Tri-Band 4G-V
Adjustable Gain 700 (Band 13) / 800 / 1900 MHz
In-Building Wireless Smart Technology
(Band 13 is 700 MHz Verizon
Tri-Band 4G-A
Adjustable Gain 700 (Band 12/17) / 800 / 1900 MHz
In-Building Wireless Smart Technology
(Band 12/17 is 700 MHz AT&T
Contents:
Antenna Options & Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Quick Install Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Installation Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Before Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Finding the Strongest Signal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Outside Antenna Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Inside Antenna Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Wilson Electronics Signal Booster Installation. . . . . . . . . . . . . . . . . . .9
Powering up a Wilson Electronics Signal Booster . . . . . . . . . . . . . . . .9
Understanding the Signal Booster Lights . . . . . . . . . . . . . . . . . . . . .10
Warnings and Recommendations . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Guarantee & Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Back Cover
Appearance of device and accessories may vary.
Note: This manual contains important safety and operating information. Please read and follow the instructions in
this manual. Failure to do so could be hazardous and result in damage to your Signal Booster.
Signal Booster
™
LTE)
™
Signal Booster
™
LTE)
®
