SPECIFICATIONS - CyclonePro - MT120EVO
Input Voltage..............................230-240 Vac, 50 Hz
Max. Pull Force .........................1200 N
Power ........................................225 Watt
Standby Power ..........................0.8 Watt (door fully closed)
Normal Torque ...........................8 Nm
Max door weight.........................286 kgs
Max lift under spring tension ....20 kg
Max door area............................Residential Sectional Doors up to 20 m
Motor
Type...........................................DC gearmotor permanent lubrication
Noise level .................................54 db at 1 metre
Speed ........................................2 speed programmable (NORMAL or SLOW)
Drive Mechanism
Drive ..........................................Chain with one-piece trolley on steel rail.
Length of Travel.........................Adjustable to 3.0 m
LED light ....................................25 Watt equivalent
Door Linkage .............................Adjustable door arm. Pull cord trolley release.
Safety
Personal ....................................Push button stop in UP and DOWN direction. Automatic safety reverse in both UP
Electronic...................................Automatic force adjustment
Electrical ....................................Transformer overload protector and low voltage push button wiring.
Limit Device ...............................Mechanical Passpoint/RPM sensor
Limit Adjustment ........................Electronic
Soft-start/Soft-stop
Dimensions
Length (Overall)..........................3.24 m
Headroom Required ..................30 mm
Hanging Weight .........................12.5 kg
Receiver
Memory Registers .....................64 handset codes
Operating
Frequency..................................433.30/433.92/434.54 MHz
Warranty Registration
To validate your warranty you must complete
TM
Trademark of The Chamberlain Group, Inc.
® Registered Trademark of The Chamberlain Group, Inc.
© 2015, The Chamberlain Group Inc.
and DOWN direction.
4 keypad devices - 1 code each
the registration form online at:
gomerlin.com.au/warranty
gomerlin.co.nz/warranty
