READ AND SAVE THESE INSTRUCTIONS
44" & 52" Damp & Wet Location
Snugger Ceiling Fan Owner's Manual
44" Model Numbers
for Damp Locations
CF244BS00
Brushed Steel
CF244CRM00
Chrome
44" Model Numbers
for Wet Locations
CF244WW00
Appliance White
CF244ORB00
Oil Rubbed Bronze
Net Weight:
Questions, problems, missing parts: Before returning to the store call
Part No. F40BP74080003
Revision: 130211
CURVA
18.3
Lbs.
Emerson Electric Customer Service
8 a.m. - 6 p.m., EST, Monday-Friday
1-800-654-3545
www.emersonfans.com
™
52" Model Numbers
for Damp Locations
CF252BS00
Brushed Steel
CF252CRM00
Chrome
52" Model Numbers
for Wet Locations
CF252WW00
Appliance White
CF252ORB00
Oil Rubbed Bronze
19.2
Net Weight:
Lbs.
Form No. BP7408-3
U.L. Model No.: CF244 & CF252
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Emerson CURVA CF244BS00
Summary of Contents for Emerson CURVA CF244BS00
- Page 1 18.3 19.2 Net Weight: Lbs. Net Weight: Lbs. Questions, problems, missing parts: Before returning to the store call Emerson Electric Customer Service 8 a.m. - 6 p.m., EST, Monday-Friday 1-800-654-3545 Part No. F40BP74080003 Form No. BP7408-3 www.emersonfans.com Revision: 130211 U.L. Model No.: CF244 & CF252...
-
Page 2: Safety Instructions
Electric Co. Substitution of parts or accessories not fan without blades. designated for use with this product by Emerson could 2. All wiring must be in accordance with the National result in personal injury or property damage. -
Page 3: Unpacking Instructions
Emerson Electric Co. Substitution of parts or Hanger Bracket accessories not designated for use with this product Hanger Ball/Downrod Assembly by Emerson Electric Co. could result in personal injury 6-Speed Electronic Receiver Control or property damage. with Parts Bag 6-Speed Handheld Transmitter 1. -
Page 4: Tools Needed For Assembly
Emerson Electric Fan/Light Remote Control supplied with the fan. WARNING Your new ceiling fan will require a grounded electrical Turning off wall switch is not sufficient. -
Page 5: Ceiling Fan Assembly
Ceiling Fan Assembly General FAN HOUSING M5 x 16mm FLANGE Your Emerson ceiling fan comes supplied with a HEAD BLADE SCREWS Fan/Light Remote Control which consists of a receiver (3 per blade) mounted inside the ceiling cover of the fan motor housing. - Page 6 Ceiling Fan Assembly (continued) 11. Carefully turn the partially assembled ceiling fan right side up and place the fan securely into the packing styrofoam in preparation for final assembly. HANGER BALL 12. Remove the hanger ball by loosening the setscrew in the hanger ball until the ball falls freely down the downrod (Figure 5).
-
Page 7: How To Hang Your Ceiling Fan
How to Hang Your Ceiling Fan WARNING CEILING The fan must be hung with at least 7' of clearance from floor to blades (Figure 9). WARNING LEAST The outlet box and joist must be securely mounted and capable of supporting at least 50 lbs. Use only a U.L. outlet box listed as “Acceptable for Fan Support of 22.7 kg. -
Page 8: How To Wire Your Ceiling Fan
How to Wire Your Ceiling Fan If you feel that you do not have enough electrical OUTLET BOX wiring knowledge or experience, have your fan BLACK SUPPLY WIRE installed by a licensed electrician. HANGER BRACKET BLACK FAN WIRE HANGER BRACKET BLACK/WHITE GROUND WIRE WARNING... - Page 9 How to Wire Your Ceiling Fan (continued) 3. After connections have been made, turn leads upward and carefully push leads into the outlet box, with the white and green leads on one side of the outlet box and the black and blue leads on the other inside of the outlet box.
-
Page 10: Remote Control Procedures
COMPARTMENT COVER Figure 18 Your Emerson receiver is equipped with a preset memory feature. If the AC supply to the receiver is powered through a wall switch, when the switch is turned OFF, the control will remember the light intensity and fan speed. - Page 11 Remote Control Procedures (continued) Installation of Storage Bracket TO INSTALL BRACKET TO WALL: SLIDE THE COVER UP TO EXPOSE THE for Remote Control SCREW HOLES FOR INSTALLATION A storage bracket is provided for holding your remote control when not in use. If you desire to use the bracket, install it on a wall that is away from excess COVER heat or humidity (Figure 19).
-
Page 12: Remote Control Trouble Shooting
Maintenance IMPORTANT CARE INSTRUCTIONS WARNING for your Ceiling Fan Do not use water when cleaning your ceiling fan. It Periodic cleaning of your new ceiling fan is the only could damage the motor or the blades and create the maintenance that is needed. possibility of an electrical shock. -
Page 13: Trouble Shooting
Trouble Shooting WARNING: FOR YOUR OWN SAFETY TURN OFF POWER AT FUSE BOX OR CIRCUIT BREAKER BEFORE TROUBLE SHOOTING YOUR FAN. TROUBLE PROBABLE CAUSE SUGGESTED REMEDY 1. Fan will not 1. Fuse or circuit breaker blown. 1. Check main and branch circuit fuses or circuit breakers. -
Page 14: Repair Parts
Repair Parts 10 - 52" 11- 44" U.L. Model No.: CF244 & CF252... -
Page 15: How To Order Repair Parts
Repair Parts Listing Damp Part Numbers Wet Part Numbers Model No. Model No. Model No. Model No. Model No. Model No. Model No. Model No. Description CF244BS00 CF252BS00 CF244CRM00 CF252CRM00 CF244WW00 CF252WW00 CF244ORB00 CF252ORB00 Hanger Pack Consisting of: 761655-17 761655-17 761655-88 761655-88 761655-14... -
Page 16: Energy Efficient Use Of Ceiling Fans
8 - 9 feet above the floor for optimal occupied space. Remember to adjust your thermostat airflow. Consult your Emerson Retailer for optional when using your ceiling fan - additional energy and mounting accessories. - Page 17 Notes emersonfans.com Please contact 1-800-654-3545 for further assistance U.L. Model No.: CF244 & CF252...
- Page 18 Notes U.L. Model No.: CF244 & CF252...
- Page 19 What We Will Do To Correct Problems: If during the one (1) year warranty period the motor or any component or accessory of your Emerson Ceiling Fan is defective in materials or workmanship, or if during the expected lifetime of the Emerson Ceiling Fan (when used in accordance with the User Manual or other instructions) the motor is defective in materials or workmanship, you must contact Emerson during the applicable warranty period.
- Page 20 Air Comfort Products DIVISION OF EMERSON ELECTRIC CO. 8100 W. Florissant • St. Louis, MO 63136 Questions, problems, missing parts: Before returning to the store call Emerson Electric Customer Service 8 a.m. - 6 p.m., EST, Monday-Friday 1-800-654-3545 www.emersonfans.com Retain this manual for future use.
