READ AND SAVE THESE INSTRUCTIONS
ATHENIAN

Ceiling Fan

Owner's Manual
Net Weight:
What The Warranty Covers:
This warranty covers the motor and the other components and accessories of your Emerson ceiling fan against all defects in workmanship and materials.
You must be the original purchaser or user of the product to be covered.
What The Period Of Coverage Is:
As it applies to the motor, this warranty will last for a lifetime of your ceiling fan. All other components and accessories are
covered by this warranty for one year from the date you purchased your ceiling fan. ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE, MADE WITH RESPECT TO COMPONENTS AND ACCESSORIES IS ALSO LIMITED TO ONE YEAR.
What Will Emerson Electric Co. Do To Correct Problems:
Emerson Electric Co. will replace a defective Emerson Air Comfort Ceiling Fan motor, blade, component or other accessory at no charge to you. If repair of
the motor or blades is not practical or possible within a reasonable time and no replacement can be provided, Emerson will refund the actual purchase price
of your fan. WE WILL SHIP THE REPAIRED PRODUCT OR REPLACEMENT TO YOU AT NO CHARGE, BUT YOU ARE RESPONSIBLE FOR ALL COSTS OR
REMOVAL, REINSTALLATION AND SHIPPING OF THE PRODUCT TO EMERSON ELECTRIC CO.
How Can You Get Service:
YOU MUST HAVE PROOF OF YOUR PURCHASE OF THE CEILING FAN TO OBTAIN LIMITED WARRANTY SERVICE. KEEP YOUR RECEIPT OR OTHER PROOF
OF PURCHASE. You can return the product to our factory or to your nearest authorized service center.
• To return the product to the factory, obtain a return authorization and service identification tag by writing to Air Comfort Products, Division of Emerson
Electric Co., 8100 W. Florissant Ave., St. Louis, MO 63136. Include all model numbers shown on the product with your request.
• To return the product to an authorized service center, call 1-800-654-3545 for the address of the nearest authorized service center.
You will be responsible for all insurance, freight or other transportation charges to our factory or authorized service center. Your Emerson Air Comfort
Ceiling Fan should be properly packed to avoid damage in transit since we will not be responsible for any such damage.
What Is Not Covered:
The glass globes and light bulbs of your ceiling fan are not covered by this warranty. This warranty also does not cover any defects, malfunctions or failures
caused by:
• Repairs by persons not authorized by Emerson Electric Co.,
• Use of parts or accessories not authorized by Emerson Electric Co.,
• Mishandling, improper installation, modifications or damage to your ceiling fan while in your possession, or
• Unreasonable use, misuse, abuse, including failing to do reasonable and necessary maintenance, and normal wear and tear.
Additionally, this warranty and any implied warranty of merchantability or fitness for a particular purpose are voided when:
• The original purchaser or user ceases to own the product, or
• The fan is moved from its original point of installation.
This warranty is only valid within the 50 states of the United States and the District of Columbia. No other written or oral warranties apply, and no employee,
agent, dealer or other person is authorized to give any warranties on behalf of Emerson Electric Co.
REPAIR, REPLACEMENT OR A REFUND ARE THE EXCLUSIVE REMEDIES AVAILABLE UNDER THIS WARRANTY AND EMERSON IS NOT RESPONSIBLE
FOR DAMAGES OF ANY KIND, INCLUDING INCIDENTAL AND CONSEQUENTIAL DAMAGES. Incidental damages include but are not limited to such damages
as loss of time and loss of use. Consequential damages include but are not limited to the cost of repairing or replacing other property which was damaged if
this product does not work properly.
How State Law Relates To The Warranty:
Some states do not allow the exclusion or limitation of incidental or consequential damages so the above exclusion or limitation may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
Part No. F40BP72780000
®
21.6
Lbs.
LIMITED WARRANTY
Model No.
CF2400AB00
CF2400BC00
CF2400ORB00
CF2400PW00
CF2400SCK00
CF2400WB00
Form No. BP7278

