MultiFRAD 3000-Series User Guide

Technical Specifications

• Provides access to frame relay networks for SLIP, PPP, async and HDLC sync devices.
• Trunk and Data ports may be configured as EIA-232 or V.35
• Trunk Speeds up to T1/E1 synchronous
• 4MB DRAM
• 16MB of flash memory

Ethernet Port

• One Ethernet Interface - 10Base-T (twisted Pair) RJ-45 connector

Command Port

• Single 19.2K bps asynchronous Command Port with a DB-25 female connector

Composite Link (external)

• Access Rate: 1.544M bps (T1) or 2.048M bps (E1) sync on DTE-type RS-232 or V.35
interface.

Channel Connectors

• 6 on the FR3060; 10 on the FR3100
• Data Rate: Channels 1 and 2 up to 512K bps with V.35 interface; synchronous to 128K
bps on RS-232/V.35 interface; or asynchronous to 115.2K bps on RS-232/V.35 interface.

Voice/Fax Channel Connectors

• Two RJ-11 jacks (FXO and FXS)
• One RJ-48 jack (E&M)

Electrical/Physical

• Operating Environment:
• Power Requirements:
• Dimensions:
• Weight:

Requirement

• PC with Windows 3.1x/95/98/NT, Terminal/Dumb Terminal @19,200 bps for menu driven
local configuration, or Remote Configuration via web browser or Telnet.
12
o o
32-104 F (0-40 C); 95% non-condensing humidity
100-250V AC at 50/60 Hz
17.4" wide x 3.75" high x 8" deep
44.2 cm wide x 8.9 cm high x 20.3 cm deep
7.4 lbs.
3.4 kg
