6 - PANEL REMOVAL
Filler panel "F"
Loosen the three screws "v" and raise the panel "F" slightly so that screw "v" comes out of the hole "a" then slide out panel "F".
a
F
v
31
Technical Dept. - All rights reserved - Reproduction is prohibited
