500 Ced Wiring Diagram, 115V/60Hz, Lancer Electronic Ice Bank Control - lancer Series 500 Operation Manual

6.4

500 CED WIRING DIAGRAM, 115V/60HZ, LANCER ELECTRONIC ICE BANK CONTROL

WHEN STARTING UNIT OR IF CURRENT IS INTERRUPTED, THERE IS
A FIVE (5) MINUTE DELAY BEFORE THE COMPRESSOR/FAN STARTS.
GREEN
BLACK
WHITE
AGITATOR
MOTOR
24V LEADS
TRANSFORMER
IMPORTANT
JCT.
LANCER
ICE
BANK
CONTROL
LABEL, WIRING DIAGRAM, CED, PN 06-0031/01
EIBC PROBE CONNECTION
CONTROL HOUSING CONNECTIONS
FAN
MOTOR
COMPRESSOR
PROBE
POWER INDICATOR LAMP
HOT OUT
HOT IN
24
OVERLOAD
C
M
S
M
S
RELAY L
LABEL, WIRING
500 / 2500, CED
06-0031/01
POWER
CONNECTIONS
