Connect keyboard, mouse, and monitor, and printer

Keyboard
Connect the signal cable of a PS/2
I/O panel.
Mouse
Connect the signal cable of a PS/2-compatible mouse to the mouse port on the server I/O panel.
Monitor
Connect the signal cable of the video monitor to the Super VGA
Printer Connect the signal cable of a PS/2-compatible printer to the parallel port on the server I/O panel.
N
M
L
K
A. PCI and ISA add-in board expansion slots
B. External LVDS connector
C. PS/2-compatible keyboard/mouse port, 6-pin
D. PS/2-compatible keyboard/mouse port, 6-pin
E. PS/2-compatible serial ports 0 and 1, 9-pin
RS-232 connector
F. Super VGA compatible, 15-pin video connector
G. PS/2-compatible parallel port (LPT), 25-pin
bidirectional subminiature D connector
8 Quick Start Guide
†
-compatible keyboard to the keyboard port on the server
A
J
H. USB ports 0 and 1, 4-pin connector
I. Intelligent Chassis Management Bus (ICMB)
connectors port 1 and 2
J. Power supplies
K. Failure LED (yellow)
L. Predictive failure LED (yellow) for power supply
fan
M. Power LED (green)
N. AC input power connector
†
port on the server I/O panel.
B C D
E
F
G
H
I
OM07300
