Thermal Dynamics C-20A Cutskill Service Manual page 30

7.01 Parts List Power Supply
Item Number
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
2
1
Art # A-07743
Parts List
Quantity Description
1 Cable Ground PG29
1 Case, Front
1 Circuit Breaker
1 PCB-Front
1 Cover Assembly
1 Solenoid Assembly
1 Cover, Back
1 Cable Ground PG21
1 Air Assembly
1 Cooling Fan
1 Connector
1 Main Trans and Reactor Assy
1 Heat Sink Assembly
1 Case, Bottom
1 Case, Terminal Plate
1 PCB-Torch Filter
1 Case, Top
1 PCB-Control
1 PCB-Input Filter
1 Control Transformer
1 Pilot Relay Assembly
1 Current Sensor
1 Bracket, Upper
1 PCB-Input Capacitor Assembly
3
4
7-2
Catalog Number
5
6
10
9-0382
9-0323
9-7176
9-7117
9-0293
9-0294
9-0295
9-0296
9-0297
9-7163
9-0305
9-0325
9-0306
9-0298
9-0327
9-7121
9-0299
9-7115
9-7126
9-7150
9-0304
9-7153
9-0301
9-7127
7
8
9
Maual 0-4697