Advertisement

Table of Contents
loading

Summary of Contents for Emerson ATHENIAN CF2400AB00

  • Page 1: Ceiling Fan

    READ AND SAVE THESE INSTRUCTIONS ® ATHENIAN ™ Model No. CF2400AB00 Ceiling Fan CF2400BC00 Owner's Manual CF2400ORB00 CF2400PW00 CF2400SCK00 21.6 Net Weight: Lbs. CF2400WB00 LIMITED WARRANTY What The Warranty Covers: This warranty covers the motor and the other components and accessories of your Emerson ceiling fan against all defects in workmanship and materials.
  • Page 2: Safety Instructions

    WARNING WARNING: To avoid fire, shock, and serious personal injury, follow these instructions. Safety Instructions 1. Read your owner’s manual carefully and keep it for future reference. 2. Before servicing or cleaning unit, switch power off at service panel and lock service panel disconnecting means to prevent power from being switched on accidentally.
  • Page 3: Unpacking Instructions

    This Manual Is Designed to Make it as Easy as Possible for You to Assemble, Install, Operate and Maintain Your Ceiling Fan Tools Needed for Assembly Installed Wire Length Wire Size A.W.G. Up to 50 ft. One Phillips head screwdriver One wire stripper 50-100 ft.
  • Page 4: Electrical Requirements

    Electrical Requirements How to Assemble Your Ceiling Fan Your new ceiling fan will require a grounded electrical supply line of 120 volts AC, 60 Hz, 15 amp circuit. IMPORTANT: If you are going to use an Emerson The outlet box must be securely anchored and remote control and receiver to control your fan, capable of withstanding a load of at least 50 pounds.
  • Page 5 4. Align the clevis pin holes in the downrod with the 8. Reinstall the hanger ball on the downrod (Figure 4) holes in the motor coupling. Install the clevis pin as follows. Route the motor leads through the and secure with the hairpin clip (Figure 2). (Pin and hanger ball and slide the hanger ball over the clip are supplied in loose parts bag.) The clevis pin downrod.
  • Page 6: Your Ceiling Fan How To Hang

    11. Use the 10 round recessed holes in the motor hub WARNING that are marked with a “5” and install the five blade assemblies in accordance with Step 12. The outlet box and joist must be securely mounted One side of the switch housing has been indented and capable of supporting at least 50 lbs.
  • Page 7: How To Wire Your Ceiling Fan

    How to Wire Your EMERSON FAN CONTROL Ceiling Fan LISTED OUTLET BOX BLACK FAN WIRE If you feel that you do not have enough electrical GREEN WIRE BLACK LIGHT BLACK wiring knowledge or experience, have your fan (GROUND) CONTROL (HOT) FROM installed by a licensed electrician.
  • Page 8 4. Screw the two 1-1/4” threaded studs (supplied) into 9. Position the switch housing cover so that the tab on the tapped holes in the hanger bracket the inside of the switch housing cover aligns with (Figure 9). the notch in the switch housing (Figure 14). With the switch housing cover held in this position, 5.
  • Page 9: Using Your Ceiling Fan

    Using Your Ceiling Fan Attaching Light Kit 1. Restore electrical power to the outlet box by turning To install an Emerson accessory light kit, remove the the electricity on at the main fuse box. three screws securing the switch housing cover to the switch housing.
  • Page 10: Troubleshooting

    WARNING: FOR YOUR OWN SAFETY TURN OFF POWER AT FUSE BOX OR CIRCUIT BREAKER BEFORE TROUBLE SHOOTING YOUR FAN. Trouble Shooting TROUBLE PROBABLE CAUSE SUGGESTED REMEDY 1. Fan will not start. 1. Fuse or circuit breaker blown. 1. Check main and branch circuit fuses or circuit breakers. 2.
  • Page 11: Repair Parts

    Repair Parts Before discarding packaging material, be certain all parts have been removed. HOW TO ORDER REPAIR PARTS WHEN ORDERING REPAIR PARTS, ALWAYS GIVE THE FOLLOWING INFORMATION: • PART NUMBER • NAME OF ITEM • PART DESCRIPTION • MODEL NUMBER The model number of your Fan will be found on a label attached to the top housing.
  • Page 12 Repair Parts Listing Part Numbers Model No. Model No. Model No. Model No. Model No. Model No. Description CF2400AB00 CF2400BC00 CF2400ORB00 CF2400PW00 CF2400SCK00 CF2400WB00 Hanger Pack, Consisting of: 761655-3 761655-24 761655-32 761655-22 761655-31 761655-20 Hanger Bracket — — — —...
