BodyCraft 50442 Assembly Instructions Manual

The jones strength training system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
THE JONES STRENGTH TRAINING SYSTEM
Jones Cable Functional Trainer Attachment (for Light Commercial Model)
QUESTION?
As a quality home gym supplier we are committed to your complete satisfaction. If you have
questions, or find missing or damaged parts, we will guarantee your complete satisfaction through
our authorized dealer service centers or our home office customer service department. Please call
your local dealer for assistance or BodyCraft at 800-990-5556 (9:00 AM - 5:00 PM). Our trained
technicians will provide immediate assistance to you, free of charge.
Bodycraft is a division of Recreation Supply Inc.
P.O. BOX 181
Sunbury, OH 43074

ASSEMBLY INSTRUCTION

50442

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 50442 and is the answer not in the manual?

Questions and answers

Related Manuals for BodyCraft 50442

Summary of Contents for BodyCraft 50442

  • Page 1: Assembly Instruction

    Please call your local dealer for assistance or BodyCraft at 800-990-5556 (9:00 AM - 5:00 PM). Our trained technicians will provide immediate assistance to you, free of charge.

  • Page 2: Before You Begin

    BEFORE YOU BEGIN Congratulations and thank you for selecting the JONES MACHINE strength training system. The JONES MACHINE offers an impressive array of strength training exercises to develop every major muscle group of the body. Whether your goal is cardiovascular fitness, a shapely, toned body or dramatic muscle size and strength, the JONES MACHINE will help you achieve the specific results you want.
  • Page 3 OVERVIEW 403R 404L 406L2 405R1 406L1 405R2 407R 408L 401R 402L...
  • Page 4 PARTS LIST NO. DESCRIPTION QTY. 401R RIGHT BASE FRAME 402L LEFT BASE FRAME 403R RIGHT TOP FRAME 404L LEFT TOP FRAME 405R1 RIGHT FRONT TOP PANEL 401R 402L 403R 404L 405R2 RIGHT REAR TOP PANEL 406L1 LEFT FRONT TOP PANEL 406L2 LEFT REAR TOP PANEL 407R...
  • Page 5 STEP 1 Base Frame Assembly 1. To ease assembly, DO NOT tighten any bolts until instructed. Wherever we describe assembly for a right side component, please duplicate procedure for the left side. 2. Remove two 3/8" X 4" Hex Bolts (42) on your Jones and attach Right Base Frame (401R) to The Jones.

  • Page 6: Pulley Bracket

    STEP 2 Weight Base Assembly 1. Attach Upright Frame (415) to the Right Base Frame (401R), using two 3/8" X 2-3/4" Hex Bolts (433), four 3/8" Washers (438) and two 3/8" Nylon Nuts (441). 2. Insert two Guide Rod Holders (429) to the Right Base Frame (401R) as shown.

  • Page 7: Guide Rod

    STEP 3 Top Frame Assembly 1. Loosen the pre-assembled two 5/16" X 1/4" Set Screws (437) in the ringlets on the Top Frame (403R) to allow it to easily slide onto the Guide Rods (414). Slide the Top Frame (403R) onto the Guide Rods (414). Attach Right Top Frame (403R) to Front Top Frame (2) of the Jones, re-using the two 3/8"...
  • Page 8 STEP 4 Top Panel Assembly 1. Attach Right Top Panel (405R1 & 405R2), to the Right Top Frame (403R) as shown using five 3/8" X 3" Hex Bolts (432), ten 3/8" Washers (438) and five 3/8" Nylon Nuts (441). Repeat for left side. Tighten all Bolts.

  • Page 9: Top Cable

    STEP 5 Top Cable Assembly TOP CABLE (416) Assemble cables and pulleys simultaneously. ※Pulleys are mounted using 3/8" X 3" Hex Bolts (432), 3/8" Washers (438), and 3/8" Nylon Nuts (441). Pay attention, as some places use washers, others don't. 1.
  • Page 10 STEP 6 Top Cable Assembly TOP CABLE (416) Assemble cables and pulleys simultaneously. ※Pulleys are mounted using 3/8" X 3" Hex Bolts (432), 3/8" Washers (438), and 3/8" Nylon Nuts (441). Pay attention, as some places use washers, others don't. 1.

  • Page 11: X 1/2" Hex Threaded Bolt

    STEP 7 Stack Shroud Assembly 1. Attach Front & Rear Stack Shroud (412 & 413) and Trim for Shroud (446) to the Right Top Frame (403R) and Right Base Frame (401R) using four 5/16" X 1/2" Hex Threaded Bolts (436) and eight 5/16" Washers (439). 2.
  • Page 12 ADJUSTER(407R) are fully engaged when using Jones Cable Functional Trainer Attachment. 4.Enjoy many years of a Fit Lifestyle. Thank you for purchasing the Jones Machine System. If You have any questions, please call your local BodyCraft dealer or call our customer service department at 800-990-5556...
