- Page 1 Operating Instructions Wall saw WSE1217 Index 000 Original operating instructions 10991490 en / 11.08.2015...
- Page 2 Any repair work must be carried out by trained personnel only. Our aftersales service is available to help ensure that your TYROLIT Hydrostress units remain in perfect working order.
- Page 3 TYROLIT Hydrostress AG Safety These instructions are just one part of the documentation which is supplied together with the wall saw. These instructions go together with the «Safety Manual / System Description for Wall Saws» to form a complete set of documentation.
- Page 4 TYROLIT Hydrostress AG Description Wall saw system The design and function of the wall saw systems are described in the “Safety Manual / System Description for Wall Saws”. Wall saw Components 1 Guide roller 10 Feed motor cable 2 Lock unit...
-
Page 5: Assembly / Disassembly
TYROLIT Hydrostress AG Assembly / Disassembly Place the wall saw on the guide rail 2. If the grips fail to engage or the wall saw sits too loosely on the guide rail: adjust the guide rollers. Adjusting the guide rollers * The guide rollers are set correctly when they align in the guide groove and it is possible to turn them by hand. -
Page 6: Mounting The Drive Motor
Mounting the saw blade DANGER It can cause death or serious injury if the saw blade flies away. X Only use original screws and bolts from TYROLIT Hydrostress AG. DANGER Serious injury can be caused by sudden start-up of the saw blade. - Page 7 TYROLIT Hydrostress AG 3.4.2 Preassemble the saw blade unit The direction of rotation of the saw blade must match the direction of rotation of the machine. Correct alignment: Countersinking of the fastening holes against the blade cover. For normal cuts with saw blades up to Ø 1,000 mm For normal cuts with saw blades bigger than Ø...
- Page 8 TYROLIT Hydrostress AG For flush cuts 3.4.3 Fastening the saw blade unit DANGER It can cause death or serious injury if the saw blade flies away. X Check whether the sleeve and central screw are countersunk. X Tighten the central screw to a torque of 60 Nm.
-
Page 9: Mounting The Blade Guard
TYROLIT Hydrostress AG Removing the saw blade unit WARNING Injuries can be caused if the saw blade drops down. X Lift out the saw blade unit to the top when removing it. 2. Disassemble the saw blade unit in the reverse order to the assembly process. - Page 10 TYROLIT Hydrostress AG Connecting the wall saw to the control unit 9 The control unit is isolated from the power supply. 9 Connectors/plugs are clean. 9 Cables are undamaged. Page 10 Wall saw WSE1217...
-
Page 11: Maintenance And Servicing
TYROLIT Hydrostress AG Maintenance and servicing Maintenance and servicing table Wall saw X Retighten loose bolts and nuts (re- fer to the tightening torque specifi- cations) X Clean * Lock unit X Clean latching recesses and guide grooves * X Lubrication... -
Page 12: Lubricating The Lock Unit
Changing the gear oil The use of unsuitable oil can damage the wall saw. X Use only TYROLIT Hydrostress AG oil containers (no. 10981362, 10 dl). Replacing the guide rollers X Defective guide rollers should be replaced with replacement set no. 10977911. - Page 13 TYROLIT Hydrostress AG Technical data Dimensions Measurements in mm Design Design Parameter Value Construction Light aluminium/steel construction Rotatable swivel arm 360° Power transmission Toothed wheel Carrying handle 2-pieces, with locking function Guide rollers Low-wearing, suitable for all VS and VAS rails...
-
Page 14: Feed Motor, Travel
TYROLIT Hydrostress AG Weight Weight Parameter Value 22 kg Wall saw head complete 15 kg Drive motor Blade drive motor Blade drive motor Parameter Value Electric motor High-frequency, water-cooled Voltage 400 V Frequency 50 - 400 Hz Feed motor, travel... -
Page 15: Saw Blades
TYROLIT Hydrostress AG Saw blades Saw blades Parameter Value Saw blade max. Ø 1,200 mm Fully detachable saw blade Ø 800 mm Blade holder Ø 60 mm Blade flange mounting at wall saw Quick-release flange ST Saw blade fixing on blade flange... -
Page 16: Ec Declaration Of Conformity
TYROLIT Hydrostress AG EC declaration of conformity Description Wall saw Type designation WSE1217 Year of construction 2011 We declare under our sole responsibility that this product complies with the following direc- tives and standards: Directive applied 2006/42/EC from 17th May 2006...
