READ AND SAVE THESE INSTRUCTIONS

CURVA LED OUTDOOR

44" & 52" Wet Location Ceiling Fan

44" Model Numbers

CF244LGRT00

Graphite

CF244LORB00

Oil Rubbed Bronze

CF244LWW00

Appliance White

Questions, problems, missing parts: Before returning to the store, Call Customer Service

BP7537-1 Curva LED Outdoor (EnSpFr) 20210201.indb 1

Owner's Manual

1-888-757-7697

52" Model Numbers

CF252LGRT00

Graphite

CF252LORB00

Oil Rubbed Bronze

CF252LWW00

Appliance White

U.L. Model No.: CF244L & CF252L

2/1/21 4:16 PM

Table of Contents

Need help?

Do you have a question about the Curva CF244LGRT00 and is the answer not in the manual?

Questions and answers

Summary of Contents for Emerson Curva CF244LGRT00

Page 1 READ AND SAVE THESE INSTRUCTIONS CURVA LED OUTDOOR 44” & 52” Wet Location Ceiling Fan Owner’s Manual 44” Model Numbers 52” Model Numbers CF252LGRT00 CF244LGRT00 Graphite Graphite CF252LORB00 CF244LORB00 Oil Rubbed Bronze Oil Rubbed Bronze CF252LWW00 CF244LWW00 Appliance White Appliance White Questions, problems, missing parts: Before returning to the store, Call Customer Service 1-888-757-7697 U.L.
Page 2: Table Of Contents
Table of Contents Section Section Safety Instructions 9 . Maintenance 10 . Troubleshooting 1 . Unpacking Instructions 11 . Repair Parts 2 . Electrical Requirements 12 . Energy Efficient Use of Ceiling Fan 3 . Ceiling Fan Assembly 4 . How to Hang Your Ceiling Fan 5 .
Page 3: Unpacking Instructions
1. Unpacking Instructions PACKAGE CONTENTS HARDWARE CONTENTS Part Description Quantity Wire Connectors, 12 ga. M5 x 16 mm Flange Head Blade Screws M4 x 10 mm Pan Head Screw for Lower Housing/LED Light Fixture Assembly (spare) Clevis Pin Hairpin Clip Threaded Stud, #8-32 x 1/1-4”...
Page 4: Electrical Requirements
1. Unpacking Instructions (Continued) THESE FAN MODELS ARE SUITABLE FOR WET LOCATIONS SUCH AS PORCHES, PATIOS, AND DECKS. This Manual Is Designed to Make it as Easy as Possible for You to Assemble, Install, Operate and Maintain Your Ceiling Fan Tools Needed for Assembly One Phillips Head Screwdriver One Stepladder...
Page 5: Ceiling Fan Assembly
3. Ceiling Fan Assembly M5 x 16 mm FLANGE HEAD BLADE SCREWS (3 per blade) FAN BLADE SLIDE FAN BLADE INTO BLADE CENTER SLOT FAN MOTOR ASSEMBLY WARNING BLADE SLOT Figure 1 To reduce the risk of personal injury, do not bend the blades during installation, balancing the blades or cleaning the fan.
Page 6 3. Ceiling Fan Assembly (Continued) GREEN GROUND WIRE 4.5" DOWNROD HANGER BALL PHILLIPS HEAD SET SCREW (LOOSENED) Figure 3 1/2-INCH BLACK WIRE 6 TO 9 BLUE WIRE INCHES WHITE WIRE THREE 80" MOTOR WIRES (UNTWISTED) 4.5" DOWNROD Figure 4 BP7537-1 Curva LED Outdoor (EnSpFr) 20210201.indb 6 BP7537-1 Curva LED Outdoor (EnSpFr) 20210201.indb 6 2/1/21 4:16 PM 2/1/21 4:16 PM...
Page 7 3. Ceiling Fan Assembly (Continued) DOWNROD LOOSEN PHILLIPS HEAD SET MOTOR SCREWS (2) COUPLER Figure 5 HAIRPIN CLIP CLEVIS MOTOR COUPLER HAIRPIN CLEVIS CLIP WARNING It is critical that the clevis pin in the motor coupler is properly installed. Failure to verify that the pin is properly installed could result in the fan falling.
Page 8 3. Ceiling Fan Assembly (Continued) Make sure the Grommet is properly installed in the Coupler Cover, then slide the Coupler Cover on the DOWNROD GROMMET Downrod until it rests on the Motor Housing (Figure 8) . COUPLER COVER Figure 8 Place the Ceiling Cover over the Downrod (Figure 9) .
Page 9 CAUTION CEILING To reduce the risk of injury, install the fan so that the blades are at least 7 ft. (2.1m) above the floor (Figure 11). WARNING Turning off wall switch is not sufficient. To avoid LEAST possible electrical shock, be sure electricity is turned off at the main fuse box before wiring.
Page 10 Securely attach the Hanger Bracket to the Outlet Box using the Two Screws supplied with the Outlet Box . (Figure 13) . OUTLET WARNING TWO SCREWS SUPPLIED WITH OUTLET BOX HANGER Hanger bracket must seat firmly against outlet box. BRACKET If the outlet box is recessed, remove wall board until bracket contacts box.
Page 11: How To Wire Your Ceiling Fan
5. How to Wire Your Ceiling Fan If you feel that you do not have enough electrical NOTE: Make all wiring connections using wiring knowledge or experience, have your fan wire connectors (supplied). Make sure that all installed by a licensed electrician. connections are tight, including ground, and that no bare wire is visible at the wire connectors, except for the ground wire.
Page 12 5. How to Wire Your Ceiling Fan (Continued) Securely connect the Supply White Wire (neutral) to the Receiver White Wire (AC IN N) / (TO MOTOR N) and FAN WHITE Fan Motor White Wire (neutral) using a Wire Connector WIRE (supplied) (Figure 17) .
