JOYTEST
POTODAT
POTlDAT
POTOO
POTOOR
necessary to logically
combine
(exclusive OR)
the
lower two bits of each counter.
This is illustrated in
the
following table.
To detect
Forward
Left
Back
Right
Read these
counter bits
Yl xor YO (BIT#09 xor BIT#08)
Y1
Xl xor XO (BIT#Ol xor BIT#OO)
Xl
036 W D Write to all four joystick-mouse counters
at once.
Mouse counter write test data:
BIT# 15,14,13,12,11,10,09,08 07,06,05,04,03,02,01,00
ODAT
Y7
Y6 YS Y4 Y3 Y2 xx xx
X7
X6
X5
X4 X3 X2 xx xx
lDAT
Y7
Y6 YS Y4 Y3 Y2 xx xx
X7
X6
X5
X4 X3 X2 xx xx
012 R P Pot counter data left pair (vert,horiz)
014 R P Pot counter data right pair (vert,horiz)
These
addresses each read a pair of 8-bit pot counters.
(Four counters total.)
The
bit assignment for both
addresses is shown below.
The
counters are stopped by
signals from two controller connectors (left-right)
with two pins each.
BIT# 15,14,13,12,11,10,09,08 07,06,05,04,03,02,01,00
RIGHT Y7 Y6 YS Y4 Y3 Y2 Yl YO X7 X6 X5 X4 X3 X2 Xl XO
LEFT Y7 Y6 YS Y4 Y3 Y2 Y1 YO X7 X6 X5 X4 X3 X2 Xl XO
CONNECTORS PAUIA
Loe. Dir. Sym Pin Pin# Pin Name
----
---
---- --------
RIGHT Y RY
9 36
(POT1Y)
RIGHT X
RX
5 35 (POTlX)
LEFT
Y
LY 9 33 (POTOY)
LEFT
X
LX
5
32 (POTOX)
034 W P Pot port data write and start.
016 R P Pot port data read (formerly called POTINP).
This register controls a 4-bit bi-directional I/O port
that shares the same four pins as the four pot counters
above.
BIT# FUNCT DESCRIPTION
15
14
13
12
11
10
09
OUTRY
DATRY
OUTRX
DATRX
OUTLY
DATLY
0U'l'LX
Output enable for Paula pin 36
I/O data Paula pin 36
Output enable for Paula pin 35
I/O data Paula pin 35
Output enable for Paula pin 33
I/O data Paula pin 33
Output enable for Paula pin 32
SERDAT
SERDATR
08 DATLX
07-01 0
00 START
I/O data Paula pin 32
Reserved for chip ID code (presently 0)
Start pots (duDp capacitors. start
counters)
028 W A Refresh pointer
This register is used
as a dynamic RAM refresh
address generator. It is writeable for test
purposes only, and should never be written by
the
microprocessor.
030 W P Serial port data and stop bits write
(transmit data buffer)
This address writes data to a transmit data buffer.
Data from this buffer is moved into a serial shift
register for output transmission whenever it is
eopty. This sets the interrupt request
TBE
(transmit buffer eopty).
A
stop bit must be
provided as part of
the data word. The length of
the
data word is set by
the position of the stop
bit.
BIT# 15,14,13,12,11,10,09,08,07,06,05,04,03,02,01,00
USE 0 0 0 0 0 0 S
DB
D7
D6
D5
D4
D3 D2 D1 DO
Note: S
=
stop bit
=
1, D
=
data bits.
018 R P Serial port data and status read
(receive data buffer)
This address reads data from a receive data buffer.
Data in this buffer is loaded from a receiving
shift register whenever it is full. Several
interrupt request bits are also read at this
address, along with
the
data, as shown below.
BIT#
15
1<1
13
12
11
10
~9
OVRUN
RBF
TBE
TSRE
RXD
0
STP
08 STP-DB8
07 DB7
06 DB6
05 DBS
04 DB4
03 DB3
02 DB2
01 DBl
00 DBO
Serial port receiver overrun.
Reset by resetting bit 11 of
INTREQ.
Serial port receive buffer full
(mirror) •
Serial port transmit buffer
eopty (mirror).
Serial port transmit shift
register eopty.
Reset by loading into buffer.
RXD pin receives UART serial
data for direct bit test by
the microprocessor.
Not used
Stop bit
Stop bit i f LONG. data bit if
not.
Data bit
Data bit
Data bit
Data bit
Data bit
Data bit
Data bit
Data bit
