10 Quick Start Guide
A
B
C
D E F G
O
N
M L
A.
Power switch
B.
Reset switch
C. NMI switch
D. Power LED (green)
E.
Power fault LED (yellow)
F.
Cooling fault LED (yellow)
G. Drive fault LED (yellow)
H. Front panel LCD
I.
Drive fault LED (yellow)
J.
Drive activity LED (green)
K.
Drive power LED (green)
L.
Open/close button
M. Activity LED
N. Volume control
O. Headphone jack
P.
Activity LED
Q. Ejector button
H
K J I
OM07301
