Corner Installations - Top Vent Configuration
A typical 45° installation uses the framing dimensions shown in the illustration below (NOTE: all
clearances still apply).
15-1/2"
394mm
48" Min.
1219mm
Travis Industries
Installation
(for qualified installers only)
Minimum 1/2" (13mm) Clearance
4140220
100-01347
