Finalizing the Installation

Center Twig

The center twig is shown below. It has a pin on the bottom side. When in place, the fork on the front
straddles the grate and the pin rests on the rear burner (make sure it is not over any burner holes).

Front Ember Chunk

The front ember chunk has a groove on the bottom that fits over the grate. Place it as shown below.
