Brickcom FB-100A Quick Installation Manual page 5
Hide thumbs
Also See for FB-100A:
- User manual (85 pages) ,
- Quick installation manual (28 pages) ,
- User manual (139 pages)
Advertisement
2. Device Description
<Front Panel>
Status LED
Built-in
Microphone
<Rear Panel>
Power Connector (AC24V in) (*)
Power Connector
(DC12V in)
Auto Iris Connector (*)
SD/SDHC
Card Slot (*)
Reset Button
Microphone/Line
In
Light Sensor
WPS LED (*)
Ethernet RJ45 10/100 Socket
(Link/Power LED embedded)
Detachable Antenna (*)
Extension I/O
Terminal Block
Audio Out
WPS Button (*)
