READ AND SAVE THESE INSTRUCTIONS
Ceiling Fan Owner's Manual
CF2000AB02 -
CF2000AP02 -
CF2000ORB02 -
Questions, problems, missing parts: Before returning to the store call
Part No. F40BP73230002
Revision: 130605
TM
MAUI BAY
Damp Location
Model Numbers
Antique Brass
Antique Pewter
Oil Rubbed Bronze
26.0
Net Weight:
Emerson Electric Customer Service
8 a.m. - 6 p.m., EST, Monday-Friday
1-800-654-3545
www.emersonfans.com
™
Lbs.
Form No. BP7323-2
U.L. Model No.: CF2000
Advertisement
Table of Contents
Related Manuals for Emerson MAUI BAY CF2000AB02
Summary of Contents for Emerson MAUI BAY CF2000AB02
- Page 1 CF2000ORB02 - Oil Rubbed Bronze 26.0 Net Weight: Lbs. Questions, problems, missing parts: Before returning to the store call Emerson Electric Customer Service 8 a.m. - 6 p.m., EST, Monday-Friday 1-800-654-3545 Part No. F40BP73230002 Form No. BP7323-2 www.emersonfans.com Revision: 130605...
-
