IDE Primary Master/Slave UDMA and IDE Secondary Master/
Slave UDMA
These fields allow you to set the Ultra DMA in use. When Auto
is selected, the BIOS will select the best available option after
checking your hard drive or CD-ROM.
Auto The BIOS will automatically detect the settings
for you.
Disabled The BIOS will not detect these categories.
On-Chip Serial ATA Setting
This section is used to configure the SATA 1 and SATA 2 ports
that are controlled by the Intel ICH5 chip.
On-Chip Serial ATA
Disabled
Auto
Combined Mode This option allows you to use both IDE and
Enhanced Mode This option allows you to use both IDE and
SATA Only
Disables the onboard SATA.
The system will detect the existing SATA
and IDE drives then automatically set them
to the available master/slave mode.
SATA drives; allowing a maximum of 4
drives. You must manually set the SATA
drives' master/slave mode in the "Serial ATA
Port0 Mode" and "Serial ATA Port1 Mode"
fields.
SATA drives; allowing a maximum of 6
drives.
This option automatically sets the SATA
drives to Primar y Master and Secondar y
Master modes. Since both drives are in mas-
ter mode, you cannot set the IDE drives to
Master mode. The "Serial ATA Port0 Mode"
and "Serial ATA Port1 Mode" fields will not
be configurable.
