OPERATING INSTRUCTIONS
WALL SAW WSE2226
Index 000
Originalbetriebsanleitung
10991485 en / 14.08.2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WSE2226QC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for TYROLIT Hydrostress WSE2226QC

  • Page 1 OPERATING INSTRUCTIONS WALL SAW WSE2226 Index 000 Originalbetriebsanleitung 10991485 en / 14.08.2018...
  • Page 2 Any repair work must be carried out by trained personnel only. Our aftersales service is available to help ensure that your TYROLIT Hydrostress units remain in perfect working order.
  • Page 3 TYROLIT Hydrostress AG Safety These instructions are just one part of the documentation which is supplied together with the wall saw. These instructions go together with the «Wall Saw Safety Manual / System Descrip- tion» to form a complete set of documentation.
  • Page 4: Wall Saw System

    TYROLIT Hydrostress AG Description Wall saw system The design and function of the wall saw systems are described in the «Wall Saw Safety Manual / System Description». Wall saw Components 1 Guide prism 11 Rotary gear speed knob 2 Chassis...
  • Page 5: Assembly / Disassembly

    TYROLIT Hydrostress AG Assembly / Disassembly Place the wall saw on the guide rail Wall saw WSE2226 Page 5...
  • Page 6 TYROLIT Hydrostress AG Guide prism fine adjustment Page 6 Wall saw WSE2226...
  • Page 7: Mounting The Drive Motor

    TYROLIT Hydrostress AG Mounting the drive motor Wall saw WSE2226 Page 7...
  • Page 8: Mounting The Saw Blade

    Mounting the saw blade DANGER Death or serious injury can be caused by escaping saw blades! X Only use original screws and bolts from TYROLIT Hydrostress AG. DANGER Serious injury can be caused by sudden start-up of the saw blade X Switch off the control unit before working on the saw blade.
  • Page 9 TYROLIT Hydrostress AG 3.4.4 Fixing for normal cuts with saw blades bigger than Ø 1000 mm 3.4.5 Fixing with flush cut Wall saw WSE2226 Page 9...
  • Page 10 TYROLIT Hydrostress AG Securing the saw blade unit DANGER Death or serious injury can be caused by escaping saw blades! X Check whether the sleeve and central screw are countersunk. X Tighten the central screw to a torque of 60 Nm.
  • Page 11: Blade Guard

    TYROLIT Hydrostress AG Removing the saw blade unit WARNING Injuries can be caused if the saw blade drops down. X Lift out the saw blade unit to the top when removing it. 2. Disassemble the saw blade unit in the reverse order to the installation/assembly process.
  • Page 12: Selecting Gear

    TYROLIT Hydrostress AG Selecting gear Gears I and II are selected in relation to the tool diameter. Select the switch position in accordance with the size of the saw blade. Never use force, and always change over with the drive motor stationary.
  • Page 13 TYROLIT Hydrostress AG Connecting the wall saw to the control unit 9 The control unit is isolated from the power supply. 9 Connectors/plugs are clean. 9 Cables are undamaged Wall saw WSE2226 Page 13...
  • Page 14: Operation

    TYROLIT Hydrostress AG Operation The WSE2226 wall saw is turned into a wall sawing system by adding suitable TYROLIT Hy- drostress components. Information on safe working with wall saw systems can be found in the «Wall Saw Safety Manual / System Description».
  • Page 15: Water Supply

    TYROLIT Hydrostress AG Water supply Wet and dry cut The WSE2226 wall saw can be used for wet and dry cutting. For dry cutting the water is led away via a bypass after cooling the main motor. Water connection Parameter...
  • Page 16: Servicing And Maintenance

    TYROLIT Hydrostress AG Servicing and maintenance Maintenance and servicing table Wall saw X Retighten loose bolts, screws and nuts (refer to the tightening torque speci- fications) X Check cleanliness Lock unit X Clean latching recesses and guide grooves X Lubricate (page 17 / 5.1)
  • Page 17: Lubricating The Lock Unit

    TYROLIT Hydrostress AG Lubricating the lock unit Changing the gear oil The use of unsuitable oil can damage the wall saw. X Only use TYROLIT Hydrostress AG oil containers. Swivel arm: Oil container no. 10981362, 1dl Drive motor gears: Oil container no. 10992759, 2dl Wall saw WSE2226...
  • Page 18 TYROLIT Hydrostress AG Replacing the sliding prisms X Defective or worn guide prisms must be replaced with new guide prisms. Page 18 Wall saw WSE2226...
  • Page 19 TYROLIT Hydrostress AG Technical data Dimensions Measurements in mm Design Design Parameter Value Construction Light aluminium/steel construction Rotatable swivel arm 360° Power transmission Gear wheel Carrying handle 2-piece with locking function Sliding guide Low-wearing, suitable for all VS and VAS rails...
  • Page 20: Feed Motor, Travel

    TYROLIT Hydrostress AG Weight Weight Parameter Value 26 kg Wall saw head complete 25 kg Drive motor Blade geared drive motor Blade drive motor Parameter Value Electric motor High-frequency, water-cooled Voltage 390 V Frequency 400 Hz Gears 2 (gear I  i=6 / gear II  i=3)
  • Page 21: Saw Blades

    TYROLIT Hydrostress AG Saw blades Saw blades Parameter Value Saw blade max. Ø 2,200 mm Fully detachable saw blade Ø 1,000 mm Blade holder Ø 60 mm Blade flange mounting at wall saw Quick-release flange ST Saw blade fixing on blade flange...
  • Page 22 TYROLIT Hydrostress AG 6.10 Connectable control units The wall saw must only be operated with the coordinated control units from TYROLIT Hydros- tress. Control unit Parameter Type Control unit WSE2226 (Ø800 / Ø1,000 / Ø1,200 / Ø1,600 / Ø1,800 / Ø2,000 / Ø2,200) 6.11...
  • Page 23: Eu Declaration Of Conformity

    TYROLIT Hydrostress AG EU Declaration of Conformity Description Wall saw Type designation WSE2226 Year of construction 2011 We declare under our sole responsibility that this product complies with the following direc- tives and standards: Applied directives 2006/42/EC from 17th May 2006...
