep the burner ports clean. It is necessary to clean them periodically for optimum performance. The burners will only operate in one position and must be mounted correctly for safe operation. Exercise caution when cleaning grill. To avoid steam burns, do not use a wet sponge or cloth to clean the grill while it is hot.

  • Page 7: Package Contents List

    PACKAGE CONTENTS LIST A. Firebox Assembly --------1pc. B. Bottom Panel Tank Bolt-1pc. C. Wheel-----------------------2pcs. & 30 0 7 0 0 D. Side Burner Shelf & Control E. Left Side Shelf & Control F. Cart Leg, Front Left--------1pc. Panel-------1pc. Panel------1pc. G. Cart Leg, Back Left--------1pc. H.

  • Page 8: Preparation

    V. 1.5 Volt “AA” Size Alkaline W. Grease Box ----------1pc. X. Grease Tray -------- 1pc. Battery----------1pc. Y. Diagonal Bar Barrier -----1pc. Z. Warming Rack ----------1pc. HARDWARE CONTENTS Required for Extra Pack Description Total assembly hardware 5/32-in. x 10-mm Truss Head Screw 38 pcs.

  • Page 9: Assembly Instructions

    ASSEMBLY INSTRUCTIONS Fig. 1 1. Cart Assembly a) Place the Cart Caster Insert (K) into the Cart Leg, Front Left (F) and Cart Leg, Back Left (G). As shown in Fig.1. Attach Cart Leg, Front Left (F) and Cart Leg, Back Left (G) with Cart Frame (H) Using four 1/4-in.
  • Page 10 Fig. 5 3. Bottom Panel Assembly a) Use four 1/4-in. x 61-mm Truss Head Screws (JJ) and four 1/4-in. Locking Washers (DD) to connect the bottom of the left cart legs to the Bottom Panel (B). Make sure the cart legs are flush with the Bottom Panel (B) and tighten the screws.
  • Page 11 6. Front Panel, Top Assembly Fig. 8 Use four 5/32-in. x 10-mm Truss Head Screws (AA) and four 5/32-in. Locking Washers (BB) to attach the Front panel, Top (S) to the Cart Leg, Front Left (F) and Cart Leg, Front Right (I). Use two 5/32-in.
  • Page 12 Fig. 11 9. Firebox Assembly a) Remove the Firebox Assembly (A) 3 0 0 40 0 2 0 0 8 0 0 from the carton and carefully place onto the grill cart. Lid handle will face front and be above front panel (S). As shown in Fig.11.
  • Page 13 Fig. 14 c)Use four 5/32-in. x 10-mm Truss Head Screw (AA) and four 5/32-in Locking Washer (BB) to assemble the Triangle Bracket, Right (P) to the bottom rear of Side Burner Shelf (D) and Cart Leg, Back Right (J). As shown in Fig. 14. Fig.
  • Page 14 13. Side Burner Installation Fig. 18 a) Open side burner lid and place the Side Tube Burner (T) through the opening. 70 0 8 00 Place the Side Tube Burner (U) tube over the side burner gas valve and make sure Side Burner gas valve is inserted into side burner tube.
  • Page 15 Fig. 21 16. Position Flame Tamers, Cooking Grids and warming rack a) The Flame Tamers (N) are shipped in the main firebox assembly. Unpack them in firebox and make sure the Flame Tamers (N) in the channels to ensure the Flame Tamers are centered over the burners. As shown in Figure 21A.

  • Page 16: Installation Instructions

    INSTALLATION INSTRUCTIONS GAS HOOK-UP Only the pressure regulator and hose assembly supplied with the grill should be used. Any replacement pressure regulator and hose assembly must be specified by the grill manufacturer. This grill is configured for Liquid Propane. Do not use a Natural Gas supply. Total gas consumption (per hour) with all burners set on “HI”: Main burners 48,000 BTU/Hr.
  • Page 17 h) Before lighting the grill, use a soap and water solution to check all the connections for leaks. If a leak is found, turn the cylinder valve “OFF” and do not use the grill until a local Liquid Propane dealer can make repairs. Please make sure the cylinder valve connection device shall properly and safely mate with the connection device attached to the inlet of the pressure regulator.
  • Page 18 WARNING 1. Storage of an outdoor cooking gas appliance indoor is permissible only if the cylinder is disconnected and removed from the outdoor cooking gas appliance. 2. Cylinder must be stored outdoors out of the reach of children and must not be stored in a building, garage or any other enclosed area.

  • Page 19: Operating Instructions

    OPERATING INSTRUCTIONS General Use of the Grill Each main burner is rated at 12,000 BTU/Hr. The main grill burners encompass the entire cooking area and are side ported to minimize blockage from falling grease and debris. Above the burners are flame tamers. The igniter knobs are located on the center portion of the valve panel.
  • Page 20 TO LIGHT THE SIDE BURNER 1. Push and turn Side Burner control knob to IGNITE/HI, at the same time, press and hold electronic ignition button to light the burner. 2. Once the burner is lit, release the electronic ignition button and knob. 3.

  • Page 21: Care And Maintenance

    Side Burner 1. If you have already attempted to light the side burner with the igniter, allow 5 minutes for any accumulated gas to dissipate. 2. Insert a match into the lighting rod as shown in Fig. 25. Ignite the match and hold next to the burner. 3.
  • Page 22 Grill Burners Extreme care should be taken when removing a burner. It must be correctly centered on the orifice before any attempt is made to relight the grill. Frequency of cleaning will depend on how often you use the grill. Failure to properly place the burner over the orifice could cause a fire to occur behind and beneath the valve panel, thereby damaging the grill and making it unsafe to operate.

  • Page 23: Troubleshooting

    TROUBLESHOOTING Problems Possible Solutions Grill will not light. 1. Push and turn the knob and check for sparks. 2. If there is a spark, check to make sure gas is supplied to the burner. a. Purge the line of any trapped air. b.
  • Page 24 Possible Solutions Burner blows out. 1. Check for any burner defects. 2. Check for proper burner installation. 3. Make certain the fuel mixture is not too lean. 4. Make sure the gas supply is sufficient. 5. See if the LP tank is empty. Low heat, LP gas.

  • Page 25: Warranty

    LIMITED WARRANTY (Model # 720-0697A) The manufacturer warrants to the original consumer-purchaser only that this product (Model #720-0697A) shall be free from defects in workmanship and materials after correct assembly and under normal and reasonable home use for the periods indicated below beginning on the date of purchase.

  • Page 26: Replacement Parts List

    REPLACEMENT PARTS LIST For replacement parts, call our customer service department at 1-800-913-8999, 7 a.m. – 5 p.m., PST, Monday – Friday. WARRANTY WARRANTY REF# DESCRIPTION QTY REF# DESCRIPTION COVERAGE COVERAGE Main Lid Bottom Panel, LP Hood Buffer B 2pcs 33 Cart Frame 2pcs Main Lid Screw...
  • Page 27 3 00 40 0 5 00 20 0 60 0 10 0 70 0 8 00...
