12.1.2 Preset Program Changes

EDIT : PRESET : PAGE
Preset Program Changes is used to set the MIDI Program Change (PC) messages sent by the currently selected MFC-101 preset.
One program change may be set per MIDI channel, up to 16 in total.
You must first select a preset (12.1.0 on p. 36) to edit it using this menu page.
Use the PARAMETER footswitches to move between MIDI Channel and Program Number parameters.
Note that while AXE-FX MODE is ON, the saved Program Change command for the "Axe-Fx MIDI Channel" (12.4.0) will be
IGNORED. Instead, the MFC-101 preset number and "Axe-Fx Default Bank" (12.4.1), or the "Axe-Fx Preset Transmit Map"
(12.4.2) determine which Bank Select and Program Change commands will be sent.
To support program changes from 000-999 with a single parameter, the MFC-101 automatically sends a Bank Select (CC#0)
command preceding the actual program change command, as follows:
Program Range Bank Select
000-127
128-255
256-383
384-511
The actual program change number is the remainder of the value as set, divided by 128. For example, take an MFC-101
Program Change value setting of 200. 200/128 = 1, remainder of 72. The BANK SELECT message will be 1 and the PROGRAM
CHANGE will be 72.

12.1.3 Preset Instant Access Switch States

EDIT : PRESET : PAGE
Preset Instant Access Switch States is used to set the initial ON/OFF state of each IA Switch when the selected preset is loaded.
The saved state determines whether the ON messages or OFF messages will be sent for a given IA Switch when the selected
preset is loaded. The burst of initial data caused by saved IA Switch states provides a kind of "scene recall" for your rig
triggered simply by loading a preset. After they are initially set, the states of IA Switches can be changed any time just by
stomping.
You must first select a preset (12.1.0 on p. 36) to edit it using this menu page.
Use the PARAMETER footswitches to switch between IA Switch Number and IA Switch State parameters.
NOTE: The saved states for IA Switches set to Axe-Fx Functions (see 12.4.6) are IGNORED. Instead, the actual effect block states
saved in the Axe-Fx preset are used to dynamically set the MFC-101 switch states (and LEDs):
GREEN=PRESENT & ACTIVE
RED=PRESENT & BYPASSED
OFF=NOT PRESENT
NOTE: IA Switch states can also be stored on-the-fly using the SAVE footswitch (see 12.5.16).
Doc v1.0.1
(2x)
Program Range
0 512-639
1 640-767
2 768-895
3 895-999
(3x)
Bank Select
4
5
6
7
