Signal Booster
Installation
Guide
4G LTE 700
Band 13, 70 dB
Adjustable Gain
In-Building Wireless 700 MHz
Smart Technology ™
Signal Booster
Contents:
Antenna Options & Accessories . . . . . . . . . . . . . . . . . . . 1
Quick Install Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Installation Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Before Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Outside Antenna Installation . . . . . . . . . . . . . . . . . . . . . . 6
Installing the Inside Antenna . . . . . . . . . . . . . . . . . . . . . . 8
Finding the Strongest Signal . . . . . . . . . . . . . . . . . . . . . 11
Warnings and Recommendations . . . . . . . . . . . . . . . . . 15
Guarantee & Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . Back Cover
Note: This manual contains important safety and operating information . Please read and
follow the instructions in this manual . Failure to do so could be hazardous and result in
damage to your Signal Booster .
Wilson
Electronics, Inc.
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 4G LTE 700 and is the answer not in the manual?

Questions and answers

Related Manuals for Wilson Electronics 4G LTE 700

Summary of Contents for Wilson Electronics 4G LTE 700

  • Page 1: Table Of Contents

    Installing the Inside Antenna . . . . . . . . . . . . . . . . . . . . . . 8 Installing a Wilson Electronics Signal Booster . . . . . . . . . 9 Powering up a Wilson Electronics Signal Booster .

  • Page 2: Antenna Options & Accessories

    Installation Instructions for the Following Wilson Electronics Signal Booster: 4G LTE 700 Band 13, 70 dB Adjustable Gain In-Building Wireless 700MHz Smart Technology ™ Signal Booster Model # 271865 FCC ID: PWO271865 IC: 4726A-271865 The term “IC” before the radio certification number signifies that Industry Canada technical specifications were met .

  • Page 3: Quick Install Overview

    Connecting the Signal Booster directly to a cell phone with use of an adapter may damage the cell phone and the Signal Booster . Contact Wilson Electronics Technical Support Team with any questions at 866-294-1660 or email: tech@wilsonelectronics.com. Hours: 7 am to 6 pm MST.

  • Page 4: Installation Diagram

    Make sure the protector is installed in line coverage). between the Outside Antenna and the Signal Booster. Typical Installation Contact Wilson Electronics Technical Support Team with any questions at 866-294-1660 or email: tech@wilsonelectronics.com. Hours: 7 am to 6 pm MST.

  • Page 5: Before Getting Started

    Inside Antennas) Inside Antenna (Optional third antenna for additional Lightning coverage) . Surge Protector (recommended) Signal Booster Power Supply Contact Wilson Electronics Technical Support Team with any questions at 866-294-1660 or email: tech@wilsonelectronics.com. Hours: 7 am to 6 pm MST.
  • Page 6 Antenna and back to the cell tower . (Note: The Signal Booster will only operate if there is an adequate signal to amplify.) Contact Wilson Electronics Technical Support Team with any questions at 866-294-1660 or email: tech@wilsonelectronics.com. Hours: 7 am to 6 pm MST.

  • Page 7: Outside Antenna Installation

    Signal Booster . Attach a ground wire (not included) to the LSP . LSP may be purchased at www.WilsonElectronics.com or 800-204-4104 . Contact Wilson Electronics Technical Support Team with any questions at 866-294-1660 or email: tech@wilsonelectronics.com. Hours: 7 am to 6 pm MST.
  • Page 8 After drilling the required hole, run the cable through and seal it with silicone, cable bushings or other waterproof sealant to Contact Wilson Electronics Technical Support Team with any questions at 866-294-1660 or email: tech@wilsonelectronics.com. Hours: 7 am to 6 pm MST.

  • Page 9: Installing The Inside Antenna

    8 inches for the panel antenna . Splitter Options: Optional Panel (sold separately) Inside Antenna (sold separately) 2-way 3-way 4-way (859957) (859980) (859981) Contact Wilson Electronics Technical Support Team with any questions at 866-294-1660 or email: tech@wilsonelectronics.com. Hours: 7 am to 6 pm MST.

  • Page 10: Installing A Wilson Electronics Signal Booster

    Note: Be careful when plugging the connector in so as not to damage the center pins on the connectors. Contact Wilson Electronics Technical Support Team with any questions at 866-294-1660 or email: tech@wilsonelectronics.com. Hours: 7 am to 6 pm MST.

  • Page 11: Powering Up A Wilson Electronics Signal Booster

    866-294-1660 or email tech@wilsonelectronics .com . Technical Support hours are 7 am to 6 pm MST . Contact Wilson Electronics Technical Support Team with any questions at 866-294-1660 or email: tech@wilsonelectronics.com. Hours: 7 am to 6 pm MST.

  • Page 12: Finding The Strongest Signal

    . (See graph below) . Signal Strength Graph EXCELLENT GOOD POOR SIGNAL -50dB -60dB -70dB -80dB -90dB -100dB -110dB Contact Wilson Electronics Technical Support Team with any questions at 866-294-1660 or email: tech@wilsonelectronics.com. Hours: 7 am to 6 pm MST.
  • Page 13 Antenna Signal Booster Figure 2 INCORRECT INSTALLATION Never point antennas toward each other Outdoor Antenna Inside Antenna Signal Booster Contact Wilson Electronics Technical Support Team with any questions at 866-294-1660 or email: tech@wilsonelectronics.com. Hours: 7 am to 6 pm MST.

  • Page 14: Understanding The Signal Booster Lights

    Outside Antenna until the light turns to blinking green, waiting 5 seconds between each adjustment for the Signal Booster to Contact Wilson Electronics Technical Support Team with any questions at 866-294-1660 or email: tech@wilsonelectronics.com. Hours: 7 am to 6 pm MST.
  • Page 15 The 700 MHz indicator light on the Signal Booster will be a solid green after the first 15 minute installation period, if the unit is powered up and working properly . Contact Wilson Electronics Technical Support Team with any questions at 866-294-1660 or email: tech@wilsonelectronics.com. Hours: 7 am to 6 pm MST.

  • Page 16: Warnings And Recommendations

    Antenna are connected to the Signal Booster before powering up the Signal Booster . Recommendation: Lightning Surge Protection is recommended for all in-building installations. Contact Wilson Electronics Technical Support Team with any questions at 866-294-1660 or email: tech@wilsonelectronics.com. Hours: 7 am to 6 pm MST.
  • Page 17 About Wilson Electronics Wilson Electronics, Inc . has been a leader in the wireless communications industry for over 40 years . The company designs and manufactures Signal Boosters, Antennas and related components that significantly improve cellular phone signal reception and transmission in a wide variety of applications, both mobile (marine, RV, vehicles) and in-building (home, office, M2M) .

  • Page 18: Guarantee & Warranty

    Returned Material Authorization (RMA) number supplied by Wilson Electronics . Wilson Electronics shall, at its option, either repair or replace the product . Wilson Electronics will pay for delivery of the repaired or replaced product back to the original consumer if located within the continental U .S .
  • Page 19 Copyright © 2011 Wilson Electronics, Inc . All rights reserved . This device complies with part 15 of the FCC Rules . Operation is subject to the following two conditions: (1) This device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation .

  • Page 20: Specifications

    4G LTE 700 Specifications 4G LTE 700 Specifications Model Number 271865 Antenna connectors N-Female Antenna impedance 50 ohms Dimensions 5 .7 x 4 .2 x 1 .5 inch (14 .0 x 10 .8 x 3 .9 cm) Weight 1 .27 lbs (0 .544 kg)
