Kit Contents - Phoenix Model strega Instruction Manual

Instruction Manual
KIT CONTENTS: We have organized the parts as they were out of the box for better
identification during assembly. We recommend that you regroup the parts in the same
manner. This will ensure you have all of parts required before you begin assembly.
AIR FRAME ASSEMBLIES
• (2) Wing halves with ailerons
• (1) Fuselage with canopy, motor mount
• (1) Horizontal stabilizer with elevator halves
• (1) Vertical stablilizer with rudder
• (1) Fiber glass cowling
• (1) Air scoop
• (2) Wing fillet
MAIN GEAR ASSEMBLY
• (2) Main gear
• (2) 60mm diameter wheels
• (4) Nylon strap
• (4) Collars
• (4) 3mm x 6mm screws collars
• (8) 3mm x 12mm wood screw
TAIL WHEEL ASSEMBLY
• (1) Tail wheel bracket w/wire
• (1) 25mm diameter wheel
• (1) 2mm collar
• (1) 4mm screw
• (2) Nylon control clasp
• (4) 2mm x 10mm wood screw
ELEVATOR CONTROL SYSTEM
• (1) Nylon clevis
• (1) Silicon tube
• (1) Nylon snap keeper
• (1) Nylon control horn w/plate
• (2) 2mm x 14mm wood screw
RUDDER CONTROL SYSTEM
• (1) Nylon clevise
• (1) Silicon tube
• (1) Nylon snap keeper
• (1) Nylon control horn w/plate
• (2) 2mm x 14mm wood screw
MOTOR MOUNT ASSEMBLY
• (4) 3mm x 20mm screws
• (4) Lock washer

KIT CONTENTS

AILERON CONTROL SYSTEM
• (2) 2mm x 180mm threaded wires
• (2) Nylon clevises
• (2) Silicon tube
• (2) Nylon snap keeper
• (2) Nylon control horn w/plate
• (4) 2mm x 20mm wood screw
• (4) 20mm x 25mm block of woods
• (8) 2mm x 12mm wood screw
THROTTLE CONTROL SYSTEM
• (1) 1,3mm x 500mm wire
• (1) 3,5mm x 350mm nylon pushrod housing
• (1) Metal connector
• (1) 4mm x 4mm screw
FUEL TANK
• (1) Nylon fuel Tank
• (1) Metal clunk
• (1) Silicon tube / 110mm
• (1) Pre - assembled stopper w / 3 tube
• (1) 165mm x 250mm foam protec
MISCELLANEOUS ITEMS
• (1) Plywood dihedral brace
• (2) 4mm x 25mm x 81mm light wood
• (4) 25mm light wood triangle stock
• (2) 25mm x 600mm trim tape
• (4) 6mm x 45mm nylon screws
• (2) Nylon plate of screw
• (4) 3mm x 12mm wood screws
• (1) Decal sheet.
• (1) Set of pushrod
• (1) Block of wood
• (1) Spinner
ADDITIONAL ITEMS REQUIRED
• 46 two stroke Engine.
• 52 four stroke Engine.
• 4 channel Radio with 5 servos.
• Glow plug to suit Engine.
• Propeller to suit Engine.
• Protective foam Rubber.
• Silicon fuel line.
• Stick on weight for balance.
1
Strega