Page 13 FAN BLACK WIRE RECEIVER BLACK WIRE (TO MOTOR L) Figure 20 RECEIVER BLACK WHITE SUPPLY RECEIVER WIRE WHITE WIRE SUPPLY WIRE BLACK RECEIVER Complete wiring diagram of Receiver, Supply & Ceiling WIRE Fan (Figure 21) . BLACK/WHITE RECEIVER WIRE BLUE RECEIVER After connections have been made, turn Wires upward WIRE and carefully push Wires into the Outlet Box, with the...
Page 14 CEILING COVER & RECEIVER NOT SHOWN FOR CLARITY. Screw the two Threaded Studs (supplied) into the tapped holes in the Hanger Bracket (Figure 22) . THREADED STUDS (2) Figure 22 Lift the Ceiling Cover up to the Threaded Studs and turn until Studs protrude through the holes in the Ceiling Cover (Figure 23) .
Page 15 FAN MOTOR ASSEMBLY WHITE WIRE FAN MOTOR ASSEMBLY BLUE WIRE LED LIGHT FIXTURE ASSEMBLY BLACK WIRE LED LIGHT FIXTURE ASSEMBLY WHITE WIRE LED LIGHT FIXTURE ASSEMBLY Figure 24 LOWER Remove one of the three M4 x 10 mm Pan Head HOUSING Screws in the Lower Housing and loosen the remaining two screws .
Page 16 LOWER Rotate the LED Light Fixture Assembly clockwise on HOUSING the Lower Housing by engaging the two loosened screws onto the key hole slots (Figure 26) . Secure the LED Light Fixture Assembly by tightening the two M4 x 10 mm Pan Head Screws . Reinstall the M4 x 10 mm Pan Head Screw that was previously removed .
Page 17: Optional Installation Of No-Light Cover
7. Optional Installation of No-Light Cover NOTE: To use the No-Light Cover, the LED Light Fixture Assembly MUST NOT Be Installed, or the LED Light Fixture Assembly MUST Be Removed. WARNING Turning off wall switch is not sufficient. To avoid possible electrical shock, be sure electricity is turned off at the main fuse box before wiring.
Page 18 7. Optional Installation of No-Light Cover (Continued) Disconnect the LED Light Fixture Assembly wire terminals from the Fan Motor Assembly wire terminals . (Figure 30) . Store the LED Light Fixture Assembly in a safe location for future installation . Tuck the Fan Motor Assembly wires and connectors into the Lower Housing prior to assembling the No-Light FAN MOTOR...
Page 19: Remote Control Procedures
8. Remote Control Procedures 8.1: Preset Memory Feature WARNING Your Receiver is equipped with a preset memory Fan installation must be completed, including the feature . If the AC supply to the Receiver is powered installation of the fan blades, before testing the remote through a Wall Switch, when the Switch is turned OFF, control.
Page 20 Your Remote Control has full control of your Ceiling Fan and Light POWER INDICATOR When power is restored, push and hold the FAN LIGHT POWER OFF Button ( ) for 3 to 5 Seconds to set FAN POWER OFF the Code in the Receiver (Figure 34) . BUTTON NOTE: The Ceiling Fan Lights (if installed) will Blink to indicate the Transmitter has been paired with the...
Page 21: Power Indicator Light
To turn the Downlight ON/OFF: Press and release the ( ) Button . The Light will turn ON at the Light Intensity previously selected . To change the Intensity, POWER INDICATOR LIGHT hold the Button down . The Intensity will go up and down while the Button is held .
Page 22: Maintenance
8.8: Storage Bracket Installation A Storage Bracket is provided for holding your Remote Control when not in use . If you desire to use the Bracket, install it on a wall that is away from excess heat or humidity . COVER Slide the Wall Bracket Cover up to expose the Screw Holes for installation (Figure 38) .
Page 23: Troubleshooting
10. Troubleshooting WARNING FOR YOUR OWN SAFETY TURN OFF POWER AT FUSE BOX OR CIRCUIT BREAKER BEFORE TROUBLESHOOTING YOUR FAN. TROUBLE PROBABLE CAUSE SUGGESTED REMEDY 1. Fan will not start. 1. Fuse or circuit breaker blown. 1. Check main and branch circuit fuses or circuit breakers. WARNING Make sure main power is turned OFF.
Page 24: Repair Parts
11. Repair Parts PARTS BAG 10 - 52" 11- 44" BP7537-1 Curva LED Outdoor (EnSpFr) 20210201.indb 24 BP7537-1 Curva LED Outdoor (EnSpFr) 20210201.indb 24 2/1/21 4:16 PM 2/1/21 4:16 PM...
Page 25: Energy Efficient Use Of Ceiling Fan
12. Energy Efficient Use of Ceiling Fans Ceiling fan performance and energy savings rely Using the Ceiling Fan Year Round. In the summer, heavily on the proper installation and use of the use the ceiling fan in the counter-clockwise direction . ceiling fan .
Page 26 SERIAL NUMBER: DATE CODE: The serial number of this fan can be found on the nameplate on top of the fan housing . The date code can be found on the carton and on top of the fan housing, stamped in ink on a white label . You should record this data above and keep it in a safe place for future use .

This manual is also suitable for:

Curva cf244lorb00 Curva cf244lww00 Curva cf252lgrt00 Curva cf252lorb00 Curva cf252lww00
