Lubrication Points - Two-Stage Snowblower

Ident
No. Location
1 Auger Sections
2 Gearbox
3 Cutting Edge
4 Skid Shoes
5 Gearbox Shaft
6 Rotation Worm
7 Reduction Chain
8 Sprockets
9 Parallel Bar Pivot Pins
10 Universal Joint Shaft Assembly
(Grease Slide Area)
SERVICE INSTRUCTIONS
July 2006
Lubrication No.
Type Places
Grease 2
*
Oil 1
Oil 1
Grease 2
Oil 1
Grease 1
Oil 1
Oil 2
Oil 2
**
Grease 1
WALKER MANUFACTURING COMPANY
Page: 2-42
Ident
No. Location
11 Rotation Handle Pivot
12 Plastic Anti-Friction Insert
13 Chute Knobs
14 Deflector Slide Area
*
Gearboxes are permanently lubricated and sealed requiring
no scheduled lubrication. Oil level should be checked only
when an oil leak is noted. Refer to Two-Stage Snowblower
Gearbox in this section.
**
Grease every eight (8) hours.
Lubrication No.
Type Places
Oil 1
Grease 1
Grease 2
Grease 1
