Intake Restrictor Adjustment
The intake restrictor is located behind the accent light, on the back wall of the firebox. To adjust the
restrictor, follow the steps below:
Travis Industries
Installation
(for qualified installers only)
Loosen the two screws
holding the intake
restrictor in place..
Position # 1 (open)
Slide the restrictor down
to the second position
and tighten the screws.
Position # 3 (not used)
Position # 2 (open)
4140220
23
100-01347
